Channel FDG6321C
General Description
These dual N & P−Channel logic level enhancement mode field effect transistors are produced using ON Semiconductor’s proprietary, high cell density, DMOS technology. This very high density process is especially tailored to minimize on−state resistance. This device has been designed especially on low voltage replacement for bipolar digital transistors and small signal MOSFETS. Since bias resistors are not required, this dual digital FET can replace several different digital transistors, with different bias resistor values.
Features
• N−Ch 0.50 A, 25 V
♦
R
DS(ON)= 0.45 W @ V
GS= 4.5 V
♦
R
DS(ON)= 0.60 W @ V
GS= 2.7 V
• P−Ch −0.41 A, −25 V
♦
R
DS(ON)= 1.1 W @ V
GS= −4.5 V
♦
R
DS(ON)= 1.5 W @ V
GS= −2.7 V
• Very Small Package Outline SC70−6
• Very Low Level Gate Drive Requirements Allowing Direct Operation in 3 V Circuits (V
GS(th)< 1.5 V)
• Gate−Source Zener for ESD Ruggedness (>6 kV Human Body Model)
• These Devices are Pb−Free and are RoHS Compliant
ABSOLUTE MAXIMUM RATINGS (TA = 25°C unless otherwise noted) Symbol Parameter N−Channel P−Channel Units
VDSS Drain−Source Voltage 25 −25 V
VGSS Gate−Source Voltage 8 −8 V
ID Drain Current Continuous 0.5 −0.41 A
Pulsed 1.5 −1.2
PD Maximum Power Dissipation
(Note 1) 0.3 W
TJ, TSTG Operating and Storage
Temperature Range −55 to 150 °C
ESD Electrostatic Discharge Rating MIL−STD−883D Human Body Model (100 pF / 1500 W)
6 kV
Stresses exceeding those listed in the Maximum Ratings table may damage the device. If any of these limits are exceeded, device functionality should not be assumed, damage may occur and reliability may be affected.
SC−88/SC70−6/SOT−363 CASE 419B−02 www.onsemi.com
S1 D2
See detailed ordering and shipping information on page 8 of this data sheet.
ORDERING INFORMATION 21 = Specific Device Code M = Assembly Operation Month
MARKING DIAGRAM G1 D1G2S2
21M
PIN CONNECTIONS
4 6
5
3 1
2
www.onsemi.com 2
THERMAL CHARACTERISTICS
Symbol Parameter Ratings Unit
RqJA Thermal Resistance, Junction−to−Ambient (Note 1) 415 _C/W
1. RqJA is the sum of the junction−to−case and case−to−ambient thermal resistance where the case thermal reference is defined as the solder mounting surface of the drain pins. RqJC is guaranteed by design while RqCA is determined by the user’s board design. RqJA = 415°C/W on minimum pad mounting on FR−4 board in still air.
ELECTRICAL CHARACTERISTICS (TA = 25°C unless otherwise noted)
Symbol Parameter Conditions Type Min Typ Max Unit
OFF CHARACTERISTICS
BVDSS Drain−Source Breakdown Voltage VGS= 0 V, ID= 250 mA N−Ch 25 − − V
VGS= 0 V, ID=−250 mA P−Ch −25 − −
DBVDSS / DTJ Breakdown Voltage Temperature
Coefficient ID= 250mA, Referenced to 25_C N−Ch − 26 − mV/_C
