PRODUCT CATALOG

INDUSTRIAL

(2)

Screen Size 1.6 inch 2.0 inch 2.2 inch 2.3 inch 2.4 inch 2.83 inch 3.0 inch Mode Resolution(pixel) Active Area(mm) Luminance(cd/m²) Contrast Ratio Viewing Angle(U/D/L/R)(Typ.) NTSC Interface Operating Temperature Storage Temperature Module Size(WxHxD)(mm) Lifetime Application 256x320 25.34x31.68 450 800:1 80/80/80/80 50% MIPI -20°C~+70°C -30°C~+80°C 31.20x44.36x2.82 20000H Wearable TN 176x220 31.68x39.60 220 500:1 70/60/70/70 60% CPU 8/16 bits -20°C~+70°C -30°C~+80°C 38.03x51.65x2.50 20000H Industrial mobile 240x320 33.84x45.12 90 120:1 48/45/40/45 50% RGB 18 bits -20°C~+70°C -30°C~+80°C 40.60x56.60x2.70 20000H Industrial mobile TN 320x240 35.06x46.75 320 350:1 60/70/70/70 50% CPU 16 bits -20°C~+70°C -30°C~+80°C 53.30x46.90x2.25 20000H TN 240x320 36.72x48.96 200 500:1 70/60/70/70 53% CPU 8 bits -20°C~+70°C -30°C~+80°C 42.72x60.26x2.55 20000H TN 240x320 43.20x57.60 300 500:1 70/60/70/70 65% RGB 18 bits -20°C~+70°C -30°C~+80°C 49.90x66.10x2.70 30000H POS TN / Trasnﬂective TN / Trasnﬂective 240x400 38.88x64.80 130 100:1 55/40/40/45 30% RGB+3 SPI/CPU -20°C~+70°C -30°C~+80°C 47.28x76.04x2.40 20000H Industrial mobile

INDUSTRIAL

PRODUCTS

産業用製品

TM SERIES

Industrial mobile

/POS Home healthcare/POS

Screen Size 3.5 inch 3.5 inch 3.5 inch 3.5 inch 3.7 inch 4.3 inch 4.3 inch

Mode Resolution(pixel) Active Area(mm) Luminance(cd/m²) Contrast Ratio Viewing Angle(U/D/L/R)(Typ.) NTSC Interface Operating Temperature Storage Temperature Module Size(WxHxD)(mm) Lifetime Application 240x320 53.64x71.52 100 150:1 50/40/40/45 30% RGB 6 bits+SPI -20°C~+60°C -30°C~+70°C 64.00x85.00x2.93 20000H Industrial mobile TN 320x480 48.96x73.44 300 500:1 70/60/70/70 60% MCU+RGB+SPI -20°C~+70°C -30°C~+80°C 55.26x84.69x2.20 20000H POS TN 320x240 70.08x52.56 300 500:1 60/70/70/70 50% RGB 24 bits -20°C~+70°C -30°C~+80°C 76.90x63.90x3.15 20000H POS TN 320x240 70.08x52.56 350 500:1 60/70/70/70 50% RGB 24 bits -20°C~+70°C -30°C~+80°C 76.90x63.90x4.00 20000H 480x640 56.16x74.88 200 150:1 45/55/50/55 35% RGB 18 bits -20°C~+70°C -30°C~+80°C 65.00x89.00x3.00 50000H TN 480x272 95.04x53.85 800 800:1 80/60/80/80 50% RGB 24 bits -20°C~+70°C -30°C~+80°C 105.50x67.20x4.10 20000H GPS TN 480x272 95.04x53.86 400 800:1 80/60/80/80 50% RGB 24 bits -20°C~+70°C -30°C~+80°C 105.50x67.20x2.90 20000H MFP/ HMI Industry mobile/ White goods RTP RTP RTP Industrial mobile Wide color

gamut Long-lifeLED

Wide temperature

range High brightness On-cell

LED _In-cell RTP _RTP Super Fine TFT

TN / Trasnﬂective TN /

Trasnﬂective

(3)

Screen Size 4.3 inch 4.3 inch 4.3 inch 4.3 inch 4.3 inch 4.6 inch Mode Resolution(pixel) Active Area(mm) Luminance(cd/m²) Contrast Ratio Viewing Angle(U/D/L/R)(Typ.) NTSC Interface Operating Temperature Storage Temperature Module Size(WxHxD)(mm) Lifetime Application TN 480x272 95.04x53.86 280 800:1 80/60/80/80 50% RGB 24 bits -20°C~+70°C -30°C~+80°C 105.50x67.20x4.10 20000H 480x800 57.96x95.40 300 800:1 85/85/85/85 65% RGB 24 bits+SPI -20°C~+70°C -30°C~+80°C 67.50x117.70x4.77 20000H TN 480x272 95.04x53.85 885 800:1 70/60/70/70 50% RGB 24 bits -20°C~+70°C -30°C~+80°C 105.50x67.20x2.90 20000H TN 480x272 95.04x53.85 350 900:1 80/60/80/80 50% RGB 24 bits -20°C~+70°C -30°C~+80°C 105.50x67.20x2.90 20000H 720x1280 58.10x103.30 400 800:1 85/85/85/85 70% MIPI -20°C~+70°C -30°C~+80°C 61.06x113.18x1.43 20000H Industrial mobile

Screen Size 5.0 inch 5.0 inch 5.5 inch 5.7 inch 5.7 inch

Mode Resolution(pixel) Active Area(mm) Luminance(cd/m²) Contrast Ratio Viewing Angle(U/D/L/R)(Typ.) NTSC Interface Operating Temperature Storage Temperature Module Size(WxHxD)(mm) Lifetime Application TN 800x480 108.00x64.80 250 800:1 75/75/75/70 50% RGB -20°C~+70°C -30°C~+80°C 120.70x75.80x3.10 20000H VOIP 720x1080 62.10x110.40 600 800:1 80/80/80/80 70% MIPI -20°C~+70°C -30°C~+80°C 65.40x118.90x1.72 20000H POS 720x1280 68.04x120.96 300 1000:1 80/80/80/80 70% MIPI -20°C~+70°C -30°C~+80°C 76.00x143.30x3.75 20000H POS TN 320x240 115.20x86.40 500 500:1 70/60/70/70 50% RGB 18 bits -20°C~+70°C -30°C~+80°C 144.00x104.60x12.30 50000H HMI TN 320x240 115.20x86.40 400 500:1 60/70/70/70 50% RGB 18 bits -20°C~+70°C -30°C~+80°C 144.00x104.60x12.30 50000H HMI TN 480x272 95.04x53.86 250 900:1 80/60/80/80 50% RGB 24 bits -20°C~+80°C -30°C~+80°C 105.50x67.20x2.90 50000H White goods

/Outdoor navigation HMI / Medical/White goods HMI / Medical/White goods HMI / Medical/White goods HMI / Medical/White goods

RTP

Screen Size 7.0 inch 7.0 inch 7.0 inch

Mode Resolution(pixel) Active Area(mm) Luminance(cd/m²) Contrast Ratio Viewing Angle(U/D/L/R)(Typ.) NTSC Interface Operating Temperature Storage Temperature Module Size(WxHxD)(mm) Lifetime Application TN 800x480 154.08x85.92 450 800:1 70/80/80/80 50% RGB 24 bits -20°C~+70°C -30°C~+80°C 164.90x100.00x5.70 20000H HMI TN 800x480 154.08x85.92 400 800:1 60/80/80/80 50% RGB 24 bits -30°C~+85°C -40°C~+90°C 164.90x100.00x5.70 50000H White goods 800x480 154.08x85.92 520 800:1 85/85/85/85 70% RGB 24 bits -20°C~+70°C -30°C~+80°C 164.90x100.00x5.70 20000H HMI

