Hyperfast Diode 50 A, 600 V

50 A, 600 V

RHRG5060

Description

The RHRG5060 is a hyperfast diode with soft recovery characteristics. It has the half recovery time of ultrafast diodes and is silicon nitride passivated ionimplanted epitaxial planar c o n s t r u c t i o n . T h e s e d e v i c e s a r e i n t e n d e d t o b e u s e d as freewheeling/ clamping diodes and diodes in a variety of switching power supplies and other power switching applications. Their low stored charge and hyperfast soft recovery minimize ringing and electrical noise in many power switching circuits reducing power loss in the switching transistors.

Features

• Hyperfast Recovery ( t rr = 50 ns (@ I F = 50 A )

• Max Forward Voltage( V _F = 2.1 V (@ T _C = 25 ° C )

• 600 V Reverse Voltage and High Reliability

• Avalanche Energy Rated

• This Device is Pb−Free and is RoHS Compliant Applications

• Switching Power Supplies

• Power Switching Circuits

• General Purpose

ABSOLUTE MAXIMUM RATINGS (T

= 25°C unless otherwise noted)

Rating Symbol Value Unit

Peak Repetitive Reverse Voltage V

600 V

Working Peak Reverse Voltage V

600 V

DC Blocking Voltage V

600 V

Average Rectified Forward Current

(T

= 93 °C) I

50 A

Repetitive Peak Surge Current

(Square Wave, 20 kHz) I

100 A

Nonrepetitive Peak Surge Current

(Halfwave 1 Phase, 60 Hz) I

500 A

Maximum Power Dissipation P

150 W

Avalanche Energy

(See Figure 10 and Figure 11) E

40 mJ

Operating and Storage Temperature T

T

−65 to

+175 °C

Stresses exceeding those listed in the Maximum Ratings table may damage the

www.onsemi.com

JEDEC STYLE TO−247

340CL

MARKING DIAGRAM

$Y&Z&3&K RHRG5060

See detailed ordering and shipping information on page 2 of

ORDERING INFORMATION CATHODE

ANODE

$Y = ON Semiconductor Logo

&Z = Assembly Plant Code

&3 = Numeric Date Code

&K = Lot Code

RHRG5060 = Specific Device Code

1. Cathode 2. Anode

RHRG5060

www.onsemi.com 2

PACKAGE MARKING AND ORDERING INFORMATION

Part Number Package Brand

RHRG5060 TO−247−2L RHRG5060

ELECTRICAL CHARACTERISTICS (T

= 25°C unless otherwise noted)

Symbol Parameter Test Conditions Min Typ Max Unit

V

Instantaneous Forward Voltage

(Pulse Width = 300 ms, Duty Cycle = 2%) I

= 50 A 2.1 V

I

= 50 A,

T

= 150°C 1.7 V

I

Instantaneous Reverse Current V

= 600 V 250 m A

V

= 600 V

T

= 150°C 1.5 mA

t

Reverse Recovery Time (See Figure 9 )

Summation of t

+ t

I

= 1 A,

dl

/dt = 100 A/ms 45 ns

I

= 50 A,

dI

/dt = 100 A/ms 50 ns

t

Time to Reach Peak Reverse Current (See Figure 9) I

= 50 A,

dI

/dt = 100 A/ms 25 ns

t

Time from Peak I

to Projected Zero Crossing of I

Based on a Straight Line from Peak I

Through 25%

of I

(See Figure 9)

I

= 50 A,

dI

/dt = 100 A/ms 20 ns

Q

Reverse Recovery Charge I

= 50 A,

dI

/dt = 100 A/ms 65 nC

C

Junction Capacitance V

= 10 V,

I

= 0 A 140 pF

R

Thermal Resistance Junction to Case 1.0 ° C/W

Product parametric performance is indicated in the Electrical Characteristics for the listed test conditions, unless otherwise noted. Product

performance may not be indicated by the Electrical Characteristics if operated under different conditions.

TYPICAL PERFORMANCE CURVES

Figure 1. Forward Current vs. Forward Voltage Figure 2. Reverse Current vs. Reverse Voltage

Figure 3. T

, t

and t

Curves vs. Forward Current Figure 4. T

, t

and t

Curves vs. Forward Current I

, Reverse Current ( m A)

V

, Reverse Voltage (V) I

, Forward Current (A)

V

, Forward Voltage (V)

t, Recovery T ime (ns)

I

, Forward Current (A)

t, Recovery T imes (ns)

I

, Forward Current (A)

imes (ns)

1 300

10

0 0.5 12 1.5 2.5 3

25^oC 175^oC 100^oC 100

0 200 300 400 600

100

0.01 0.1 1 10 1000

100 500

100^oC 175^oC

25^oC 3000

ta Trr

tb

01 100 150

125

50 75

50

10 25

T_C = 100^oC, dI_F/dt = 100A/ms

50

10 20 30 40

SQ. WAVE DC

ta

Trr 250

150

100

50 tb

200

TC = 175^oC, dIF/dt = 100A/ms 01

40 60

50

50 Trr

tb

30 ta

20

10 10

T_C = 25^oC, dI_F/dt = 100A/ms

RHRG5060

www.onsemi.com 4

TYPICAL PERFORMANCE CURVES (continued)

Figure 7. Junction Capacitance vs. Reverse Voltage C

, Junction Capacitance (pF)

V

, Reverse Voltage (V)

100

0 300

0 50 100 150 200

350

250

50 150

TEST CIRCUITS AND WAVEFORMS

Figure 8. T

Test Circuit Figure 9. T

Waveforms and Definitions

Figure 10. Avalanche Energy Test Circuit Figure 11. Avalanche Current and Voltage Waveforms I = 1 A

L = 40 mH R < 0.1 W

E

= 1/2LI

[V

/(V

−V

)]

Q

= IGBT (BV

> DUT V

)

I_RM R_G

L

V_DD IGBT

CURRENT SENSE DUT

GE t₁

t₂

+

−

dt dI_F

I_F Trr

ta tb

0

0.25IRM

DUT CURRENT

SENSE

+

L R

VDD

−

V_DD

Q1 I

t₀ t₁ t₂

I_L V_AVL

t I_L

V

AMPLITUDE AND R

CONTROL dl

/dt t

AND t

CONTROL I

V

V

XXXX = Specific Device Code A = Assembly Location Y = Year

WW = Work Week ZZ = Assembly Lot Code

*This information is generic. Please refer to device data sheet for actual part marking.

Pb−Free indicator, “G” or microdot “G”, may GENERIC

MARKING DIAGRAM*

AYWWZZ XXXXXXX XXXXXXX

TO−247−2LD CASE 340CL