ID=−250mA, Referenced to 25_C P−Ch − −22 −
IDSS Zero Gate Voltage Drain Current VDS= 20 V, VGS= 0 V N−Ch − − 1 mA
VDS= 20 V, VGS= 0 V, TJ = 55_C − − 10
IGSS Gate−Body Leakage Current VDS=−20 V, VGS= 0 V P−Ch − − −1 mA
VDS=−20 V, VGS= 0 V, TJ = 55_C − − −10
IGSS Gate−Body Leakage Current VGS= 8 V, VDS= 0 V N−Ch − − 100 nA
VGS=−8 V, VDS= 0 V P−Ch − − −100 ON CHARACTERISTICS (Note 2)
VGS(th) Gate Threshold Voltage VDS= VGS, ID= 250 mA N−Ch 0.65 0.8 1.5 V
VDS= VGS, ID=−250 mA P−Ch −0.65 −0.82 −1.5 DVGS(th) / DTJ Gate Threshold Voltage
Temperature Coefficient ID= 250mA, Referenced to 25_C N−Ch − −2.6 − mV/_C ID=−250mA, Referenced to 25_C P−Ch − 2.1 −
RDS(ON) Static Drain−Source
On−Resistance VGS= 4.5 V, ID= 0.5 A N−Ch − 0.34 0.45 W
VGS= 4.5 V, ID= 0.5 A, TJ = 125_C − 0.55 0.72
VGS= 2.7 V, ID= 0.2 A − 0.44 0.6
VGS=−4.5 V, ID=−0.41 A P−Ch − 0.85 1.1 VGS=−4.5 V, ID=−0.41 A,
TJ = 125_C − 1.2 1.8
VGS=−2.7 V, ID=−0.05 A − 1.15 1.5
ID(ON) On−State Drain Current VGS= 4.5 V, VDS= 5 V N−Ch 0.5 − − A
VGS=−4.5 V, VDS=−5 V P−Ch −0.41 − −
gFS Forward Transconductance VDS= 5 V, ID= 0.5 A N−Ch − 1.45 − S
VDS=−5 V, ID=−0.41 A P−Ch − 0.9 − DYNAMIC CHARACTERISTICS
Ciss Input Capacitance N−Channel
VDS= 10 V, VGS= 0 V, f = 1.0 MHz P−Channel
VDS=−10 V, VGS= 0 V, f = 1.0 MHz
N−Ch − 50 − pF
P−Ch − 62 −
Coss Output Capacitance N−Ch − 28 −
P−Ch − 34 −
Crss Reverse Transfer Capacitance N−Ch − 9 −
P−Ch − 10 −
ELECTRICAL CHARACTERISTICS (TA = 25°C unless otherwise noted) (continued)
Symbol Parameter Conditions Type Min Typ Max Unit
SWITCHING CHARACTERISTICS (Note 2)
tD(on) Turn-On Delay Time N−Channel
VDD= 5 V, ID= 0.5 A, VGS= 4.5 V, RGEN= 50W P−Channel
VDD=−5 V, ID=−0.5 A, VGS=−4.5 V, RGEN= 50W
N−Ch − 3 6 ns
P−Ch − 7 15
tr Turn-On Rise Time N−Ch − 8.5 18 ns
P−Ch − 8 16
tD(off) Turn-Off Delay Time N−Ch − 17 30 ns
P−Ch − 55 80
tf Turn-Off Fall Time N−Ch − 13 25 ns
P−Ch − 35 60
Qg Total Gate Charge N−Channel
VDS= 5 V, ID= 0.5 A, VGS= 4.5 V P−Channel
VDS=−5 V, ID=−0.41 A, VGS=−4.5 V
N−Ch − 1.64 2.3 nC
P−Ch − 1.1 1.5
Qgs Gate−Source Charge N−Ch − 0.38 − nC
P−Ch − 0.31 −
Qgd Gate−Drain Charge N−Ch − 0.45 − nC
P−Ch − 0.29 −
DRAIN−SOURCE DIODE CHARACTERISTICS AND MAXIMUM RATINGS
IS Maximum Continuous Drain−Source Diode Forward Current N−Ch − − 0.25 A
P−Ch − − −0.25
VSD Drain−Source Diode Forward
Voltage VGS= 0 V, IS= 0.5 A (Note 2) N−Ch − 0.8 1.2 V
VGS= 0 V, IS=−0.5 A (Note 2) P−Ch − −0.8 −1.2
Product parametric performance is indicated in the Electrical Characteristics for the listed test conditions, unless otherwise noted. Product performance may not be indicated by the Electrical Characteristics if operated under different conditions.