Screen Size 5.7 inch 6.0 inch

Mode Resolution(pixel) Active Area(mm) Luminance(cd/m²) Contrast Ratio Viewing Angle(U/D/L/R)(Typ.) NTSC Interface Operating Temperature Storage Temperature Module Size(WxHxD)(mm) Lifetime Application 720x1280 71.28x126.72 450 900:1 85/85/85/85 70% MIPI -20°C~+70°C -30°C~+80°C 74.98x137.00x1.57 20000H Industrial mobile 5.7 inch TN 640x480 115.20x86.40 400 500:1 70/60/70/70 50% RGB 18 bits -20°C~+70°C -30°C~+85°C 144.00x104.60x12.30 50000H 800x1280 80.76x129.22 400 800:1 85/85/85/85 70% MIPI -20°C~+70°C -30°C~+80°C 143.02x90.06x2.87 20000H VOIP 6.0 inch 800x1280 80.76x129.22 400 800:1 85/85/85/85 68% MIPI -20°C~+70°C -30°C~+80°C 140.57x87.76x2.70 30000H VOIP Measurement tester / HMI 6.2 inch TN 800x480 137.40x77.28 400 500:1 60/70/75/75 50% RGB 24 bits -20°C~+70°C -30°C~+80°C 155.20x88.20x4.90 20000H 7.0 inch TN 800x480 154.08x85.92 350 1000:1 60/80/80/80 50% RGB 24 bits -20°C~+70°C -30°C~+80°C 164.90x100.00x6.80 20000H 7.0 inch TN 1024x600 153.60x90.00 270 500:1 70/75/75/75 50% LVDS -20°C~+70°C -30°C~+80°C 171.50x110.30x5.05 20000H HMI Measurement tester Auto after market

5.7 inch TN 640x480 115.20x86.40 350 500:1 70/60/70/70 50% RGB 18 bits -20°C~+70°C -30°C~+85°C 144.00x104.60x12.30 50000H 5.7 inch TN 320x240 115.20x86.40 320 500:1 70/60/70/70 50% RGB 18 bits -20°C~+70°C -30°C~+80°C 144.00x104.60x13.50 50000H POS Construction machine 5.0 inch TN 800x480 108.00x64.80 250 800:1 75/75/75/70 50% RGB -20°C~+70°C -30°C~+80°C 120.70x75.80x3.10 20000H VOIP Wide color

gamut Long-lifeLED

Wide temperature

range High brightness On-cell RTP

LED RTP

RTP

Super Fine TFT

LED

LED LED LED

LED LED

(4)

Screen Size 8.0 inch 8.0 inch Mode Resolution(pixel) Active Area(mm) Luminance(cd/m²) Contrast Ratio Viewing Angle(U/D/L/R)(Typ.) NTSC Interface Operating Temperature Storage Temperature Module Size(WxHxD)(mm) Lifetime Application TN 800x600 162.00x121.50 250 800:1 60/70/70/70 50% RGB 24 bits -20°C~+70°C -30°C~+80°C 183.00x141.00x5.60 25000H HMI

Screen Size 9.7 inch

Mode Resolution(pixel) Active Area(mm) Luminance(cd/m²) Contrast Ratio Viewing Angle(U/D/L/R)(Typ.) NTSC Interface Operating Temperature Storage Temperature Module Size(WxHxD)(mm) Lifetime Application TN 1024x768 196.61x147.46 350 500:1 70/60/70/70 50% LVDS -20°C~+70°C -30°C~+80°C 210.20x166.30x3.55 30000H POS TN 800x600 162.00x121.50 700 500:1 50/70/70/70 50% RGB 24 bits -20°C~+70°C -30°C~+80°C 183.00x141.00x5.60 40000H White goods Screen Size Mode Resolution(pixel) Active Area(mm) Luminance(cd/m²) Contrast Ratio Viewing Angle(U/D/L/R)(Typ.) NTSC Interface Operating Temperature Storage Temperature Module Size(WxHxD)(mm) Lifetime Application

Screen Size 12.1 inch 12.1 inch 12.1 inch 15.0 inch 15.0 inch 15.0 inch

Mode Resolution(pixel) Active Area(mm) Luminance(cd/m²) Contrast Ratio Viewing Angle(U/D/L/R)(Typ.) NTSC Interface Operating Temperature Storage Temperature Module Size(WxHxD)(mm) Lifetime Application TN 800x600 246.00x184.50 350 500:1 80/80/60/70 55% LVDS -20°C~+70°C -30°C~+80°C 279.00x209.00x9.00 30000H POS TN 1024x768 245.76x184.32 450 700:1 80/80/80/80 55% LVDS -20°C~+70°C -30°C~+80°C 279.00x209.00x9.00 50000H Medical/HMI 1280x800 261.10x163.20 450 500:1 85/85/85/85/85 40% LVDS -20°C~+70°C -30°C~+80°C 278.00x184.00x9.50 50000H HMI/Marine TN 1024x768 304.12x228.09 450 800:1 80/80/80/80 60% LVDS -20°C~+70°C -30°C~+80°C 326.50x253.50x11.80 50000H POS/ATM TN 1024x768 304.12x228.09 300 800:1 80/80/80/80 60% LVDS -20°C~+70°C -30°C~+80°C 326.50x253.50x11.80 30000H POS TN 1024x768 304.12x228.09 300 800:1 80/80/80/80 60% eDP -20°C~+70°C -30°C~+80°C 326.50x253.50x11.80 30000H POS

9.7 inch 10.1 inch 10.1 inch 10.1 inch 10.4 inch 10.4 inch

TN 1024x768 196.61x147.46 250 500:1 70/70/70/60 50% RGB 24 bits -20°C~+70°C -30°C~+80°C 210.20x166.30x3.66 30000H POS TN 1024x600 222.72x125.28 350 800:1 75/80/80/80 47% LVDS 6 bits -20°C~+70°C -30°C~+80°C 253.20x161.08x7.35 30000H 1280x800 216.96x135.60 400 800:1 85/85/85/85 50% LVDS -10°C~+50°C -20°C~+60°C 229.46x149.10x2.50 30000H IPC/POS 1280x800 216.96x135.60 430 800:1 85/85/85/85 50% LVDS 6/8 bits -20°C~+70°C -30°C~+80°C 231.93x150.60x6.73 50000H TN 800x600 211.20x158.40 400 500:1 60/70/70/70 50% TTL -20°C~+70°C -30°C~+80°C 228.40x175.40x6.20 30000H HMI/ POS TN 800x600 211.20x158.40 400 500:1 60/70/70/70 50% LVDS -30°C~+80°C -30°C~+85°C 243.00x184.00x6.50 50000H HMI/ POS Industrial/Tablet/ MFP/HMI/ Auto after market

