NTD5865NL MOSFET – Power, N-Channel

MOSFET – Power, N-Channel

60 V, 46 A, 16 mW

Features

• Low Gate Charge

• Fast Switching

• High Current Capability

• 100% Avalanche Tested

• These Devices are Pb−Free, Halogen Free and are RoHS Compliant

Parameter Symbol Value Unit

Drain−to−Source Voltage V_DSS 60 V

Gate−to−Source Voltage − Continuous V_GS ±20 V Gate−to−Source Voltage

− Non−Repetitive (t_p < 10 ms) V_GS ±30 V Continuous Drain

Current (R_qJC) Steady State

TC = 25°C I_D 46 A

T_C = 100°C 33

Power Dissipation

(R_qJC) TC = 25°C PD 71 W

Pulsed Drain Current t_p = 10 ms I_DM 203 A Operating Junction and Storage Temperature T_J, T_stg −55 to

175 °C

Source Current (Body Diode) I_S 46 A

Single Pulse Drain−to−Source

Avalanche Energy (L =

0.1 mH) E_AS 36 mJ

I_AS 27 A

Lead Temperature for Soldering Purposes

(1/8″ from case for 10 s) TL 260 °C

Stresses exceeding those listed in the Maximum Ratings table may damage the device. If any of these limits are exceeded, device functionality should not be assumed, damage may occur and reliability may be affected.

THERMAL RESISTANCE MAXIMUM RATINGS

Parameter Symbol Value Unit

Junction−to−Case (Drain) R_qJC 2.1 °C/W

Junction−to−Ambient − Steady State (Note 1) R_qJA 49 1. Surface−mounted on FR4 board using a 650 mm², 2 oz. Cu pad.

DPAK CASE 369AA (Surface Mount)

STYLE 2

MARKING DIAGRAMS

& PIN ASSIGNMENT 60 V

R_DS(on) MAX I_D MAX V_(BR)DSS

16 mW @ 10 V http://onsemi.com

Gate1 Drain 32

Source Drain4

AYWW 58 65NLG

A = Assembly Location*

Y = Year

WW = Work Week 5865NL = Device Code

G

S

N−Channel D

IPAK CASE 369D (Straight Lead)

STYLE 2 123

4

Drain4

Drain2 Gate1 3

Source

AYWW 58 65NLG

46 A

1 2 3 4

19 mW @ 4.5 V

OFF CHARACTERISTICS

Drain−to−Source Breakdown Voltage V_(BR)DSS V_GS = 0 V, I_D = 250 mA 60 V

Drain−to−Source Breakdown Voltage

Temperature Coefficient V(BR)DSS/TJ 55 mV/°C

Zero Gate Voltage Drain Current I_DSS V_GS = 0 V, VDS = 60 V

T_J = 25°C 1.0 mA

T_J = 150°C 100

Gate−to−Source Leakage Current IGSS VDS = 0 V, VGS = ±20 V ±100 nA

ON CHARACTERISTICS (Note 2)

Gate Threshold Voltage V_GS(TH) V_GS = V_DS, I_D = 250 mA 1.0 2.0 V

Negative Threshold Temperature Co-

efficient V_GS(TH)/T_J 5.6 mV/°C

Drain−to−Source on Resistance R_DS(on) V_GS = 10 V, I_D = 20 A 13 16 mW

Drain−to−Source on Resistance R_DS(on) V_GS = 4.5 V, I_D = 20 A 16 19 mW

Forward Transconductance gFS VDS = 15 V, ID = 20 A 15 S

CHARGES, CAPACITANCES AND GATE RESISTANCES

Input Capacitance C_iss

V_GS = 0 V, f = 1.0 MHz, V_DS = 25 V

1400 pF

Output Capacitance C_oss 137

Reverse Transfer Capacitance C_rss 95

Total Gate Charge Q_G(TOT)