2. Pulse Test: Pulse Width ≤ 300 ms, Duty Cycle ≤ 2.0%
www.onsemi.com 4
TYPICAL PERFORMANCE CHARACTERISTICS: N−CHANNEL
0 0.2 0.4 1 1.2
0.5 1 1.5 2
I , DRAIN CURRENT (A)
DRAIN−SOURCE ON−RESISTANCE
V = 2.0 VGS
2.7 V 3.0 V
4.5 V
D
3.5 V 2.5 V
R , NORMALIZED
−50 −25 0 25 50 75 100 125 150
0.6 0.8 1 1.2 1.4 1.6
T , JUNCTION TEMPERATURE (°C)
DRAIN−SOURCE ON−RESISTANCE
J V = 4.5 VGS
I = 0.5 AD
R , NORMALIZEDDS(ON)
0 0.5 1 1.5 2 2.5 3
0 0.3 0.6 0.9 1.2 1.5
I , DRAIN−SOURCE CURRENT (A)
2.7 V
2.5 V V = 4.5 VGS
2.0 V
1.5 V
DS
D
3.0 V
1 1.5 2 2.5 3 3.5 4 4.5 5
0 0.4 0.8 1.2 1.6 2
V , GATE TO SOURCE VOLTAGE (V)GS I = 0.3 AD
T = 125°CA
T = 25A °C
0 0.5 1 1.5 2 2.5
0 0.2 0.4 0.6 0.8 1
V , GATE TO SOURCE VOLTAGE (V)
I , DRAIN CURRENT (A)
25°C 125°C V = 5.0 VDS
GS
T = −55°CJ
0 1 1.2
0.0001 0.001 0.01 0.1 1
V , BODY DIODE FORWARD VOLTAGE (V)
I , REVERSE DRAIN CURRENT (A)
T = 125°CJ
25°C
−55°C V = 0 VGS
SD
Figure 1. On−Region Characteristics Figure 2. On−Resistance Variation with Drain Current and Gate Voltage
Figure 3. On−Resistance Variation with Temperature
Figure 4. On−Resistance Variation with Gate−to−Source Voltage
Figure 5. Transfer Characteristics Figure 6. Body Diode Forward Voltage Variation with Source Current and Temperature
V , DRAIN−SOURCE VOLTAGE (V)
R , ON−RESISTANCE ( )DS(ON)W
0.6 0.8
0.2 0.4 0.6 0.8
TYPICAL PERFORMANCE CHARACTERISTICS: N−CHANNEL
(continued)0.1 1 2 5 10 25 40
0.01 0.02 0.05 0.1 0.2 0.5 1 3
V , DRAI N−SOURCE VOLTAGE (V)
I , DRAIN CURRENT (A)
DS
D
0.1 0.3 1 2 5 10 25
3 10 30 70 200
V , DRAIN TO SOURCE VOLTAGE (V)
CAPACITANCE (pF)
DS
Ciss
f = 1 MHz V = 0 VGS
Coss Crss
0.00010 0.001 0.01 0.1 1 10 200
10 20 30 40 50
SINGLE PULSE TIME (sec)
POWER (W)
0 0.4 0.8 1.2 1.6 2
0 1 2 3 4 5
Q , GATE CHARGE (nC)
V , GATE−SOURCE VOLTAGE (V)
g
GS
I = 0.5 AD
10 V15 V V = 5 VDS
Figure 7. Gate Charge Characteristics Figure 8. Capacitance Characteristics
Figure 9. Maximum Safe Operating Area Figure 10. Single Pulse Maximum Power Dissipation
SINGLE PULSE RqJA = 415°C/W TA = 25°C
VGS = 4.5 V SINGLE PULSE RqJA = 415°C/W TA = 25°C
www.onsemi.com 6
TYPICAL PERFORMANCE CHARACTERISTICS: P−CHANNEL
0 1 2 3 4
0 0.3 0.6 0.9 1.2
−V , DRAIN−SOURCE VOLTAGE (V)
−I , DRAIN−SOURCE CURRENT (A) V =−4.5 VGS
DS
D −1.5 V
−2.7 V
−2.5 V
−2.0 V −3.0 V
0 0.2 0.4 0.6 0.8 1 1.2
0.5 1 1.5 2 2.5
−I , DRAIN CURRENT (A)
DRAIN−SOURCE ON−RESISTANCE
V = −2.0 VGS
D R , NORMALIZEDDS(ON)
−3.5 V
−4.5 V
−2.7 V
−2.5 V
−3.0 V
0.5 1 1.5 2 2.5 3
0 0.2 0.4 0.6 0.8 1
−V , GATE TO SOURCE VOLTAGE (V)
−I , DRAIN CURRENT (A)
V = −5 VDS
GS
T = −55°CJ
125°C 25°C
0.2 0.4 0.6 0.8 1 1.2
0.0001 0.001 0.01 0.1 1
−V , BODY DIODE FORWARD VOLTAGE (V)
−I , REVERSE DRAIN CURRENT (A)
T = 125°CJ 25°C