VOIP/HMI/ Medical/ POS

8.4 inch 8.4 inch 9.0 inch 9.0 inch 9.2 inch

TN 800x600 170.40x127.80 350 500:1 60/70/70/70 50% LVDS -20°C~+70°C -30°C~+80°C 203.00x12.50x5.70 50000H HMI TN 800x600 170.40x127.80 330 500:1 60/70/70/70 50% TTL+RGB 24 bits -20°C~+70°C -30°C~+80°C 189.75x149.40x4.80 30000H HMI TN 800x480 198.00x111.69 350 500:1 60/70/70/70 50% TTL -20°C~+70°C -30°C~+80°C 211.10x126.50x5.60 20000H MFP TN 1024x600 196.60x114.15 500 800:1 60/70/70/70 50% LVDS -20°C~+70°C -30°C~+80°C 211.10x126.50x5.70 20000H TN 1920x480 226.99x56.73 500 600:1 80/80/60/70 75% LVDS -30°C~+85°C -40°C~+95°C 237.00x72.30x5.80 50000H Auto after market

/ White goods Auto after market

7.0 inch 7.0 inch 7.0 inch 8.0 inch

TN 800x480 154.08x85.92 1400 1000:1 60/80/80/80 50% RGB 24 bits -20°C~+70°C -30°C~+80°C 164.90x100.00x5.70 50000H HMI TN 1024x600 153.60x90.00 320 500:1 70/75/75/75 50% LVDS 6 bits -20°C~+70°C -30°C~+80°C 165.75x105.39x3.40 20000H White goods 1280x800 149.76x93.60 400 800:1 85/85/85/85 50% LVDS 6 bits -20°C~+70°C -30°C~+80°C 150.76x94.60x3.35 30000H VOIP TN 1024x768 162.05x121.54 400 700:1 80/80/80/80 50% LVDS 6 bits -20°C~+70°C -30°C~+80°C 183.00x141.00x3.40 30000H MFP Wide color

gamut Long-lifeLED

Wide temperature

range High brightness On-cell RTP

LED RTP Super Fine TFT

LED

LED LED LED LED

LED LED

(5)

Screen Size 5.7 inch 5.7 inch Part Number Mode Resolution Active Area(mm) Display Color Pixel Pitch(mm) Luminance(cd/m2₎ Contrast Ratio Response Time Interface Power Consumption Operating Temperature Storage Temperature Polarizer Surface Weight Reverse Scan Remarks NL3224AC36-01F TN 320x240 115.2x86.4 262K 0.36x0.36 800 900:1 80/80/80/80 18ms 2.7W -30°C~+80°C -30°C~+80°C AG 144.0x104.6x12.8 150g ○ NL3224AC36-01D TN 320x240 115.2x86.4 262K 0.36x0.36 500 900:1 80/80/80/80 18ms 1.6W -30°C~+80°C -30°C~+80°C AG 144.0x104.6x12.8 150g ○ Viewing Angle(U/D/L/R) Module Size(WxHxD)(mm) (D : max) CMOS

RGB 6 bits RGB 6 bitsCMOS

5.7 inch 5.7 inch 5.7 inch 5.7 inch 5.7 inch

NL6448AC18-12F TN 640x480 115.2x86.4 262K 0.18x0.18 800 900:1 80/80/80/80 18ms 3.6W -30°C~+80°C -30°C~+80°C AG 144.0x104.6x12.8 150g ○ NL6448AC18-11D TN 640x480 115.2x86.4 16.19M 0.18x0.18 550 900:1 80/80/80/80 18ms 2.4W -30°C~+80°C -30°C~+80°C AG 144.0x104.6x12.8 150g ○ NL6448AC18-08F TN 640x480 115.2x86.4 262K 0.18x0.18 800 900:1 80/80/80/80 18ms 3.6W -30°C~+80°C -30°C~+80°C AG 144.0x104.6x12.8 150g ○ NL6448AC18-08D TN 640x480 115.2x86.4 262K 0.18x0.18 550 900:1 80/80/80/80 18ms 2.3W -30°C~+80°C -30°C~+80°C AG 144.0x104.6x12.8 150g ○ NL6448BC18-07 TN 640x480 115.2x86.4 262K 0.18x0.18 300 900:1 80/80/80/80 18ms 1.4W -20°C~+70°C -30°C~+80°C Clear 127.2x100.4x6.1 110g ○ ― CMOS

RGB 6 bits RGB 8 bitsLVDS RGB 6 bitsCMOS RGB 6 bitsCMOS RGB 6 bitsCMOS

Screen Size Part Number Mode Resolution Active Area(mm) Display Color Pixel Pitch(mm) Luminance(cd/m2₎ Contrast Ratio Response Time Interface Power Consumption Operating Temperature Storage Temperature Polarizer Surface Weight Reverse Scan Remarks Viewing Angle(U/D/L/R) Module Size(WxHxD)(mm) (D : max) 6.5 inch 6.5 inch NL6448BC20-30C/30F TN 640x480 132.48x99.36 16.77M / 262K 0.20x0.20 1000 800:1 80/80/80/80 18ms 3.8W -30°C~+80°C -30°C~+80°C 153.0x118.0x8.7 ○ NL6448BC20-30/30D TN 640x480 132.48x99.36 16.77M / 262K 0.20x0.20 600 800:1 80/80/80/80 18ms 2.6W -30°C~+80°C -30°C~+80°C 153.0x118.0x8.7 150g ○ LVDS RGB 6/8 bits RGB 6/8 bitsLVDS -30: Clear -30D: AG -30C: Clear+AR -30F: Clear -35C: Clear+AR -35F: Clear 6.5 inch NL10276BC13-01C TN 1024x768 132.09x99.07 16.77M / 262K 0.12x0.12 650 500:1 80/60/80/80 25ms 3.9W -20°C~+70°C -30°C~+80°C Clear+AR 153.0x118.0x9.5 170g ○ LVDS RGB 6/8 bits -30C: 155g -30F: 150g 6.5 inch NL10276BC13-01 TN 1024x768 132.09x99.07 16.77M / 262K 0.12x0.12 500 500:1 80/60/80/80 25ms 3.9W -20°C~+70°C -30°C~+80°C Clear 153.0x118.0x9.5 165g ○ ― LVDS RGB 6/8 bits 6.5 inch NL6448BC20-35/35D TN 640x480 132.48x99.36 262K 0.20x0.20 600 800:1 80/80/80/80 18ms 2.7W -30°C~+80°C -30°C~+80°C 153.0x118.0x8.7 150g ○ CMOS RGB 6 bits -35: Clear -35D: AG Super Fine

TFT Transmissive-Enhanced View TFT

(-30 C) 6.5 inch NL6448BC20-35C/35F TN 640x480 132.48x99.36 262K 0.20x0.20 1000 800:1 80/80/80/80 18ms 3.9W -30°C~+80°C -30°C~+80°C 153.0x118.0x8.7 ○ CMOS RGB 6 bits -35C: 155g -35F: 150g (-35 C) 8.4 inch NL6448BC26-27C/27F TN 640x480 170.88x128.16 16.77M / 262K 0.26x0.26 900 1000:1 80/80/80/80 18ms 5.0W -30°C~+80°C -30°C~+80°C 200.0x152.0x8.7 260g ○ LVDS RGB 6/8 bits -27C: Clear+AR -27F: Clear (-27 C)

LED LED LED LED LED

INDUSTRIAL

PRODUCTS

産業用製品

(6)

