MOSFET - N-Channel, Shielded Gate PowerTrench

Shielded Gate PowerTrench

120 V, 2.95 mW , 181 A

FDP2D9N12C

Features

• Shielded Gate MOSFET Technology

• ^{Max R}

= 2.95 m W at V

= 10 V, I

= 181 A

• 50% Lower Qrr than Other MOSFET Suppliers

• Lowers Switching Noise/EMI

• 100% UIL Tested

• These Devices are Pb−Free, Halogen−Free and are RoHS Compliant

• Synchronous Rectification for ATX / Server / Telecom PSU

• Motor Drives and Uninterruptible Power Supplies

• Micro Solar Inverter

MAXIMUM RATINGS (T_J = 25°C unless otherwise noted)

Parameter Symbol Value Unit

Drain−to−Source Voltage V_DSS 120 V

Gate−to−Source Voltage V_GS ±20 V

Continuous Drain

Current R_qJC (Note 2) Steady

State TC = 25°C

I_D 181 A

Power Dissipation

R_qJC (Note 2) PD 179 W

Continuous Drain Current R_qJA

(Notes 1, 2) Steady

State T_A = 25°C

I_D 19.5 A

Power Dissipation

R_qJA (Notes 1, 2) PD 2.0 W

Pulsed Drain Current T_A = 25°C, tp = 10 ms I_DM 933 A Operating Junction and Storage Temperature

Range T_J, T_stg −55 to

+150 °C

Source Current (Body Diode) IS 172 A

Single Pulse Drain−to−Source Avalanche

Energy (I_AV = 99 A_pk, L = 0.1 mH) EAS 490 mJ Lead Temperature Soldering Reflow for Solder-

ing Purposes (1/8″ from case for 10 s) T_L 300 °C Stresses exceeding those listed in the Maximum Ratings table may damage the device. If any of these limits are exceeded, device functionality should not be assumed, damage may occur and reliability may be affected.

1. Surface−mounted on FR4 board using a 1 in² pad size, 1 oz. Cu pad.

2. The entire application environment impacts the thermal resistance values shown, they are not constants and are only valid for the particular conditions noted.

MARKING DIAGRAM www.onsemi.com

V_(BR)DSS R_DS(ON) MAX I_D MAX 120 V 2.95 mW @ 10 V 181 A

G

S N−CHANNEL MOSFET

D

&Z = Assembly Plant Code

&3 = Date Code (Year & Week)

&K = Lot TO−220 CASE 221A

STYLE 5 12

3 4

&Z&3&K FDP2D9N12C 1

Gate 3

Source 4

Drain

2 Drain

Device Package Shipping^† ORDERING INFORMATION

FDP2D9N12C TO−220

(Pb−Free) 50 / Tube, 800 / Box

†For information on tape and reel specifications, including part orientation and tape sizes, please refer to our Tape and Reel Packaging Specifications Brochure, BRD8011/D.

Junction−to−Case − Steady State (Note 2) R_qJC 0.7 °C/W

Junction−to−Ambient − Steady State (Note 2) R_qJA 62.5

ELECTRICAL CHARACTERISTICS (TJ = 25°C unless otherwise specified)

Parameter Symbol Test Condition Min Typ Max Unit

OFF CHARACTERISTICS

Drain−to−Source Breakdown Voltage V_(BR)DSS V_GS = 0 V, I_D = 250 mA 120 V

Drain−to−Source Breakdown Voltage

Temperature Coefficient V_(BR)DSS/

T_J I_D = 250 mA, ref to 25°C 46 mV/°C

Zero Gate Voltage Drain Current I_DSS V_GS = 0 V,

VDS = 96 V T_J = 25°C 1 mA

T_J = 150°C 100 mA

Gate−to−Source Leakage Current IGSS VDS = 0 V, VGS = ±20 V ±100 nA

ON CHARACTERISTICS (Note 3)

Gate Threshold Voltage VGS(TH) VGS = VDS, ID = 664 mA 2.0 3.1 4.0 V

Negative Threshold Temperature Coefficient VGS(TH)/TJ I_D = 664 mA, ref to 25°C −8.6 mV/°C