VGS = 10 V, VDS = 48 V, I_D = 40 A

29 nC

Threshold Gate Charge QG(TH) 1.1

Gate−to−Source Charge QGS 4

Gate−to−Drain Charge Q_GD 8

Total Gate Charge Q_G(TOT) V_GS = 4.5 V, V_DS = 48 V,

I_D = 40 A 15 nC

Gate Resistance R_G 1.3 W

SWITCHING CHARACTERISTICS (Note 3)

Turn−On Delay Time t_d(on)

V_GS = 10 V, V_DD = 48 V, ID = 40 A, RG = 2.5 W

8.4 ns

Rise Time t_r 12.4

Turn−Off Delay Time t_d(off) 26

Fall Time tf 4.4

DRAIN−SOURCE DIODE CHARACTERISTICS

Forward Diode Voltage V_SD V_GS = 0 V,

I_S = 40 A

TJ = 25°C 0.95 1.2 V

T_J = 125°C 0.85

Reverse Recovery Time t_RR

V_GS = 0 V, dIs/dt = 100 A/ms, IS = 40 A

20 ns

Charge Time ta 13

Discharge Time tb 7

Reverse Recovery Charge QRR 13 nC

Product parametric performance is indicated in the Electrical Characteristics for the listed test conditions, unless otherwise noted. Product performance may not be indicated by the Electrical Characteristics if operated under different conditions.

2. Pulse Test: Pulse Width ≤ 300 ms, Duty Cycle ≤ 2%.

3. Switching characteristics are independent of operating junction temperatures.

TYPICAL CHARACTERISTICS

0 10 20 30 40 50 60 70 80

0 1 2 3 4 5

Figure 1. On−Region Characteristics VDS, DRAIN−TO−SOURCE VOLTAGE (V) ID, DRAIN CURRENT (A)

V_GS = 10 V

T_J = 25°C 4.5 V

4 V 3.8 V

3.6 V 3.4 V 3.2 V 3 V 2.8 V

2.6 V 0

10 20 30 40 50 60 70 80

1 2 3 4 5

V_DS ≥ 10 V

T_J = −55°C TJ = 125°C

Figure 2. Transfer Characteristics VGS, GATE−TO−SOURCE VOLTAGE (V) ID, DRAIN CURRENT (A)

T_J = 25°C

0.010 0.015 0.020 0.025 0.030

2 3 4 5 6 7 8 9 10

Figure 3. On−Resistance vs. Gate Voltage V_GS, GATE−TO−SOURCE VOLTAGE (V) RDS(on), DRAIN−TO−SOURCE RESISTANCE (W)

T_J = 25°C ID = 40 A

0.010 0.012 0.014 0.016 0.018

5 10 15 20 25 30 35 40

Figure 4. On−Resistance vs. Drain Current I_D, DRAIN CURRENT (A)

RDS(on), DRAIN−TO−SOURCE RESISTANCE (W)

V_GS = 10 V T_J = 25°C

VGS = 4.5 V

SOURCE RESISTANCE (NORMALIZED)

1000 10000

IDSS, LEAKAGE (nA)

TJ = 125°C T_J = 150°C VGS = 0 V

1.0 1.2 1.4 1.6 1.8

2.0 V_GS = 10 V I_D = 38 A 2.2

0 200 400 600 800 1000 1200 1400 1600

0 10 20 30 40 50 60

Figure 7. Capacitance Variation V_DS, DRAIN−TO−SOURCE VOLTAGE (V)

C, CAPACITANCE (pF)

T_J = 25°C V_GS = 0 V Ciss

C_oss C_rss

0 2 4 6 8

0 5 10 15 20 25 30

Qgs

Q_T

Qgd

Figure 8. Gate−to−Source vs. Total Charge Q_g, TOTAL GATE CHARGE (nC) VGS, GATE−TO−SOURCE VOLTAGE (V)

V_DS = 48 V I_D = 40 A T_J = 25°C

1 10 100 1000

1 10 100

Figure 9. Resistive Switching Time Variation vs. Gate Resistance

R_G, GATE RESISTANCE (W)

t, TIME (ns)