Screen Size

Super Fine

8.4 inch 8.4 inch NL8060BC21-21D TN 800x600 170.4x127.8 16.77M / 262K 0.21x0.21 400 800:1 80/80/80/80 18ms 3.3W -30°C~+80°C -30°C~+80°C AG 200.0x152.0x8.7 260g ○ NL8060BC21-11C/11F TN 800x600 170.4x127.8 16.77M / 262K 0.21x0.21 800 800:1 80/80/80/80 18ms 5.0W -30°C~+80°C -30°C~+80°C 200.0x152.0x8.7 260g ○ LVDS RGB 6/8 bits RGB 6/8 bitsLVDS -11C: Clear+AR -11F: Clear 8.4 inch NL8060BC21-11/11D TN 800x600 170.4x127.8 16.77M / 262K 0.21x0.21 400 800:1 80/80/80/80 18ms 3.0W -30°C~+80°C -30°C~+80°C 200.0x152.0x8.7 260g ○ LVDS RGB 6/8 bits -11: Clear -11D: AG 8.4 inch NL10276BC16-06/06D SFT 1024x768 170.49x127.87 16.77M / 262K 0.16x0.16 600 1000:1 88/88/88/88 25ms 5.6W -30°C~+70°C -30°C~+80°C 200.0x152.0x8.7 260g ○ LVDS RGB 6/8 bits -06: Clear -06D: AG 10.4 inch 10.4 inch NL10276BC20-18C/18F TN 1024x768 210.43x157.82 16.77M / 262K 0.20x0.20 800 900:1 80/80/80/80 18ms 7.5W -30°C~+80°C -30°C~+80°C 228.0x178.5x9.2 380g ○ NL10276BC20-18/18D TN 1024x768 210.43x157.82 16.77M / 262K 0.20x0.20 400 900:1 80/80/80/80 18ms 4.8W -30°C~+80°C -30°C~+80°C 228.0x178.5x9.2 380g ○ LVDS RGB 6/8 bits RGB 6/8 bitsLVDS -18C: Clear+AR -18F: Clear -18: Clear-18D: AG

10.4 inch 10.4 inch 10.4 inch 10.4 inch

NL6448BC33-71C/71F TN 640x480 211.2x158.4 16.77M / 262K 0.33x0.33 900 900:1 80/80/80/80 18ms 6.2W -30°C~+80°C -30°C~+80°C 243.0x185.1x11.0 475g ○ NL6448BC33-71/71D TN 640x480 211.2x158.4 16.77M / 262K 0.33x0.33 450 900:1 80/80/80/80 18ms 3.5W -30°C~+80°C -30°C~+80°C 243.0x185.1x11.0 475g ○ NL6448BC33-70C/70F TN 640x480 211.2x158.4 262K 0.33x0.33 900 900:1 80/80/80/80 18ms 6.4W -30°C~+80°C -30°C~+80°C 243.0x185.1x11.0 475g ○ NL6448BC33-70/70D TN 640x480 211.2x158.4 262K 0.33x0.33 450 900:1 80/80/80/80 18ms 3.7W -30°C~+80°C -30°C~+80°C 243.0x185.1x11.0 475g ○ LVDS

RGB 6/8 bits RGB 6/8 bitsLVDS RGB 6/8 bitsLVDS

NL8060AC26-54D TN 800x600 211.2x158.4 16.77M / 262K 0.26x0.26 450 900:1 80/80/80/80 18ms 5.1W -30°C~+80°C -30°C~+80°C AG 227.3x177.5x9.8 375g ○ -71C: Clear+AR

-71F: Clear -71: Clear-71D: AG -71C: Clear+AR-71F: Clear CMOS

-70: Clear -70D: AG

10.4 inch 10.4 inch 10.4 inch

NL8060AC26-52D TN 800x600 211.2x158.4 16.77M / 262K 0.26x0.26 400 900:1 80/80/80/80 18ms 4.7W -30°C~+80°C -30°C~+80°C AG 243.0x185.1x11.0 430g ○ NL8060BC26-35C/35F TN 800x600 211.2x158.4 16.77M / 262K 0.26x0.26 800 900:1 80/80/80/80 18ms 6.3W -30°C~+80°C -30°C~+80°C 243.0x185.1x11.0 475g ○ NL8060BC26-35/35D TN 800x600 211.2x158.4 16.77M / 262K 0.26x0.26 400 900:1 80/80/80/80 18ms 3.6W -30°C~+80°C -30°C~+80°C 243.0x185.1x11.0 475g ○ LVDS

RGB 6/8 bits RGB 6/8 bitsLVDS RGB 6/8 bitsLVDS

-35C: Clear+AR -35F: Clear -35: Clear-35D: AG 8.4 inch NL6448BC26-27/27D TN 640x480 170.88x128.16 16.77M / 262K 0.26x0.26 500 1000:1 80/80/80/80 18ms 3.1W -30°C~+80°C -30°C~+80°C 200.0x152.0x8.7 260g ○ LVDS RGB 6/8 bits -27: Clear -27D: AG NL6448BC26-26C/26F TN 640x480 170.88x128.16 262K 0.26x0.26 900 1000:1 80/80/80/80 18ms 5.1W -30°C~+80°C -30°C~+80°C 200.0x152.0x8.7 260g ○ CMOS RGB 6bits -26C: Clear+AR -26F: Clear 8.4 inch 12.1 inch NL10276BC24-21 TN 1024x768 245.76x184.32 16.77M / 262K 0.24x0.24 450 900:1 80/80/80/80 18ms 5.2W -30°C~+80°C -30°C~+80°C Clear 260.5x203.0x9.2 490g ○ LVDS RGB 6/8 bits 10.4 inch -47: Clear -47D: AG 12.1 inch NL8060BC31-47/47D TN 800x600 246.0x184.5 16.77M / 262K 0.30x0.30 450 900:1 80/80/80/80 18ms 4.9W -30°C~+80°C -30°C~+80°C 280.0x210.0x9.6 580g ○ LVDS RGB 6/8 bits 12.1 inch NL8060BC31-50F TN 800x600 246.0x184.5 262K 0.30x0.30 900 1000:1 80/80/80/80 18ms 7.1W -30°C~+80°C -30°C~+80°C Clear 260.5x203.0x9.2 490g ○ LVDS RGB 6 bits 12.1 inch NL10276BC24-21F TN 1024x768 245.76x184.32 16.77M / 262K 0.24x0.24 800 900:1 80/80/80/80 18ms 7.5W -30°C~+80°C -30°C~+80°C Clear 260.5x203.0x9.2 490g ○ LVDS RGB 6/8 bits 10.4 inch NL10276BC20-47 SFT 1024x768 210.43x157.82 262K 0.20x0.20 300 700:1 88/88/88/88 25ms 3.9W 0°C~+55°C -20°C~+60°C Clear 227.0x175.4x9.2 360g ○ LVDS RGB 6 bits 12.1 inch NL8060BC31-51C TN 800x600 246.0x184.5 16.77M / 262K 0.30x0.30 900 1000:1 80/80/80/80 18ms 7.0W -30°C~+80°C -30°C~+80°C Clear + AR 260.5x203.0x9.2 490g ○ LVDS RGB 6/8 bits Part Number Mode Resolution Active Area(mm) Display Color Pixel Pitch(mm) Luminance(cd/m2₎ Contrast Ratio Response Time Interface Power Consumption Operating Temperature Storage Temperature Polarizer Surface Weight Reverse Scan Remarks Viewing Angle(U/D/L/R) Module Size(WxHxD)(mm) (D : max) Part Number Mode Resolution Active Area(mm) Display Color Pixel Pitch(mm) Luminance(cd/m2₎ Contrast Ratio Response Time Interface Power Consumption Operating Temperature Storage Temperature Polarizer Surface Weight Reverse Scan Remarks Viewing Angle(U/D/L/R) Viewing Angle(U/D/L/R) Viewing Angle(U/D/L/R) Module Size(WxHxD)(mm) (D : max) Part Number Mode Resolution Active Area(mm) Display Color Pixel Pitch(mm) Luminance(cd/m2₎ Contrast Ratio Response Time Interface Power Consumption Operating Temperature Storage Temperature Polarizer Surface Weight Reverse Scan Remarks Module Size(WxHxD)(mm) (D : max) Part Number Mode Resolution Active Area(mm) Display Color Pixel Pitch(mm) Luminance(cd/m2₎ Contrast Ratio Response Time Interface Power Consumption Operating Temperature Storage Temperature Polarizer Surface Weight Reverse Scan Remarks Module Size(WxHxD)(mm) (D : max) 10.4 inch 10.4 inch NL6448AC33-A1D TN 640x480 211.2x158.4 262K 0.33x0.33 370 900:1 80/80/80/80 18ms 3.3W -30°C~+80°C -30°C~+80°C AG 227.3x177.5x9.8 380g ○ NL6448AC33-A0D TN 640x480 211.2x158.4 262K 0.33x0.33 500 900:1 80/80/80/80 18ms 5.0W -30°C~+80°C -30°C~+80°C AG 246.5x179.4x10.0 390g ○ CMOS

