IGBT
This Insulated Gate Bipolar Transistor (IGBT) features a robust and cost effective Trench construction, and provides superior performance in demanding switching applications, offering both low on state voltage and minimal switching loss.
Features
• Low Saturation Voltage using Trench with Field Stop Technology
• Low Switching Loss Reduces System Power Dissipation
• Soft Fast Reverse Recovery Diode
• Optimized for High Speed Switching
• 5 m s Short−Circuit Capability
• These are Pb−Free Devices
Typical Applications• Solar Inverters
• Uninterruptible Power Supplies (UPS)
ABSOLUTE MAXIMUM RATINGS
Rating Symbol Value Unit
Collector−emitter voltage VCES 600 V
Collector current
@ TC = 25°C
@ TC = 100°C
IC
10050
A
Diode Forward Current
@ TC = 25°C
@ TC = 100°C
IF
10050
A
Diode Pulsed Current
TPULSE Limited by TJ Max IFM 200 A
Pulsed collector current, Tpulse
limited by TJmax
ICM 200 A
Short−circuit withstand time VGE = 15 V, VCE = 300 V, TJ ≤ +150°C
tSC 5 ms
Gate−emitter voltage VGE $20 V
Transient gate−emitter voltage V
(TPULSE = 5 ms, D < 0.10) $30
Power Dissipation
@ TC = 25°C
@ TC = 100°C
PD
22389
W
Operating junction temperature
range TJ −55 to +150 °C
Storage temperature range Tstg −55 to +150 °C Lead temperature for soldering, 1/8”
from case for 5 seconds TSLD 260 °C
Stresses exceeding Maximum Ratings may damage the device. Maximum Ratings are stress ratings only. Functional operation above the Recommended Operating Conditions is not implied. Extended exposure to stresses above the Recommended Operating Conditions may affect device reliability.
TO−247 CASE 340L
STYLE 4 G C
50 A, 600 V V
CEsat= 1.65 V
E
OFF= 0.6 mJ
E
Device Package Shipping ORDERING INFORMATION
NGTB50N60FLWG TO−247
(Pb−Free) 30 Units / Rail http://onsemi.com
A = Assembly Location
Y = Year
WW = Work Week G = Pb−Free Package
MARKING DIAGRAM
50N60FL AYWWG G
E C
THERMAL CHARACTERISTICS
Rating Symbol Value Unit
Thermal resistance junction−to−case, for IGBT RqJC 0.56 °C/W
Thermal resistance junction−to−case, for Diode RqJC 0.74 °C/W
Thermal resistance junction−to−ambient RqJA 40 °C/W
ELECTRICAL CHARACTERISTICS (TJ = 25°C unless otherwise specified)
Parameter Test Conditions Symbol Min Typ Max Unit
STATIC CHARACTERISTIC Collector−emitter breakdown voltage,
gate−emitter short−circuited VGE = 0 V, IC = 500 mA V(BR)CES 600 − − V
Collector−emitter saturation voltage VGE = 15 V, IC = 50 A
VGE = 15 V, IC = 50 A, TJ = 150°C VCEsat 1.40
− 1.65
1.85 1.90
− V
Gate−emitter threshold voltage VGE = VCE, IC = 350 mA VGE(th) 4.5 5.5 6.5 V Collector−emitter cut−off current, gate−
emitter short−circuited VGE = 0 V, VCE = 600 V
VGE = 0 V, VCE = 600 V, TJ = 150°C ICES −
− −
− 0.5
2 mA
Gate leakage current, collector−emitter
short−circuited VGE = 20 V , VCE = 0 V IGES − − 200 nA
DYNAMIC CHARACTERISTIC Input capacitance
VCE = 20 V, VGE = 0 V, f = 1 MHz
Cies − 7500 − pF
Output capacitance Coes − 300 −
Reverse transfer capacitance Cres − 190 −
Gate charge total
VCE = 480 V, IC = 50 A, VGE = 15 V
Qg − 310 − nC
Gate to emitter charge Qge − 60 −
Gate to collector charge Qgc − 150 −
SWITCHING CHARACTERISTIC, INDUCTIVE LOAD Turn−on delay time
TJ = 25°C VCC = 400 V, IC = 50 A
