2 章 波について

海岸構造物の設計・漂砂の計算・海岸地形変化に必要な波情報

波角、 周期、 波高、 底面流速

波計算に用いる座標系と諸量

2.2 二次元の波浪変形

海岸の砂丘−海浜形状を模式的に描くと図

2-2 に示すようになる。

図―* 岸沖縦断面形状

波の浅水変形

巻き波砕波の様子

図-* 波浪変形の概念図

波浪理論の参考文献（CEM）

表-1 岸-沖表砂量モデルの分類

(1)波の変形計算

波浪変形の基礎式は、(2.1)に示す Dally 型のものである。

∂

∂

θ

∂

∂

θ

κ

x

(

F

c o s

)

+

y

(

F

s i n

)

=

d

(

F

−

F

s

)

（2.1）

ここで、計算で用いる座標系は図

2-7 に示す通りであり、

F＝波のエネルギ−フラックス

F

ｓ

＝安定波のエネルギ−フラックス（Stable wave energy flux）

κ＝波の減衰係数

d＝全水深である。

また、安定波のエネルギ−フラックス

F

ｓ

は(2.2)式により求められる。

F

_s

=

E

_s

C

_gs

=

1

8

ρgH

s 2

gh

=

1

8

ρg(

Γ

h )

2

gh

（2.2）

ここで、Γは安定状態における波高と局所水深の比である。加えて、平均水深

η

は、(2.3)式

より求める。

d S

d x

g d

d

d x

x x

= −

ρ

η

_（2.3）

この平均水位

η

の計算に関しては、直接解を求める方法が

Dally 等により示されており、こ

このプログラミングでもこの方法を用いた。また、プログラミングでは、直角入射のみを

対象とし、(2.1)式でθ= 0 としたものを用いる。

(2)波浪変形領域の分類

二次元の波浪変形計算領域を図

2-8 に示すように 4 つの領域 (I)前砕波帯（Prebreaking

zone), (II)砕波遷移帯 (Breaker transition zone), (III)砕波帯 (Broken wave zone), (IV)遡

上帯(swash zone)に分ける。砕波遷移帯の長さは、経験的に砕波波高の 3 倍が用いられ、そ

して、遡上限界については、

Surf similarity parameter の関数である(2.4)式が採用される。

Z

r

H

₀

=

1 . 47 [

tan

β

H

0

L

0

]

0 . 79

（2.4）

ここで、

Zｒ＝遡上高さ

tanβ＝砕波点の沖側の海底勾配

H

０

／L

０

＝深海波の波形勾配である。

2 . 3 数値計算プログラムの使用法

C --- C C Table of valiables C DS ---- BEACH PROFILE

C DA ---- TOTAL DEPTH WITH SET-DOWN AND SET-UP

C AVDS ---- AVERAGE BEACH TOPOGRAPHY FOR WAVE DECAY MODEL (3-POINTS) C ETABAR -- MEAN WATER LEVEL

C H ---- WAVE HEIGHT C SLP ---- LOCAL SLOPE

C TANB --- AVERAGE BEACH SLOPE C wkappa --- SHOALING COEFFICIENT c r ---- BREAKER RATIO

C ROU ---- DENSITY OF WATER (100 kg/m^3) C EFLUX --- ENERGY FLUX

C DHSQ --- DH^2/DX^2

C HB --- BREAKING WAVE HEIGHT C

--- C DIMMENSION DEFINITION

C

DIMENSION DS(200), DA(200), AVDS(200), H(200), ETABAR(200) DIMENSION SLP(200), FL(200), HB(200), HBF(200), HAV(200) REAL LAG, K(200), DH(200)

CHARACTER*18 DNAME$ C

WRITE (*,'(A)') ' CONSTANT '

CALL CONST(T,H0,F,ROU,G,DX,DT,WKAPPA,GAMMA,DLAG,LAG,SBF,WL) C

MM = 0 NX = 200 NN = 0 IBPNUM = 0 C ====================================================== REAL LAG C CONSTANT

C WAVE PERIOD (SEC) T = 6.0 C WAVE HEIGHT (m) H0 = 2.3 C FRICTION COEFFICIENT F F = 0.03 C DENSITY OF WATER (kg/m^3) ROU = 1000.0

C GRAVITY ACCELALATION G(m/sec^2) G = 9.8

C GRID SIZE IN X-DIRECTION (ONSHORE IS POSITIVE) (m) DX = 1.0

C COEFFICIENT OF WAVE DECAY MODEL WKAPPA = 0.15 GAMMA = 0.40 C OTHER COEFFICIENT DLAG = 1.5 LAG = 0.0 SBF = 0.1 WL = 1.56* (T**2.) C

C INITIAL BEACH PROFILE

200 WRITE (*,'(A)') ' INITIAL BEACH PROFILE ' C AVERAGE BEACH SLOPE TANB

TANB =10.0 / 100. XM = 10.0 / 100. DD = XM * DX DO 210 I=1, 200 DS(I) = 6.0 - (FLOAT(I-1)*DD) 210 CONTINUE C

C WAVE DECAY MODEL IBP(1) = 0

IBP(2) = 0

C --- CONVERT TO ENGLISH SYSTEM --- DX = DX / 0.3048 H0 = H0 / 0.3048 WL = WL / 0.3048 DD = DD / 0.3048 G = G / 0.3048 DO 302 I=1,200 DS(I) = DS(I) / 0.3048 302 CONTINUE C ---