NEW NEW (-71 C) (-70 C) (-26 C) (-11 C) (-35 C) (-18 C) 8.4 inch NL6448BC26-26/26D TN 640x480 170.88x128.16 262K 0.26x0.26 500 1000:1 80/80/80/80 18ms 3.2W -30°C~+80°C -30°C~+80°C 200.0x152.0x8.7 260g ○ CMOS RGB 6 bits -26: Clear -26D: AG LED LED LED LED LED LED LED

LED LED LED LED LED LED LED LED

LED LED LED

10.4 inch NL8060BC26-35E TN 800x600 211.2x158.4 16.77M / 262K 0.26x0.26 400 900:1 80/80/80/80 18ms 3.6W -30°C~+80°C -30°C~+80°C Clear 243.0x185.1x11.0 475g ○ LVDS RGB 6/8 bits

LED LED LED LED

12.1 inch NL10276BC24-21L TN 1024x768 245.76x184.32 16.77M / 262K 0.24x0.24 450 900:1 80/80/80/80 18ms 5.2W -30°C~+80°C -30°C~+80°C Clear 260.5x203.0x9.2 490g ○ LVDS RGB 6/8 bits LED

(7)

Screen Size

Super Fine

15.0 inch NL10276AC30-42C TN 1024x768 304.12x228.09 16.77M / 262K 0.29x0.29 600 600:1 80/80/80/80 8ms 11.9W −20°C~+70°C −30°C~+80 °C Clear + AR 326.5x253.5x12.1 1050g ― LVDS RGB 6/8 bits LVDS RGB 6/8 bits RGB 6/8 bitsLVDS 15.0 inch NL10276AC30-45D TN 1024x768 304.12x228.09 16.77M / 262K 0.29x0.29 400 600:1 80/80/80/80 8ms 7.8W -20°C~+70°C -30°C~+80°C AG 326.5x253.5x12.1 1050g ― LVDS RGB 6/8 bits NL10276BC30-34D TN 1024x768 304.12x228.09 16.77M 0.29x0.29 500 600:1 80/80/80/80 18ms 9.8W −20°C~+70°C −20°C~+80 °C AG 326.5x253.5x12.0 970g ○ LVDS RGB 8 bits 15.0 inch LVDS RGB 6 bits 15.0 inch NL10276BC30-34R TN 1024x768 304.12x228.09 262K 0.29x0.29 400 600:1 80/80/80/80 18 ms 9.8 W −20°C~+70°C −20°C~+80 °C AG 326.5x253.5x12.0 970g ○ LVDS RGB 8 bits 15.0 inch NL10276BC30-39 SFT 1024x768 304.12x228.09 16.77M 0.29x0.29 330 900:1 88/88/88/88 25ms 9.8W −20°C~+70°C −20°C~+80 °C AG 326.5x253.5x12.2 970g ― 15.0 inch NL10276AC30-48D SFT 1024x768 304.12x228.09 16.19M / 262K 0.29x0.29 350 900:1 88/88/88/88 25ms 9.5W -20°C~+70°C -30°C~+80°C AG 326.5x253.5x12.3 870g ○ LVDS RGB 6/8 bits 7.0 inch Wide NL8048BC19-03 TN 800x480 152.4x91.44 16.77M / 262K 0.19x0.19 400 1000:1 80/80/80/80 18ms 3.4W -20°C~+70°C -30°C~+80°C Clear 170.0x111.0x9.0 165g ○ LVDS RGB 6/8 bits 15.0 inch NL10276AC30-53D TN 1024x768 304.12x228.09 16.19M / 262K 0.29x0.29 500 1000:1 80/80/80/80 8ms 8.5W -20°C~+70°C -20°C~+70°C AG 326.5x253.5x6.8 640g ○ 17.0 inch NL128102AC26-01 TN 1280x1024 337.92x270.33 16.77M 0.26x0.26 400 1000:1 80/80/80/80 20ms 12.2W -20°C~+70°C -30°C~+80°C AG 358.5x296.5x14.0 1900g ― 2port LVDS RGB 8 bits 15.0 inch NL10276AC30-52C TN 1024x768 304.12x228.09 16.19M / 262K 0.29x0.29 1600 1000:1 80/80/80/80 8ms 24.1W -30°C~+70°C -30°C~+80°C Clear + AR 326.5x253.5x13.5 1150g ○ 7.0 inch Wide NL8048AC19-14F TN 800x480 152.4x91.44 262K 0.19x0.19 1000 800:1 80/80/80/80 8ms 5.4W -30°C~+80°C -40°C~+80°C AG 170.0x111.0x9.0 185g ○ LVDS RGB 6 bits 7.0 inch Wide NL8048AC19-13 TN 800x480 152.4x91.44 262K 0.19x0.19 500 800:1 80/80/80/80 8ms 3.0W -30°C~+80°C -40°C~+80°C Clear 170.0x111.0x9.0 185g ○ LVDS RGB 6 bits 7.0 inch Wide NL8048BC19-02 TN 800x480 152.4x91.44 16.77M / 262K 0.19x0.19 400 1000:1 80/80/80/80 18ms 3.4W -20°C~+70°C -30°C~+80°C Clear 170.0x111.0x9.0 165g ○ ― LVDS RGB 6/8 bits -09: Clear -09D: AG 7.0 inch Wide NL8048AC19-21 TN 800x480 152.4x91.44 16.19M 0.19x0.19 500 800:1 80/80/80/80 8ms 3.0W -30°C~+80°C -40°C~+80°C Clear 170.0x111.0x9.0 185g ○ LVDS RGB 8 bits NEW 9.0 inch Wide NL8048BC24-09/09D SFT 800x480 196.8x118.08 16.77M / 262K 0.24x0.24 400 800:1 88/88/88/88 25ms 4.4W -20°C~+70°C -30°C~+80°C 220.5x136.5x8.7 275g ○ LVDS RGB 6/8 bits 7.0 inch Wide NL8048BC19-02C TN 800x480 152.4x91.44 16.77M / 262K 0.19x0.19 550 800:1 80/80/80/80 18ms 3.4W -20°C~+70°C -30°C~+80°C Clear + AR 170.0x111.0x9.0 170g ○ LVDS RGB 6/8 bits 9.0 inch Wide NL8048BC24-12/12D TN 800x480 196.8x118.08 16.77M / 262K 0.24x0.24 450 900:1 80/80/80/80 18ms 4.1W -20°C~+70°C -30°C~+80°C 220.5x136.5x8.7 275g ○ LVDS RGB 6/8 bits -12: Clear -12D: AG 9.0 inch Wide NL192108AC10-01D SFT 1920x1080 198.72x111.78 16.77M / 262K 0.10x0.10 400 700:1 88/88/88/88 25ms 11.4W -20°C~+70°C -30°C~+80°C AG 214.6x130.0x9.6 270g ― 2port LVDS RGB 6/8 bits 11.3 inch Wide NL8840AC29-01 SFT 888x408 261.07x119.95 16.77M 0.29x0.29 500 800:1 88/88/88/88 25ms 5.8W -20°C~+70°C -20°C~+70°C Clear 271.8x133.0x8.8 335g ― Clockless Link RGB 8 bits NEW 2lanes eDP 8 bits 11.6 inch Wide NL192108AC13-02D SFT 1920x1080 256.32x144.18 16.77M 0.13x0.13 450 1000:1 88/88/88/88 20ms 8.5W -20°C~+70°C -30°C~+80°C AG 276.5x165.6x6.0 355g ― 10.1 inch Wide NL12880AC16-01D SFT 1280x800 216.96x135.6 16.77M / 262K 0.16x0.16 400 800:1 88/88/88/88 25ms 5.3W -30°C~+80°C -30°C~+80°C AG 235.4x148.8x10.2 335g ○ LVDS RGB 6/8 bits NEW 10.6 inch Wide NL12876AC18-03/03D SFT 1280x768 230.4x138.24 16.77M / 262K 0.18x0.18 300 1000:1 88/88/88/88 25ms 3.3W -20°C~+70°C -30°C~+80°C 248.8x155.8x7.0 270g ○ LVDS RGB 6/8 bits -03: Clear -03D: AG NEW 12.1 inch Wide NL12880BC20-25F TN 1280x800 261.12x163.2 16.77M / 262K 0.20x0.20 1600 800:1 80/80/80/80 15ms 16.9W -20°C~+70°C -30°C~+80°C AG 277.7x180.6x9.2 470g ○ LVDS RGB 6/8 bits Viewing Angle(U/D/L/R) Viewing Angle(U/D/L/R) Part Number Mode Resolution Active Area(mm) Display Color Pixel Pitch(mm) Luminance(cd/m2₎ Contrast Ratio Response Time Interface Power Consumption Operating Temperature Storage Temperature Polarizer Surface Weight Reverse Scan Remarks Module Size(WxHxD)(mm) (D : max) Part Number Mode Resolution Active Area(mm) Display Color Pixel Pitch(mm) Luminance(cd/m2₎ Contrast Ratio Response Time Interface Power Consumption Operating Temperature Storage Temperature Polarizer Surface Weight Reverse Scan Remarks Module Size(WxHxD)(mm) (D : max) 19.0 inch NL128102AC29-17 SFT 1280x1024 376.32x301.05 16.77M 0.29x0.29 800 1000:1 88/88/88/88 25ms 45.0W -20°C~+70°C -30°C~+80°C AG 396.0x324.0x18.5 2100g ― 2port LVDS RGB 8 bits 8.0 inch Wide NL8048BC21-03F SFT 800x480 174.0x104.4 16.77M / 262K 0.21x0.21 1000 1000:1 88/88/88/88 20ms 5.0W -40°C~+80°C -40°C~+80°C AG 192.0x122.0x7.9 225g ○ LVDS RGB 6/8 bits NEW

