PNP Low Saturation Transistor

FZT790A

Description

These devices are designed with high current gain and low saturation voltage with collector currents up to 3 A continuous.

Features

• These Devices are Pb−Free, Halogen Free/BFR Free and are RoHS Compliant

ABSOLUTE MAXIMUM RATINGS (Notes 1, 2) (Values are at T

= 25 ° C unless otherwise noted)

Parameter Symbol Value Unit

Collector−Emitter Voltage V

−40 V

Collector−Base Voltage V

−50 V

Emitter−Base Voltage V

−5 V

Collector Current − Continuous I

−3 A

Operating and Storage Junction Temperature Range

T

, T

−55 to 150 ° C Stresses exceeding those listed in the Maximum Ratings table may damage the device. If any of these limits are exceeded, device functionality should not be assumed, damage may occur and reliability may be affected.

1. These ratings are based on a maximum junction temperature of 150 ° C.

2. These are steady−state limits. onsemi should be consulted on applications involving pulsed or low−duty−cycle operations.

THERMAL CHARACTERISTICS (Note 3) (Values are at T

= 25 ° C unless otherwise noted)

Parameter Symbol Value Unit

Total Power Dissipation P

2 W

Dissipation Derate Above 25 ° C P

16 mW/ ° C

Thermal Resistance, Junction−to−Ambient

R

62.5 ° C/W

3. PCB size: FR−4, 76 mm x 114 mm x 1.57 mm (3.0 inch x 4.5 inch x 0.062 inch) with minimum land pattern size.

MARKING DIAGRAM

1. Base 2., 4. Collector

3. Emitter SOT−223

CASE 318H

See detailed ordering and shipping information on page 2 of this data sheet.

ORDERING INFORMATION

1 2 4

3

1

AYW 790A G

G

A = Assembly Location

Y = Year

W = Work Week

790A = Specific Device Code

G = Pb−Free Package

(Note: Microdot may be in either location)

FZT790A

www.onsemi.com 2

ELECTRICAL CHARACTERISTICS (Values are at T

= 25 ° C unless otherwise noted)

Symbol Parameter Conditions Min. Max. Unit

BV

Collector−Emitter Breakdown Voltage I

= −10 mA, I

= 0 −40 V

BV

Collector−Base Breakdown Voltage I

= −100 m A, I

= 0 −50 V

BV

Emitter−Base Breakdown Voltage I

= −100 m A, I

= 0 −5.0 V

I

Collector Cut−Off Current V

= −30 V, I

= 0 −100 nA

V

= −30 V, I

= 0, T

= 100 ° C −10 m A

I

Emitter Cut−Off Current V

= −4 V, I

= 0 −100 nA

h

DC Current Gain (Note 4) V

= −2.0 V, I

= −10 mA 300

V

= −2.0 V, I

= −500 mA 250 V

= −2.0 V, I

= −1.0 A 200 V

= −2.0 V, I

= −2.0 A 150 V

(sat) Collector−Emitter Saturation Voltage

(Note 4)

I

= −500 mA, I

= −5.0 mA −0.25 V

I

= −1.0 A, I

= −10 mA −0.45

I

= −2.0 A, I

= −50 mA −0.75

V

(sat) Base−Emitter Saturation Voltage (Note 4) I

= −1.0 A, I

= −10 mA −1.0 V

V

(on) Base−Emitter On Voltage (Note 4) I

= −1.0 A, V

= −2.0 V −1.0 V

f

Transition Frequency I

= −50 mA, V

= −5.0 V, f = 50 MHz 100 MHz

Product parametric performance is indicated in the Electrical Characteristics for the listed test conditions, unless otherwise noted. Product performance may not be indicated by the Electrical Characteristics if operated under different conditions.

4. Pulse test: pulse width ≤ 300 m s, duty cycle ≤ 2.0%

ORDERING INFORMATION

Part Number Top Mark Package Shipping

FZT790A 790A SOT−223 (Pb−Free) 4,000 Units/ Tape & Reel

†For information on tape and reel specifications, including part orientation and tape sizes, please refer to our Tape and Reel Packaging

Specifications Brochure, BRD8011/D.

FZT790A

www.onsemi.com 3

TYPICAL PERFORMANCE CHARACTERISTICS

Figure 1. Base−Emitter Saturation Voltage vs. Collector Current

Figure 2. Base−Emitter On Voltage vs. Collector Current

Figure 3. Collector−Emitter Saturation Voltage vs. Collector Current

I_C, COLLECTOR CURRENT [A]

VCESAT, COLLECTOR−EMITTER VOLTAGE [V]

V_CE, COLLECTOR VOLTAGE [V]

CAPACITANCE [pF]

Figure 4. Input/Output Capacitance vs. Reverse Bias Voltage

IC, COLLECTOR CURRENT [A]

HFE, CURRENT GAIN

Figure 5. Current Gain vs. Collector Current Figure 6. Power Dissipation vs. Ambient Temperature

I_C, COLLECTOR CURRENT [mA]

VBEon, BASE−EMITTER ON VOLTAGE [V]

I_C, COLLECTOR CURRENT [A]

TEMPERATURE [°C]

PD, POWER DISSIPATION [W]

VBESAT, BASE−EMITTER SATURATION VOLTAGE [V]

0.001 0.01 0.1

0.2 0.4 0.6 0.8 1 1.2 1.4

b = 10

−40°C

25°C 125°C

0.0001 0.001 0.01 0.2

0.4 0.6 0.8 1 1.2 1.4 1.6

−40°C

25°C 125°C V_CE = 2.0 V

0.01 0.1 1 10

0 0.1 0.2 0.3 0.4 0.5 0.6 0.7 0.8 b = 10

−40°C 25°C

125°C

0.1 0.5

0 50 100 150 200 250 300 350 400

V = 2.0Vce

f = 1.0 MHz Cobo

C_ibo

0.00010 0.001 0.01 100

200 300 400 500 600 700 800 900

1000 VCE = 2.0 V

−40°C 25°C 125°C

0 0.0 0.5 1.0 1.5 2.0 2.5

25 50 75 100 125 150 175

1 10 20 50 100

1 10 0.1 1 10

0.1 1 10

SOT−223 CASE 318H

ISSUE B

DATE 13 MAY 2020 SCALE 2:1

1

A = Assembly Location

Y = Year

W = Work Week

XXXXX = Specific Device Code G = Pb−Free Package GENERIC

MARKING DIAGRAM*

AYW XXXXXG

G

(Note: Microdot may be in either location)

*This information is generic. Please refer to device data sheet for actual part marking.

Pb−Free indicator, “G” or microdot “G”, may or may not be present. Some products may not follow the Generic Marking.

MECHANICAL CASE OUTLINE

PACKAGE DIMENSIONS