C AVERAGE DEPTH FOR WAVE DECAY MODEL AVDS(1) = (DS(1)+DS(2)) / 2. AVDS(200) = (DS(199)+DS(200))/2.0 DO 303 I=2,199 AVDS(I) = (DS(I+1)+DS(I))/2. 303 CONTINUE DO 305 I=2,NX-1 SLP(I) = (AVDS(I-1)-AVDS(I+1))/(2.*DX) 305 CONTINUE SLP(1) = SLP(2) SLP(NX) = SLP(NX-1) DO 307 I=1,200 K(I) = 0.17 307 CONTINUE

C WAVE HEIGHT AND SET-DOWN AT OFFSHORE BOUNDARY GRID H(1) = H0*SQRT(SQRT(G/AVDS(1))*T/(4.*3.1415)) ETABAR(1) = -(((H(1)*0.5)**2.)/(4.*AVDS(1))) DA(1) = AVDS(1) + ETABAR(1)

IB = 0 IBPNUM = 0 J = 0 IBP(1)=0 IBP(2) = 0 NX = 0 DIF = 0 C

C --- BREAKING WAVE DECAY MODEL C

C WRITE (*,'(A)') ' BREAKING WAVE MODEL ' BREAK = 0.5 I = 0 310 I = I +1 IF (BREAK.LE.1.0) GO TO 311 C WAVE BREAKING AP = EXP(-K(I)*DX/DA(I)) BP = 0.16*(DA(I)**2.) CHECK = (H(I)**2.) - BP IF (CHECK.LT.0.0) GO TO 311 HB(I) = SQRT((AP*CHECK)+BP) GO TO 312 C NON-BREAKING 311 HB(I)=H(I) BREAK = 0.5 312 CONTINUE HAV(I) = (H(I)+HB(I))/2. HBF1 = (HB(I)**2.)-(2.*0.03*(HAV(I)**3.)*DX/((DA(I)**2.) 1 *9.425)) IF (HBF1.LE.0.0) GO TO 320 HBF(I) = SQRT((HB(I)**2.)-(2.*0.03*(HAV(I)**3.)*DX/((DA(I)**2. 1 )*9.425))) CK = DA(I)/(AVDS(I+1)+ETABAR(I)) IF (CK.GE.0.0) GO TO 314 GO TO 320 314 CONTINUE H(I+1) = HBF(I)*((DA(I)/(AVDS(I+1)+ETABAR(I)))**0.25) ETABAR(I+1)=(((H(I)**2.)-(H(I+1)**2.))/(4.57*DA(I)))+ETABAR(I) DA(I+1)=AVDS(I+1)+ETABAR(I+1) IF (DA(I+1).LT.0.1) GO TO 320 IF (BREAK.LE.1.0) GO TO 316 GO TO 310 316 IF (H(I+1).LT.(1.3*DA(I+1))) GO TO 310 BREAK = 5.0 IF (IB.NE.0) GO TO 318 IB = I +1 J=J+1 IBP(J) = IB 318 GO TO 310 320 CONTINUE NX = I IBPNUM = J

C --- WAVE HEIGHT CALC. END --- C --- CONVERT TO METRIC SYSTEM --- DX = DX * 0.3048 H0 = H0 * 0.3048 WL = WL * 0.3048 DD = DD * 0.3048 G = G * 0.3048 DO 325 I=NX+1, 200 H(I) = 0.0

ETABAR(I) = 0.0 DA(I) = 0.0 325 CONTINUE DO 330 I=1,200 DS(I) = DS(I) * 0.3048 H(I) = H(I) * 0.3048 ETABAR(I) = ETABAR(I) * 0.3048 DA(I) = DA(I) * 0.3048 330 CONTINUE

C WRITE (*,*) (H(I), I=1,200) C DATA DISPLAY

WRITE (*,'(A)') ' BREAK POINT ' WRITE (*,*) IBP(1), IBP(2) WRITE (*,'(A)') ' '

WRITE (*,'(A)') ' WAVE HEIGHT ' WRITE (*,*) (H(I),I=1,200)

WRITE (*,'(A)') ' BEACH PROFILE ' WRITE (*,*) (DS(I), I=1,200)

C --- DATA SAVE --- C

C ---- DATA FILE NAME ---

DATA1$ = '¥nishi¥WH' // '.DAT' DATA2$ = '¥nishi¥DS' // '.DAT' DATA3$ = '¥DATA¥ET' // ITE$ '.DAT' C ---- DATA SAVE ----

OPEN (7,FILE = DATA1$) DO 782 I=40,150

IJ = 151- I

WRITE (7,*) IJ, H(I) 782 CONTINUE

CLOSE (7, STATUS='KEEP') OPEN (8,FILE = DATA2$) DO 784 I=40, 150

IJ = 151- I

WRITE (8,*) IJ, -DS(I) 784 CONTINUE

CLOSE (8, STATUS='KEEP') OPEN (9, FILE = DATA3$) DO 786 I=40,150

IJ = 151 -I

WRITE (9,*) IJ, ETA(I) 786 CONTINUE

CLOSE (9, STATUS = 'KEEP') C