V_DD = 48 V I_D = 40 A V_GS = 10 V

td(off)

td(on)

t_r t_f

0 5 10 15 20 25 30 35 40

0.50 0.55 0.60 0.65 0.70 0.75 0.80 0.85 0.90 0.95 1.00 Figure 10. Diode Forward Voltage vs. Current

VSD, SOURCE−TO−DRAIN VOLTAGE (V) IS, SOURCE CURRENT (A)

T_J = 25°C V_GS = 0 V

0.1 1 10 100 1000

0.1 1 10 100

V_DS, DRAIN−TO−SOURCE VOLTAGE (V) ID, DRAIN CURRENT (A)

Figure 11. Maximum Rated Forward Biased Safe Operating Area

10 ms 100 ms

1 ms

dc 10 ms

R_DS(on) LIMIT THERMAL LIMIT PACKAGE LIMIT V_GS = 10 V

SINGLE PULSE T_C = 25°C

TYPICAL CHARACTERISTICS

0.01 0.1 1 10

0.000001 0.00001 0.0001 0.001 0.01 0.1 1

Figure 12. Thermal Response t, PULSE TIME (s) RqJC(t) (°C/W) EFFECTIVE TRANSIENT THERMAL RESISTANCE

0.02 0.2

0.01 0.05

Duty Cycle = 0.5

SINGLE PULSE 0.1

ORDERING INFORMATION

Order Number Package Shipping^†

NTD5865NL−1G IPAK (Straight Lead)

(Pb−Free) 75 Units / Rail

NTD5865NLT4G DPAK

(Pb−Free) 2500 / Tape & Reel

†For information on tape and reel specifications, including part orientation and tape sizes, please refer to our Tape and Reel Packaging Specifications Brochure, BRD8011/D.

SCALE 1:1

STYLE 1:

PIN 1. BASE 2. COLLECTOR 3. EMITTER 4. COLLECTOR

STYLE 2:

PIN 1. GATE 2. DRAIN 3. SOURCE 4. DRAIN

STYLE 3:

PIN 1. ANODE 2. CATHODE 3. ANODE 4. CATHODE

STYLE 4:

PIN 1. CATHODE 2. ANODE 3. GATE 4. ANODE STYLE 5:

PIN 1. GATE 2. ANODE 3. CATHODE 4. ANODE

1 2 3

4

V

S A

K

−T−

SEATING PLANE

R B

F

G

D3 PL

0.13 (0.005)M T C

E

J

H

DIM MIN MAX MIN MAX MILLIMETERS INCHES

A 0.235 0.245 5.97 6.35 B 0.250 0.265 6.35 6.73 C 0.086 0.094 2.19 2.38 D 0.027 0.035 0.69 0.88 E 0.018 0.023 0.46 0.58 F 0.037 0.045 0.94 1.14

G 0.090 BSC 2.29 BSC

H 0.034 0.040 0.87 1.01 J 0.018 0.023 0.46 0.58 K 0.350 0.380 8.89 9.65 R 0.180 0.215 4.45 5.45 S 0.025 0.040 0.63 1.01 V 0.035 0.050 0.89 1.27

STYLE 6:

PIN 1. MT1 2. MT2 3. GATE 4. MT2

NOTES:

1. DIMENSIONING AND TOLERANCING PER ANSI Y14.5M, 1982.

2. CONTROLLING DIMENSION: INCH.

Z

Z 0.155 −−− 3.93 −−−

STYLE 7:

PIN 1. GATE 2. COLLECTOR 3. EMITTER 4. COLLECTOR

xxxxxxxxx = Device Code A = Assembly Location lL = Wafer Lot

Y = Year

WW = Work Week YWW

xxxxxxxx

xxxxx ALYWW

x Discrete

Integrated Circuits ISSUE C

DATE 15 DEC 2010

MARKING DIAGRAMS

ON Semiconductor and are trademarks of Semiconductor Components Industries, LLC dba ON Semiconductor or its subsidiaries in the United States and/or other countries.