Drain−to−Source On Resistance R_DS(on) VGS = 10 V, ID = 95 A 2.7 2.95 mW

VGS = 6 V, ID = 57 A 3.5 5.1 mW

Forward Transconductance gFS VDS = 10 V, ID = 50 A 215 S

CHARGES, CAPACITANCES & GATE RESISTANCE

Input Capacitance CISS

V_GS = 0 V, f = 1 MHz, V_DS = 60 V

7910 12883

Output Capacitance COSS 3825 pF

Reverse Transfer Capacitance C_RSS 32

Gate−Resistance R_G 0.78 1.9 W

Total Gate Charge Q_G(TOT)

V_GS = 10 V, V_DS = 60 V; I_D = 95 A

98 137

Threshold Gate Charge Q_G(TH) 23 nC

Gate−to−Source Charge Q_GS 35

Gate−to−Drain Charge Q_GD 15

Plateau Voltage V_GP 5.0 V

Output Charge Q_OSS V_DD = 60 V, V_GS = 0 V 325 nC

SWITCHING CHARACTERISTICS (Note 4)

Turn−On Delay Time t_d(ON)

VGS = 10 V, VDD = 60 V, I_D = 95 A, R_G = 6.0 W

43

Rise Time t_r 31 ns

Turn−Off Delay Time t_d(OFF) 72

Fall Time t_f 24

DRAIN−SOURCE DIODE CHARACTERISTICS

Forward Diode Voltage V_SD V_GS = 0 V, I_S = 95 A T_J = 25°C 0.9 1.3 V

Reverse Recovery Time t_RR

V_GS = 0 V, V_DD = 60 V dI_S/dt = 300 A/ms, IS = 100 A

88

Charge Time t_a 48 ns

Discharge Time t_b 40

Reverse Recovery Charge Q_RR 500 nC

Product parametric performance is indicated in the Electrical Characteristics for the listed test conditions, unless otherwise noted. Product performance may not be indicated by the Electrical Characteristics if operated under different conditions.

3. Pulse Test: pulse width ≤ 300 ms, duty cycle ≤ 2%.

4. Switching characteristics are independent of operating junction temperatures.

TYPICAL CHARACTERISTICS

7.0 V

Figure 1. On−Region Characteristics Figure 2. Normalized On−Resistance vs. Drain Current and Gate Voltage

V_DS, DRAIN−TO−SOURCE VOLTAGE (V) I_D, DRAIN CURRENT (A)

3 1

00 100 150 250

350 50

00 1 2 3

Figure 3. Normalized On−Resistance vs.

Junction Temperature Figure 4. On−Resistance vs. Gate−to−Source Voltage

T_J, JUNCTION TEMPERATURE (°C) V_GS, GATE−TO−SOURCE VOLTAGE (V) 150

50 0

−25 0.6 −50

0 10 20

Figure 5. Transfer Characteristics Figure 6. Source−to−Drain Diode Forward Voltage vs. Source Current V_GS, GATE−TO−SOURCE VOLTAGE (V) V_SD, BODY DIODE FORWARD VOLTAGE (V)

6 5

4 3

100 250 350

1.2 1.0 0.8

0.6 0.0010

ID, DRAIN CURRENT (A) RDS(on), NORMALIZED DRAIN−TO− SOURCE ON−RESISTANCE

RDS(on), NORMALIZED DRAIN−TO−SOURCE RESISTANCE RDS(on), ON−RESISTANCE (mW)

ID, DRAIN CURRENT (A) IS, REVERSE DRAIN CURRENT (A)

6.0 V

I_D = 100 A V_GS = 10 V

T_J = 25°C

I_D = 100 A

VDS = 5 V

7

5

1.4

0

1

0.2 0.4

T_J = −55°C 100

V_GS = 5.0 V

1.6 2.0

10

2 200 250

4 7

T_J = 150°C

T_J = 25°C 100

50

0.1

−75

5 50

350

200

10 V

5.5 V

25 1.8

150 200

5 10

0.01 1.2

1.0 0.8

100 75

150 4

VGS = 5.0 V

15

8 9

5 4

8 V 5.5 V

7.0 V 8.0 V 6.0 V

10 V

125

TJ = 125°C

6

T_J = −55°C TJ = 150°C

T_J = 25°C

V_GS = 0 V 300

300

300

Figure 7. Gate Charge Characteristics Figure 8. Capacitance vs. Drain−to−Source Voltage