−55°C V = 0 VGS
SD
1 2 3 4 5
0 1 2 3 4 5
−V , GATE TO SOURCE VOLTAGE (V)GS I =−0.2 AD
T =125°CJ
25°C
−50 −25 0 25 50 75 100 125 150
0.6 0.8 1 1.2 1.4 1.6
T , JUNCTION TEMPERATURE (°C)
DRAIN−SOURCE ON−RESISTANCE
J R , NORMALIZEDDS(ON)
V = −4.5 VGS
I = −0.41 AD
Figure 11. On−Region Characteristics Figure 12. On−Resistance Variation with Drain Current and Gate Voltage
Figure 13. On−Resistance Variation with Temperature
Figure 14. On−Resistance Variation with Gate−to−Source Voltage
Figure 15. Transfer Characteristics Figure 16. Body Diode Forward Voltage Variation with Source Current and Temperature
R , ON−RESISTANCE ( )DS(ON)W
TYPICAL PERFORMANCE CHARACTERISTICS: P−CHANNEL
(continued)0 0.4 0.8 1.2 1.6
0 1 2 3 4 5
Q , GATE CHARGE (nC)
−V , GATE−SOURCE VOLTAGE (V)
g
GS
V = −5 VDS
−10 V
−15 V I = −0.41 AD
0.1 0.2 0.5 1 2 5 10 25 40
0.01 0.05 0.1 0.5 1 3
− V , DRAIN−SOURCE VOLTAGE (V)
−I , DRAIN CURRENT (A)D
DS
0.1 0.3 1 2 5 10 25
3 5 10 30 80 200
−V , DRAIN TO SOURCE VOLTAGE (V)
CAPACITANCE (pF)
DS
Ciss
f = 1 MHz V = 0 VGS
Coss
Crss
0.00010 0.001 0.01 0.1 1 10 200
10 20 30 40 50
SINGLE PULSE TIME (sec)
POWER (W)
Figure 17. Gate Charge Characteristics Figure 18. Capacitance Characteristics
Figure 19. Maximum Safe Operating Area Figure 20. Single Pulse Maximum Power Dissipation
SINGLE PULSE RqJA = 415°C/W TA = 25°C
VGS = −4.5 V SINGLE PULSE RqJA = 415°C/W TA = 25°C
www.onsemi.com 8
TYPICAL PERFORMANCE CHARACTERISTICS: N & P−CHANNEL
0.0001 0.001 0.01 0.1 1 10 100 200
0.002 0.005 0.01 0.02 0.05 0.1 0.2 0.5 1
t , TIME (sec)
TRANSIENT THERMAL RESISTANCEr(t), NORMALIZED EFFECTIVE
1 Single Pulse
D = 0.5
0.1 0.05
0.02 0.01 0.2
Thermal characterization performed using the conditions described in Note 1.
Transient thermal response will change depending on the circuit board design.
Figure 21. Transient Thermal Response Curve
P(pk) t1
t2
RqJA (t) = r(t) * RqJA RqJA = 415°C/W
TJ − TA = P * RqJA (t) Duty Cycle, D = t1 / t2
ORDERING INFORMATION
Device Order Number Device Marking Package Type Shipping†
FDG6321C 21 SC−88/SC70−6/SOT−363
(Pb−Free) 3000 / Tape & Reel
†For information on tape and reel specifications, including part orientation and tape sizes, please refer to our Tape and Reel Packaging Specifications Brochure, BRD8011/D.
SC−88 (SC−70 6 Lead), 1.25x2 CASE 419AD
ISSUE A
DATE 07 JUL 2010
E1 D
A
L
L1 L2
e e
b
A1 A2
c TOP VIEW
SIDE VIEW END VIEW
q1
q1
Notes:
(1) All dimensions are in millimeters. Angles in degrees.
(2) Complies with JEDEC MO-203.
E
q
SYMBOL MIN NOM MAX
θ A A1
b c D E E1
e L
0º 8º
L2
0.00
0.15 0.10
0.26 1.80 1.80 1.15
0.65 BSC
0.15 BSC
1.10 0.10
0.30 0.18
0.46 2.20 2.40 1.35
L1
0.80
θ1 4º 10º
A2 0.80 1.00
0.42 REF 0.36 2.00 2.10 1.25 1