Wide Format Model

LED LED LVDS RGB 6/8 bits 15.0 inch NL10276AC30-42D TN 1024x768 304.12x228.09 16.77M / 262K 0.29x0.29 600 600:1 80/80/80/80 8ms 11.9W -20°C~+70°C -30°C~+80°C AG 326.5x253.5x12.1 1050g ―

LED LED LED LED

LED LED LED LED LED LED

LED LED

(8)

Screen Size

Super Fine

LVDS RGB 6/8 bits 12.1 inch Wide NL12880BC20-05/05D SFT 1280x800 261.12x163.2 16.77M / 262K 0.20x0.20 450 1000:1 88/88/88/88 25ms 6.5W -20°C~+70°C -30°C~+80°C 277.7x180.6x9.2 460g ○ -05: Clear -05D: AG LVDS RGB 6/8 bits 12.1 inch Wide NL12880AC20-14D TN 1280x800 261.12x163.2 16.77M / 262K 0.20x0.20 450 800:1 80/80/80/80 15ms 5.6W -30°C~+80°C -30°C~+80°C AG 277.7x180.6x9.2 470g ○ NEW 12.1 inch Wide NL12880AC20-20D SFT 1280x800 261.12x163.2 16.77M 0.20x0.20 400 1000:1 88/88/88/88 25ms 7.1W -20°C~+70°C -30°C~+80°C AG 277.7x180.6x9.2 470g ― LVDS RGB 8 bits 15.3 inch Wide NL12876BC26-32D SFT 1280x768 334.08x200.45 16.77M / 262K 0.26x0.26 470 700:1 88/88/88/88 25ms 9.8W -20°C~+70°C -20°C~+80°C AG 358.0x226.0x14.8 1100g ― LVDS RGB 6/8 bits 15.6 inch Wide NL13676BC25-03F TN 1366x768 344.23x193.53 16.77M / 262K 0.25x0.25 1100 900:1 80/80/80/80 18ms 16W -20°C~+70°C -30°C~+80°C AG 363.8x215.9x13.1 1070g ― LVDS RGB 6/8 bits 15.6 inch Wide NL13676AC25-01D TN 1366x768 344.23x193.53 16.77M / 262K 0.25x0.25 400 900:1 80/80/80/80 18ms 10.6W -20°C~+70°C -20°C~+80°C AG 363.8x215.9x10.8 800g ― LVDS RGB 6/8 bits 12.1 inch Wide NL12880BC20-07F TN 1280x800 261.12x163.2 16.77M / 262K 0.20x0.20 1800 800:1 80/80/80/80 15ms 16.7W -20°C~+70°C -30°C~+80°C AG 277.7x180.6x9.2 470g ○ LVDS RGB 6/8 bits NEW 15.6 inch Wide NL192108AC18-02D SFT 1920x1080 344.16x193.59 16.77M 0.17x0.17 400 1000:1 88/88/88/88 25ms 13.7W -20°C~+70°C -20°C~+70°C AG 363.8x215.9x6.8 610g ― NEW 15.6 inch Wide NL13676BC25-07F TN 1366x768 344.23x193.53 16.19M / 262K 0.25x0.25 1250 900:1 80/80/80/80 18ms 16.3W -30°C~+80°C -30°C~+80°C AG 363.8x215.9x13.1 1070g ― LVDS RGB 6/8 bits NEW 15.6 inch Wide NL192108AC18-01D SFT 1920x1080 344.16x193.59 16.77M 0.17x0.17 400 1000:1 88/88/88/88 25ms 13.9W -20°C~+70°C -20°C~+70°C AG 363.8x215.9x6.8 610g ― 2lanes eDP RGB 8 bits 2port LVDS RGB 8 bits NEW 15.6 inch Wide NL192108BC18-06F SFT 1920x1080 344.16x193.59 16.77M 0.17x0.17 1500 750:1 88/88/88/88 30ms 23.3W -30°C~+85°C -40°C~+85°C AG 363.8x215.9x16.2 1050g ― 2lanes eDP RGB 8 bits NEW 18.5 inch Wide NL192108AC21-01 SFT 1920x1080 408.96x230.4 16.77M 0.21x0.21 400 1000:1 88/88/88/88 25ms 15.3W -20°C~+70°C -20°C~+80°C AG 430.4x254.6x14.0 1550g ― 2lanes eDP RGB 8 bits NEW 18.5 inch Wide NL192108AC21-04 SFT 1920x1080 408.96x230.4 16.77M 0.21x0.21 400 1000:1 88/88/88/88 25ms 15.3W -20°C~+70°C -20°C~+80°C AG 430.4x254.6x14.0 1550g ― 2port LVDS RGB 8 bits NEW NL13676AC25-05D TN 1366x768 344.23x193.53 16.77M / 262K 0.25x0.25 400 900:1 80/80/80/80 18ms 8.5W -20°C~+70°C -20°C~+80°C AG 363.8x215.9x10.8 800g ― LVDS RGB 6/8 bits 15.6 inch Wide Viewing Angle(U/D/L/R) Viewing Angle(U/D/L/R) Part Number Mode Resolution Active Area(mm) Display Color Pixel Pitch(mm) Luminance(cd/m2₎ Contrast Ratio Response Time Interface Power Consumption Operating Temperature Storage Temperature Polarizer Surface Weight Reverse Scan Remarks Module Size(WxHxD)(mm) (D : max) Part Number Mode Resolution Active Area(mm) Display Color Pixel Pitch(mm) Luminance(cd/m2₎ Contrast Ratio Response Time Interface Power Consumption Operating Temperature Storage Temperature Polarizer Surface Weight Reverse Scan Remarks Module Size(WxHxD)(mm) (D : max) LED LED