Rg = 10 W VGE = 0 V/ 15 V
td(on) − 116 − ns
Rise time tr − 43 −
Turn−off delay time td(off) − 292 −
Fall time tf − 78 −
Turn−on switching loss Eon − 1.1 − mJ
Turn−off switching loss Eoff − 0.6 −
Total switching loss Ets − 1.7 −
Turn−on delay time
TJ = 150°C VCC = 400 V, IC = 50 A
Rg = 10 W VGE = 0 V/ 15 V
td(on) − 110 − ns
Rise time tr − 45 −
Turn−off delay time td(off) − 300 −
Fall time tf − 105 −
Turn−on switching loss Eon − 1.4 − mJ
Turn−off switching loss Eoff − 1.1 −
Total switching loss Ets − 2.5 −
DIODE CHARACTERISTIC
Forward voltage VGE = 0 V, IF = 50 A
VGE = 0 V, IF = 50 A, TJ = 150°C VF 1.55
− 1.85
1.85 2.1
− V
Reverse recovery time TJ = 25°C
IF = 50 A, VR = 200 V diF/dt = 200 A/ms
trr − 85 − ns
Reverse recovery charge Qrr − 0.40 − mC
Reverse recovery current Irrm − 8 − A
TYPICAL CHARACTERISTICS
250
200
150
100
50
00 1 2 3 4 5 6 7 8
VCE, COLLECTOR−EMITTER VOLTAGE (V) IC, COLLECTOR CURRENT (A)
Figure 1. Output Characteristics
300
0 1 2 3 4 5 6 7 8
VCE, COLLECTOR−EMITTER VOLTAGE (V) IC, COLLECTOR CURRENT (A)
Figure 2. Output Characteristics 250
200 150 100 50 0 VGE = 17 V to 13 V
11 V
10 V
9 V 7 V 8 V
TJ = 25°C TJ = 150°C VGE = 17 V to 13 V
11 V 10 V 9 V 8 V 7 V
250
200
150
100
50
00 1 2 3 4 5 6 7 8
VCE, COLLECTOR−EMITTER VOLTAGE (V) IC, COLLECTOR CURRENT (A)
Figure 3. Output Characteristics TJ = −55°C
VGE = 17 V to 13 V
11 V
10 V
9 V 8 V 7 V
200
0 4 8 12 16
VGE, GATE−EMITTER VOLTAGE (V) IC, COLLECTOR CURRENT (A)
Figure 4. Typical Transfer Characteristics 180
160 140 120 100 80 60 40 20 0
TJ = 25°C TJ = 150°C
3.00
−75 −25 25 75 125 175
TJ, JUNCTION TEMPERATURE (°C) VCE, COLLECTOR−EMITTER VOLTAGE (V)
Figure 5. VCE(sat) vs. TJ 2.50
2.00 1.50 1.00 0.50 0.00
IC = 100 A
IC = 50 A IC = 25 A IC = 5 A
100000
0 10 20 90 100
VCE, COLLECTOR−EMITTER VOLTAGE (V)
CAPACITANCE (pF)
Figure 6. Typical Capacitance 10000
1000
100
10 30 40 50 60 70 80
Cies
Coes
Cres
TYPICAL CHARACTERISTICS
120
0
VF, FORWARD VOLTAGE (V) IF, FORWARD CURRENT (A)
Figure 7. Diode Forward Characteristics 100
80 60 40 20
0 0.5 1 1.5 2 2.5 3 3.5
TJ = 25°C
TJ = 150°C
20
0
QG, GATE CHARGE (nC) VGE, GATE−EMITTER VOLTAGE (V)
Figure 8. Typical Gate Charge
50 100 150 200 250 300 350
15
10
5
0
VCE = 480 V
1.6
0 TJ, JUNCTION TEMPERATURE (°C)
SWITCHING LOSS (mJ)
Figure 9. Switching Loss vs. Temperature
20 40 60 100 120 140 160
1.4 1.2 1 0.8 0.6 0.4 0.2
0 80
Eon
Eoff
VCE = 400 V VGE = 15 V
IC = 50 A Rg = 10 W
VCE = 400 V VGE = 15 V
IC = 50 A Rg = 10 W 1000
0 TJ, JUNCTION TEMPERATURE (°C)
SWITCHING TIME (ns)
Figure 10. Switching Time vs. Temperature
20 40 60 80 100 120 140 160
100
10
1
td(off) td(on)
tf tr
4.5
8
IC, COLLECTOR CURRENT (A)
SWITCHING LOSS (mJ)
Figure 11. Switching Loss vs. IC
20 32 44 56 68 80 92 104
4 3.5 3 2.5 2 1.5 1 0.5 0
VCE = 400 V VGE = 15 V TJ = 150°C
Rg = 10 W Eon
Eoff
8 20 32 44 56 68 80 92 104
1000
IC, COLLECTOR CURRENT (A)
SWITCHING TIME (ns)
Figure 12. Switching Time vs. IC 100
10
1
td(off)
td(on) tf
tr VCE = 400 V
VGE = 15 V TJ = 150°C Rg = 10 W
TYPICAL CHARACTERISTICS
7
5
RG, GATE RESISTOR (W)
SWITCHING LOSS (mJ)
Figure 13. Switching Loss vs. RG
15 25 35 45 55 65 75 85
VCE = 400 V VGE = 15 V
IC = 50 A
TJ = 150°C Eon
Eoff 6