CHARGE (nC) V_DS, DRAIN−TO−SOURCE VOLTAGE (V)

100

40 60

00 2

0.1 10 100K

Figure 9. Unclamped Inductive Switching

Capability Figure 10. Peak Power

t_AV, TIME IN AVALANCHE (mS)

1000 10

0.001

1 100.00001 0.0001 0.001 0.01 0.1 1

Figure 11. Drain Current vs. Case Temperature Figure 12. Forward Bias Safe Operating Area T_C, CASE TEMPERATURE (°C)

100 50

025 100 150 200

1

VGS (V) CAPACITANCE (pF)

IAS, AVALANCHE CURRENT (A) PEAK TRANSIENT POWER (W)

ID, DRAIN CURRENT(A) ID, DRAIN CURRENT (A)

f = 1 MHz V_GS = 0 V

0.1

RDS(on) Limit Thermal Limit Package Limit

10 ms

100 ms/DC 1 ms 10 ms

T_C = 25°C Single Pulse R_qJC = 0.7°C/W 10

100 1000

80 20

1M 1 10 100

1K

1 6

10K

10

50

150 0.1

1

100

100

10 10

100

100 ms 100K

1K

1 0.01 0.1

T_J = 100°C T_J = 125°C

T_J = 25°C

C_ISS

C_OSS

C_RSS 4

8

V_DD = 40 V

V_DD = 80 V

V_DD = 60 V 10K

100

100

75 125

V_GS = 10 V

V_GS = 6 V

R_qJC = 0.7°C/W

TYPICAL CHARACTERISTICS

Figure 13. Transient Thermal Impedance t, RECTANGULAR PULSE DURATION (sec)

0.1 0.0001

0.001 0.01 ZqJA, NORMALIZED THERMAL IMPEDANCE (°C/W)

1 10

1 0.01

0.00001 0.001

0.1

Single Pulse Duty Cycle = 0.5 0.2

0.1 0.05 0.02 0.01

CASE 221A ISSUE AK

DATE 13 JAN 2022

SCALE 1:1

STYLE 1:

PIN 1. BASE 2. COLLECTOR 3. EMITTER 4. COLLECTOR

STYLE 2:

PIN 1. BASE 2. EMITTER 3. COLLECTOR 4. EMITTER

STYLE 3:

PIN 1. CATHODE 2. ANODE 3. GATE 4. ANODE

STYLE 4:

PIN 1. MAIN TERMINAL 1 2. MAIN TERMINAL 2 3. GATE 4. MAIN TERMINAL 2 STYLE 7:

PIN 1. CATHODE 2. ANODE 3. CATHODE 4. ANODE STYLE 10:

PIN 1. GATE 2. SOURCE 3. DRAIN 4. SOURCE STYLE 5:

PIN 1. GATE 2. DRAIN 3. SOURCE 4. DRAIN

STYLE 8:

PIN 1. CATHODE 2. ANODE

3. EXTERNAL TRIP/DELAY 4. ANODE

STYLE 6:

PIN 1. ANODE 2. CATHODE 3. ANODE 4. CATHODE STYLE 9:

PIN 1. GATE 2. COLLECTOR 3. EMITTER 4. COLLECTOR

STYLE 11:

PIN 1. DRAIN 2. SOURCE 3. GATE 4. SOURCE

STYLE 12:

PIN 1. MAIN TERMINAL 1 2. MAIN TERMINAL 2 3. GATE 4. NOT CONNECTED

98ASB42148B DOCUMENT NUMBER:

DESCRIPTION:

Electronic versions are uncontrolled except when accessed directly from the Document Repository.

Printed versions are uncontrolled except when stamped “CONTROLLED COPY” in red.

PAGE 1 OF 1 TO−220