LED LED LED LED

MEDICAL

PRODUCTS

医療診断用製品

(9)

Screen Size Part Number Mode Resolution Active Area(mm) Display Color Pixel Pitch(mm) Luminance(cd/m2₎ Contrast Ratio Response Time Interface Power Consumption Operating Temperature Storage Temperature Polarizer Surface Weight Remarks Viewing Angle(U/D/L/R) Module Size(WxHxD)(mm) (D : max) Screen Size Part Number Mode Resolution Active Area(mm) Display Color Pixel Pitch(mm) Luminance(cd/m2₎ Contrast Ratio Response Time Interface Power Consumption Operating Temperature Storage Temperature Polarizer Surface Weight Remarks Viewing Angle(U/D/L/R) Module Size(WxHxD)(mm) (D : max) Mono 21.3 inch 21.3 inch NL160120AM27-33A SFT 1600x1200 432.0x324.0 0.27x0.27 1900 1400:1 88/88/88/88 40ms 36.0W 0°C~+60°C -20°C~+60°C AG 457.0x350.0x23.0 2700g NL160120AC27-32 SFT 1600x1200 432.0x324.0 16.77M 0.27x0.27 900 1400:1 88/88/88/88 40ms 52.8W 0°C~+60°C -20°C~+60°C AG 457.0x350.0x23.0 2800g 766 gray scales/pixel 256 gray scales/sub-pixel 2port LVDS

LCR 8 bits 2port LVDSRGB 8 bits

Dr + Dr + 21.3 inch NEW NL256204AC16-01 SFT 2560x2048 422.40x337.92 1073M 0.16x0.16 1000 1300:1 88/88/88/88 25ms 65.4W 0°C~+60°C -20°C~+60°C AG 438.8x361.3x26.0 3100g 4port LVDS RGB 10 bits SFT SFT 30.0 inch NL328204AC19-01 SFT 3280x2048 645.50x403.04 1073M 0.19x0.19 1000 1500:1 88/88/88/88 25ms 114W 0°C~+60°C -20°C~+60°C AG 670.0x427.0x30.5 5500g 4lanes eDP RGB 10 bits NEW 21.3 inch NL256204AM16-02A SFT 2560x2048 422.40x337.92 0.16x0.16 2000 1400:1 88/88/88/88 25ms 49.8W 0°C~+60°C -20°C~+60°C AG 438.8x361.3x26.0 3100g 3072 gray scales/pixel 1024 gray scales/sub-pixel 4port LVDS LCR 10 bits NEW Super Fine TFT bit

10

Dr+ SFT 10bit SFT LED Dr+ 10bit Dr+ SFT Mono 10_bit LED 21.3 inch NL204153AM21-18A SFT 2048x1536 433.15x324.86 0.21x0.21 1700 1400:1 88/88/88/88 40ms 37.0W 0°C~+60°C -20°C~+60°C AG 457.0x350.0x23.0 2700g 3072 gray scales/pixel 1024 gray scales/sub-pixel 4port LVDS LCR 10 bits Dr+ SFT Mono 10_bit LED LED LED 4port LVDS RGB 10 bits 21.3 inch NL204153AC21-17 SFT 2048x1536 433.15x324.86 1073M 0.21x0.21 800 1400:1 88/88/88/88 40ms 58.0W 0°C~+60°C -20°C~+60°C AG 457.0x350.0x23.0 2700g Dr+ SFT LED 10bit Dr + 21.3 inch NL204153AC21-25 SFT 2048x1536 433.15x324.86 16.77M 0.21x0.21 800 1400:1 88/88/88/88 40ms 58.2W 0°C~+60°C -20°C~+60°C AG 457.0x350.0x23.0 2700g 4port LVDS RGB 8 bits SFT LED 10 bit driver

PRODUCTS

タッチパネル製品

TM SERIES

(10)

Wide color

gamut LED Long-lifeLED Wide temperature High brightness On-cell RTP RTP

Screen Size 4.3 inch 4.3 inch 5.0 inch 5.7 inch 5.7 inch 7.0 inch 7.0 inch

Mode Resolution Multi Touch TP Outline(mm) TP Viewing Area(mm) Transmittance(Typ.) Reﬂectance(Typ.) Operating Temperature Storage Temperature Input Type Application TN 480x272 2~5 points 113.44x71.46x1.35 96.04x54.86 88% 4% -30°C~+80°C -40°C~+90°C 4 TN 480x800 5 points 67.50x117.70x2.58 94.40x56.96 88% 4% -30°C~+80°C -40°C~+90°C 4 TN 800x480 2~5 points 123.26x80.06x1.35 96.04x54.86 88% 4% -30°C~+80°C -40°C~+90°C 4 TN 320x240 2~5 points 144.00x104.60x1.35 116.60x87.80 88% 4% -20°C~+70°C -30°C~+85°C Finger/Glove 3 TN 640x480 2~5 points 144x104.6x1.35 116.60x87.80 88% 4% -20°C~+70°C -30°C~+85°C Finger/Glove 3 TN 800x480 2~5 points 171.50x110.30x1.35 155.24x87.12 88% 4% -20°C~+70°C -30°C~+85°C Finger/Glove 3 TN 1024x 600 2~5 points 171.50x110.30x1.35 155.20x91.40 88% 4% -20°C~+70°C -30°C~+85°C Finger/Glove 3