5 4 3 2 1 0
10000
5
RG, GATE RESISTOR (W)
SWITCHING TIME (ns)
Figure 14. Switching Time vs. RG
15 25 35 45 55 65 75 85
1000
100
10
1
td(off) td(on)
tf tr VCE = 400 V
VGE = 15 V IC = 50 A TJ = 150°C
3
175
VCE, COLLECTOR−EMITTER VOLTAGE (V)
SWITCHING LOSS (mJ)
Figure 15. Switching Loss vs. VCE
225 275 325 375 425 475 525 575
2.4 1.8
1.2 0.6
0
Eon
Eoff VGE = 15 V
IC = 50 A Rg = 10 W TJ = 150°C
1000
175
VCE, COLLECTOR−EMITTER VOLTAGE (V)
SWITCHING TIME (ns)
Figure 16. Switching Time vs. VCE
225 275 325 375 425 475 525 575
100
10
1
VGE = 15 V IC = 50 A Rg = 10 W TJ = 150°C
td(off)
td(on)
tf tr
1000
1
VCE, COLLECTOR−EMITTER VOLTAGE (V) IC, COLLECTOR CURRENT (A)
Figure 17. Safe Operating Area
10 100 1000
100 10
1
0.1 0.01
50 ms
100 ms dc operation 1 ms
Single Nonrepetitive Pulse TC = 25°C Curves must be derated linearly with increase in temperature
Figure 18. Reverse Bias Safe Operating Area VCE, COLLECTOR−EMITTER VOLTAGE (V) IC, COLLECTOR CURRENT (A)
1000 100
10 11
10 100 1000
VGE = 15 V, TC = 125°C
TYPICAL CHARACTERISTICS
Figure 19. Collector Current vs. Switching Frequency
0.01 0.1 1 10 100 1000
250
200
150
100
50
0
FREQUENCY (kHz)
Ipk (A)
80°C
110°C 80°C
110°C
VCE = 400 V, TJ ≤ 150°C Rgate = 10 W, VGE = 0/15 V,
Tcase = 80 or 110°C (as noted), D = 0.5
50% Duty Cycle 20%
10%
5%
2%
1%
Single Pulse
RqJC = 0.56
Junction Case
C1 C2
R1 R2 Rn
Ci = ti/Ri
Duty Factor = t1/t2 Peak TJ = PDM x ZqJC + TC
Cn
ti (sec) 1.0E−4 5.48E−5 0.002
0.03 0.1 Ri (°C/W) 0.02087 0.05041 0.07919 0.11425 0.19393
Figure 20. IGBT Transient Thermal Impedance
R(t) (°C/W)
Figure 21. Diode Transient Thermal Impedance PULSE TIME (sec)
R(t) (°C/W)
PULSE TIME (sec)
50% Duty Cycle 20%
10%
5%
2%
1%
Single Pulse
RqJC = 0.74
Junction
C1 C2
R1 R2
Ci = ti/Ri
Duty Factor = t1/t2 Peak TJ = PDM x ZqJC + TC
Case
Cn
Rn
0.001 0.01 0.1 1
0.000001 0.00001 0.0001 0.001 0.01 0.1 1 10 100 1000
2.0 0.09951
0.001 0.01 0.1 1
0.000001 0.00001 0.0001 0.001 0.01 0.1 1 10 100 1000
ti (sec) 4.89E−4
0.002 0.03
0.1 2.0 Ri (°C/W) 0.07958 0.13798 0.18744 0.23523 0.09951
Figure 22. Test Circuit for Switching Characteristics
Figure 23. Definition of Turn On Waveform
Figure 24. Definition of Turn Off Waveform
TO−247 CASE 340L
ISSUE G
DATE 06 OCT 2021
GENERIC MARKING DIAGRAM*
XXXXX = Specific Device Code A = Assembly Location
Y = Year
WW = Work Week G = Pb−Free Package
STYLE 3:
PIN 1. BASE 2. COLLECTOR 3. EMITTER 4. COLLECTOR
SCALE 1:1
STYLE 1:
PIN 1. GATE 2. DRAIN 3. SOURCE 4. DRAIN
STYLE 2:
PIN 1. ANODE 2. CATHODE (S) 3. ANODE 2 4. CATHODES (S)
STYLE 4:
PIN 1. GATE 2. COLLECTOR 3. EMITTER 4. COLLECTOR
XXXXXXXXX AYWWG
STYLE 6:
PIN 1. MAIN TERMINAL 1 2. MAIN TERMINAL 2 3. GATE 4. MAIN TERMINAL 2 STYLE 5:
PIN 1. CATHODE 2. ANODE 3. GATE 4. ANODE
*This information is generic. Please refer to device data sheet for actual part marking.
Pb−Free indicator, “G” or microdot “G”, may or may not be present. Some products may not follow the Generic Marking.
98ASB15080C DOCUMENT NUMBER:
DESCRIPTION:
Electronic versions are uncontrolled except when accessed directly from the Document Repository.
Printed versions are uncontrolled except when stamped “CONTROLLED COPY” in red.
PAGE 1 OF 1 TO−247
