MOSFET – N-Channel, POWERTRENCH)

MOSFET – N-Channel, POWERTRENCH ⁾

100 V, 3.2 A, 108 mW

FDT86106LZ

General Description

This N−Channel logic Level MOSFETs are produced using onsemi’s advanced POWERTRENCH process that has been special tailored to minimize the on−state resistance and yet maintain superior switching performance. G−S zener has been added to enhance ESD voltage level.

Features

 Max r

= 108 m W at V

= 10 V, I

= 3.2 A

 Max r

= 153 m W at V

= 4.5 V, I

= 2.7 A

 High Performance Trench Technology for Extremely Low r

 High Power and Current Handling Capability in a Widely Used Surface Mount Package

 HBM ESD Protection Level > 3 kV Typical (Note 4)

 100% UIL Tested

 This Device is Pb−Free, Halide Free and is RoHS Compliant

 DC − DC Conversion

MOSFET MAXIMUM RATINGS(TC = 25C unless otherwise noted)

Symbol Parameter Ratings Unit

V_DS Drain−Source Voltage 100 V

VGS Gate−Source Voltage 20 V

I_D Drain Current − Continuous

T_A = 25C (Note 1a.) 3.2 A

− Pulsed 12

E_AS Single Pulse Avalanche Energy (Note 3) 12 mJ P_D Power

Dissipation T_A = 25C (Note 1a.) 2.2 W TA = 25C (Note 1b.) 1.0 T_J, T_STG Operating and Storage Junction

Temperature Range −55 to

+150 C

Stresses exceeding those listed in the Maximum Ratings table may damage the device. If any of these limits are exceeded, device functionality should not be assumed, damage may occur and reliability may be affected.

THERMAL CHARACTERISTICS

Symbol Parameter Ratings Unit

RqJC Thermal Resistance, Junction to Case 12 C/W RqJA Thermal Resistance, Junction to Ambient

(Note 1a.) 55 C/W

MARKING DIAGRAM SOT−223 CASE 318H

PINOUT

A = Specific Device Code Y = Date Code

W = Work Week

106LZ = Specific Device Code G = Pb−Free Package

V_DSS R_DS(ON) MAX I_D MAX

100 V 108 mW @ 10 V 3.2 A

153 mW @ 4.5 V

(Note: Microdot may be in either location) G D S

D

1

AYW 106LZG

G

G D S

D

Device Package Shipping^† ORDERING INFORMATION

FDT86106LZ 106LZ 4000 / Tape &

Reel

†For information on tape and reel specifications, including part orientation and tape sizes, please refer to our Tape and Reel Packaging Specification Brochure, BRD8011/D.

ELECTRICAL CHARACTERISTICS(TJ = 25C unless otherwise noted)

Symbol Parameter Test Conditions Min Typ Max Unit

OFF CHARACTERISTICS

BV_DSS Drain to Source Breakdown Voltage I_D = 250 mA, VGS = 0 V 100 − − V

DBVDSS

DTJ

Breakdown Voltage Temperature

Coefficient ID = 250 mA, Referenced to 25C − 71 − mV/C

I_DSS Zero Gate Voltage Drain Current V_DS = 80 V, V_GS = 0 V − − 1 mA

I_GSS Gate to Source Leakage Current V_GS = 20 V, V_DS = 0 V − − 10 mA

ON CHARACTERISTICS (Note 2)

V_GS(th) Gate to Source Threshold Voltage V_GS = V_DS, I_D = 250 mA 1.0 1.5 2.2 V DV_GS(th)

DTJ

Gate to Source Threshold Voltage

Temperature Coefficient I_D = 250 mA, referenced to 25C − –5 − mV/C

r_DS(on) Static Drain to Source On Resistance V_GS = 10 V, I_D = 3.2 A V_GS = 4.5 V, I_D = 2.7 A,