98AON10528D DOCUMENT NUMBER:

DESCRIPTION:

Electronic versions are uncontrolled except when accessed directly from the Document Repository.

Printed versions are uncontrolled except when stamped “CONTROLLED COPY” in red.

PAGE 1 OF 1 IPAK (DPAK INSERTION MOUNT)

DPAK (SINGLE GUAGE) CASE 369AA−01

ISSUE B

DATE 03 JUN 2010 SCALE 1:1

STYLE 1:

PIN 1. BASE 2. COLLECTOR 3. EMITTER 4. COLLECTOR

STYLE 2:

PIN 1. GATE 2. DRAIN 3. SOURCE 4. DRAIN

STYLE 3:

PIN 1. ANODE 2. CATHODE 3. ANODE 4. CATHODE

STYLE 4:

PIN 1. CATHODE 2. ANODE 3. GATE 4. ANODE STYLE 5:

PIN 1. GATE 2. ANODE 3. CATHODE 4. ANODE

b D E

b3

L3

L4b2

e 0.005 (0.13) ^M C

c2 A

c

C

Z

DIM MININCHESMAX MILLIMETERSMIN MAX

D 0.235 0.245 5.97 6.22 E 0.250 0.265 6.35 6.73 A 0.086 0.094 2.18 2.38 b 0.025 0.035 0.63 0.89

c2 0.018 0.024 0.46 0.61 b2 0.030 0.045 0.76 1.14 c 0.018 0.024 0.46 0.61

e 0.090 BSC 2.29 BSC b3 0.180 0.215 4.57 5.46

L4 −−− 0.040 −−− 1.01 L 0.055 0.070 1.40 1.78

L3 0.035 0.050 0.89 1.27

Z 0.155 −−− 3.93 −−−

NOTES:

1. DIMENSIONING AND TOLERANCING PER ASME Y14.5M, 1994.

2. CONTROLLING DIMENSION: INCHES.

3. THERMAL PAD CONTOUR OPTIONAL WITHIN DI- MENSIONS b3, L3 and Z.

4. DIMENSIONS D AND E DO NOT INCLUDE MOLD FLASH, PROTRUSIONS, OR BURRS. MOLD FLASH, PROTRUSIONS, OR GATE BURRS SHALL NOT EXCEED 0.006 INCHES PER SIDE.

5. DIMENSIONS D AND E ARE DETERMINED AT THE OUTERMOST EXTREMES OF THE PLASTIC BODY.

6. DATUMS A AND B ARE DETERMINED AT DATUM PLANE H.

1 2 3

4

STYLE 6:

PIN 1. MT1 2. MT2 3. GATE 4. MT2

STYLE 7:

PIN 1. GATE 2. COLLECTOR 3. EMITTER 4. COLLECTOR

XXXXXX = Device Code A = Assembly Location

L = Wafer Lot

Y = Year

WW = Work Week

G = Pb−Free Package YWW XXX XXXXXG XXXXXXG

ALYWW

Discrete IC

1 2 3 4

5.80 0.228

2.58 0.102

1.60 0.063 6.20

0.244

3.00 0.118

6.17 0.243

ǒ

Ǔ

SCALE 3:1

GENERIC MARKING DIAGRAM*

*This information is generic. Please refer to device data sheet for actual part marking.

*For additional information on our Pb−Free strategy and soldering details, please download the ON Semiconductor Soldering and Mounting Techniques Reference Manual, SOLDERRM/D.

SOLDERING FOOTPRINT*

H 0.370 0.410 9.40 10.41 A1 0.000 0.005 0.00 0.13

L1 0.108 REF 2.74 REF L2 0.020 BSC 0.51 BSC

A1

DETAIL A H

SEATING PLANE

A

B

C

L1 L

H L2 ^GAUGE_PLANE

DETAIL A

ROTATED 90 CW5