V_GS = 10 V, I_D = 3.2 A, T_J = 125C

−−

−

10080 140

108153 189

mW

gFS Forward Transconductance VDS = 10 V, ID = 3.2 A − 8 − S

DYNAMIC CHARACTERISTICS

C_iss Input Capacitance VDS = 50 V, VGS = 0 V, f = 1 MHz − 234 315 pF

C_oss Output Capacitance − 46 65 pF

C_rss Reverse Transfer Capacitance − 3.1 5 pF

SWITCHING CHARACTERISTICS

t_d(on) Turn–On Delay Time V_DD = 50 V, I_D = 3.2 A,

V_GS = 10 V, R_GEN = 6 W − 3.8 10 ns

tr Rise Time − 1.3 10 ns

t_d(off) Turn–Off Delay Time − 10 20 ns

t_f Fall Time − 1.5 10 ns

Qg Total Gate Charge VGS = 0 V to 10 V, VDD = 50 V, ID = 3.2 A − 4.3 7 nC

Q_g Total Gate Charge V_GS = 0 V to 5 V, V_DD = 50 V, I_D = 3.2 A − 2.4 4 nC

Qgs Gate to Source Gate Charge VDD = 50 V, ID = 3.2 A − 0.7 − nC

Q_gd Gate to Drain “Miller” Charge − 0.9 − nC

DRAIN−SOURCE DIODE CHARACTERISTICS

VSD Source to Drain Diode Forward Voltage VGS = 0 V, IS = 3.2 A (Note 2)

V_GS = 0 V, I_S = 1 A (Note 2) −

− 0.86

0.77 1.3

1.2 V

t_rr Reverse Recovery Time I_F = 3.2 A, di/dt = 100 A/s − 31 49 ns

Q_rr Reverse Recovery Charge − 21 34 nC

Product parametric performance is indicated in the Electrical Characteristics for the listed test conditions, unless otherwise noted. Product performance may not be indicated by the Electrical Characteristics if operated under different conditions.

NOTES:

1. R_qJA is the sum of the junction−to−case and case−to−ambient thermal resistance where the case thermal reference is defined as the solder mounting surface of the drain pins. R_qJC is guaranteed by design while R_qJA is determined by the user’s board design.

a. 55C/W when mounted on

a 1 in² pad of 2 oz copper. b. 118C/W when mounted on a minimum pad of 2 oz copper.

TYPICAL CHARACTERISTICS

0.001 0.01 0.1 1 0 1 2

VSD, Body Diode Forward Voltage (V) rDS(on), Drain to Source On−Resistance (mW)

Figure 1. On−Region Characteristics Figure 2. Normalized On−Resistance vs. Drain Current and Gate Voltage

Figure 3. Normalized On−Resistance vs. Junction Temperature

Figure 4. On−Resistance vs. Gate to Source Voltage

Figure 5. Transfer Characteristics Figure 6. Source to Drain Diode Forward Voltage vs. Source Current

0 1 2 3 4

0 3 6 9

V_DS, Drain to Source Voltage (V) ID, Drain Current (A)

0 3 6 9

I_D, Drain Current (A) Normalized Drain to Source On−Resistance

−75 −50 −25 0 25 50 100 125 150

0.6 0.8 1.0 1.2 1.4 1.6

Normalized Drain to Source On−Resistance

T_J, Junction Temperature (C)

2 4 6 8 10

V_GS, Gate to Source Voltage (V)

V_DS = 5 V

VGS, Gate to Source Voltage (V) ID, Drain Current (A)

0.4 0.6 0.8 1.0 1.2

IS, Reverse Drain Current (A)

I_D = 3.2 A 3

0.2 12

4 5

12

0 300 400

200 500

0 3 6 9 12

1 2 3 4 5

1.8 2.0

1020 V_GS = 10 V

VGS = 4.5 V VGS = 4 V

V_GS = 3.5 V

V_GS = 3 V

Pulse Duration = 80 ms Duty Cycle = 0.5% Max

5

VGS = 3 V

VGS = 3.5 V

V_GS = 4V

VGS = 10V V_GS = 4.5 V

Pulse Duration = 80 ms Duty Cycle = 0.5% Max

ID = 3.2 A VGS = 10 V

75

100

Pulse Duration = 80 ms Duty Cycle = 0.5% Max

T_J = 125C

T_J = 25C

Pulse Duration = 80 ms Duty Cycle = 0.5% Max

TJ = −55C T_J = 25C T_J = 150C

V_GS = 0 V

TJ = 150C T_J = 25C

T_J = −55C

TYPICAL CHARACTERISTICS

15 20 25 30 35

0 5 10

1

1 2 5

t_AV, Time in Avalanche (ms)

Ig, Gate Leakage Current (A)

Figure 7. Gate Charge Characteristics Figure 8. Capacitance vs. Drain to Source Voltage

Figure 9. Unclamped Inductive Switching Capability

Figure 10. Gate Leakage Current vs. Gate to Source Voltage

0 1 2 3

Q_g, Gate Charge (nC)

IAS, Avalanche Current (A)

V_DS, Drain to Source Voltage (V)

Capacitance (pF)

VGS, Gate to Source Voltage (V)

V_GS, Gate to Source Voltage (V)

Figure 11. Maximum Continuous Drain Current vs. Case temperature

0 2 4 6 8 10

10 100 400

ID, Drain Current (A)

4 5

0.01 0.1 1 2

7

DC

0.1 1 10 100

I_D = 3.2 A

V_DD = 50 V

VDD = 25 V V_DD = 75 V

f = 1 MHz V_GS = 0 V

C_iss

C_oss

Crss

3 4 6

TJ = 125C T_J = 25C

T_J = 100C

10⁻¹ 10⁻² 10⁻³ 10⁻⁴ 10⁻⁵ 10⁻⁶ 10⁻⁷ 10⁻⁸ 10⁻⁹ 10⁻¹⁰

V_DS = 0 V

T_J = 125C T_J = 25C

25 50 75 100 125 150

0 2 4 6 8

V_GS = 10 V

V_GS = 4.5 V Limited by package

R_qJC = 12C/W

T_C, Case Temperature (C)

0.01 0.1 1 10 20

0.1 1 10 100 400

V_DS, Drain to Source Voltage (V) ID, Drain Current (A)

This area is limited by r_DS(on)

Single Pulse T_J = Max Rated R_qJA = 118C/W

T_A = 25C ^{10 s}

1 s 100 ms10 ms

1 ms 100 ms

Figure 12. Forward Bias Safe Operating Area

TYPICAL CHARACTERISTICS

Figure 13. Single Pulse Maximum Power Dissipation t, Pulse Width (s)

P(PK), Peak Transient Power (W) 1

10⁻⁴ 300

0.5 10⁻³ 10⁻² 10⁻¹ 1 10 100 1000

10 100

Single Pulse R_qJA = 118C/W TA = 25C

D = 0.5 0.2 0.1 0.05 0.02 0.01

Single Pulse R_qJA = 118C/W Duty Cycle Descending Order

t1

t₂ Notes:

Duty Factor: D = t₁ / t₂

Peak T_J = P_DM  Z_qJA  R_qJA + T_A PDM

10⁻⁴ 10⁻³ 10⁻² 10⁻¹ 1 10 100 1000

0.001 0.01 0.1 1 2

t, Rectangular Pulse Duration (s) ZqJA, Normalized Thermal Impedance

Figure 14. Junction−to−Ambient Transient Thermal Response Curve

POWERTRENCH is a registered trademark of Semiconductor Components Industries, LLC dba “onsemi” or its affiliates and/or subsidiaries in the United States and/or other countries.

SOT−223 CASE 318H

ISSUE B

DATE 13 MAY 2020 SCALE 2:1

1

A = Assembly Location

Y = Year

W = Work Week

XXXXX = Specific Device Code G = Pb−Free Package GENERIC

MARKING DIAGRAM*

AYW XXXXXG

G

(Note: Microdot may be in either location)

*This information is generic. Please refer to device data sheet for actual part marking.

Pb−Free indicator, “G” or microdot “G”, may or may not be present. Some products may not follow the Generic Marking.

98ASH70634A DOCUMENT NUMBER:

DESCRIPTION:

Electronic versions are uncontrolled except when accessed directly from the Document Repository.

Printed versions are uncontrolled except when stamped “CONTROLLED COPY” in red.

PAGE 1 OF 1 SOT−223