Screen Size 7.0 inch 8.0 inch 10.1inch 10.1 inch 10.1 inch 10.1 inch

Mode Resolution Multi Touch TP Outline(mm) TP Viewing Area(mm) Transmittance(Typ.) Reﬂectance(Typ.) Operating Temperature Storage Temperature Input Type Application 1280x800 2~5 points 179.76x123.60x1.75 150.76x94.60 88% 4% -20°C~+70°C -30°C~+85°C Finger/Glove 3 TN 1024x768 2~10 points 183.00x141.00x1.35 163.05x122.54 88% 4% -20°C~+70°C -30°C~+85°C Finger/Glove 3 HMI/Medical TN 1280x800 2~10 points 244.50x168.10x1.75 218.36x137.00 88% 4% -20°C~+70°C -30°C~+85°C Finger/Glove 3 HMI/Instrument TN 1280x800 2~10 points 233.00X156.00x1.83 218.36x137.00 88% 4% -20°C~+70°C -30°C~+85°C Finger/Glove 4 Medical TN 1280x800 2~10 points 258.66x177.30x1.75 218.36x137.00 88% 4% -20°C~+70°C -30°C~+85°C Finger/Glove 3 Home automation TN 1024x 600 2~10 points 236.40x147.89x1.75 223.72x126.28 88% 4% -20°C~+70°C -30°C~+85°C Finger/Glove 3 HMI/Medical

Screen Size 5.0 inch 5.7 inch 7.0 inch 7.0 inch 7.0 inch

Mode Resolution(pixel) Active Area(mm) Luminance(cd/m²) Contrast Ratio Viewing Angle(U/D/L/R)(Typ.) NTSC Interface Operating Temperature Storage Temperature Module Size(WxHxD)(mm) Lifetime Application 720x1280 62.10 x110.40 400 800:1 80/80/80/80 70% MIPI -20°C~+70°C -30°C~+80°C 66.80x131.30x2.57 20000H Home automation TN 320x240 115.20x86.40 340 500:1 70/60/70/70 50% RGB 18 bits -20°C~+70°C -30°C~+80°C 144.00x104.60x12.30 50000H Industrial mobile TN 800x480 154.08x85.92 350 500:1 55/70/70/70 50% RGB 24 bits -20°C~+70°C -30°C~+80°C 171.50x110.30x6.93 25000H 1280x800 152.16x96.00 500 800:1 85/85/85/85 50% LVDS 6/8 bits -20°C~+70°C -30°C~+80°C 179.76x123.60x6.35 50000H HMI TN 800x480 154.08x85.92 1200 1000:1 60/80/80/80 50% RGB 24 bits -20°C~+70°C -30°C~+80°C 171.50x110.30x7.35 50000H HMI Available Max Glass

Cover Thickness(mm)

Available Max Glass Cover Thickness(mm)

Finger/Glove/

Passive pen Finger/Glove/Passive pen Finger/Glove/Passive pen Industrial mobile/POS

Home automation Industrial mobile/POSHome automation Industrial mobile/Medical/HMI Industrial mobile/Instrument/HMI Industrial mobile/Instrument/HMI Home automation/HMI/Medical/POS

Home automation/ HMI/Medical/POS Home automation/Power meter/Construction machine/Industrial mobile Home automation/ HMI/Medical/POS

PCAP Super Fine TFT

LED LED LED

TOUCH

PRODUCTS

タッチパネル製品

NL SERIES

(11)

Screen Size Part Number Mode Resolution Active Area(mm) Luminance(cd/m2₎ Operating Temperature Storage Temperature Polarizer Surface Cover Glass Remarks Module Size(WxHxD)(mm) (D : max) Viewing Angle(U/D/L/R) Screen Size Part Number Mode Resolution Active Area(mm) Luminance(cd/m2₎ Operating Temperature Storage Temperature Polarizer Surface Cover Glass Remarks Module Size(WxHxD)(mm) (D : max) Viewing Angle(U/D/L/R) Screen Size Part Number Mode Resolution Active Area(mm) Luminance(cd/m2₎ Operating Temperature Storage Temperature Polarizer Surface Cover Glass Remarks Module Size(WxHxD)(mm) (D : max) Viewing Angle(U/D/L/R) 6.5 inch 6.5 inch NL6448BC20-30JF TN 640x480 132.48x99.36 950 80/80/80/80 -30°C~+80°C -30°C~+80°C Clear + AFP 153.0x118.0x10.0 ― Optical bonding NL10276BC13-01JA TN 1024x768 132.096x99.072 480 80/60/80/80 -20°C~+70°C -30°C~+80°C Clear 153.0x118.0x10.7 ― Optical bonding 7.0 inch Wide 7.0 inch Wide NL8048AC19-13BD TN 800x480 152.40x91.44 430 80/80/80/80 -30°C~+80°C -40°C~+80°C AG + AFP 170.0x111.0x11.2 0.7mm ― NL8048AC19-13KD TN 800x480 152.40x91.44 470 80/80/80/80 -30°C~+80°C -40°C~+80°C AG + AFP 170.0x111.0x11.2 0.7mm Optical bonding Wet&Glove NEW 7.0 inch Wide NL8048AC19-14KH TN 800x480 152.40x91.44 950 80/80/80/80 -30°C~+80°C -40°C~+80°C AG + AFP 170.0x111.0x11.2 0.7mm Optical bonding Wet&Glove NEW 10.4 inch NL10276BC20-18KE TN 1024x768 210.43x157.82 770 80/80/80/80 -30°C~+80°C -30°C~+80°C Clear 228.0x178.5x11.2 0.7mm Optical bonding Wet&Glove 8.4 inch NL8060AC21-21KD TN 800x600 170.4x127.8 370 80/80/80/80 -30°C~+80°C -30°C~+80°C AG + AFP 200.0152.0x10.9 0.7mm Optical bonding Wet&Glove 12.1 inch Wide NL12876AC18-07DC 1280x768 230.40x138.24 250 88/88/88/88 -20°C~+70°C -20°C~+70°C AR 267.8x174.2x9.2 ― NL12880BC20-13ND 1280x800 261.12x163.2 430 88/88/88/88 -20°C~+70°C -30°C~+80°C AG Etching 298.7x200.8x11.5 0.95mm Optical bonding

Screen Size 15.3 inch Wide

Part Number Mode Resolution Active Area(mm) Luminance(cd/m2₎ Operating Temperature Storage Temperature Polarizer Surface Cover Glass Remarks NL12876BC26-33NA 1280x768 334.08x200.45 470 88/88/88/88 -20°C~+70°C -20°C~+80°C Clear 385.0x251.4x17.3 Optical bonding 10.4 inch NL10276BC20-18KH TN 1024x768 210.43x157.82 760 80/80/80/80 -30°C~+80°C -30°C~+80°C AG + AFP 228.0x178.5x11.4 0.7mm Optical bonding Wet&Glove 1.1mm Chemical strength 12.1 inch Wide NL10276BC24-36KD TN 1024x768 245.76x184.32 390 80/80/80/80 -30°C~+80°C -30°C~+80°C AG + AFP 260.5x203.0x11.6 0.7mm Optical bonding Wet&Glove 12.1 inch Wide NL10276BC24-21KH TN 1024x768 245.76x184.32 750 80/80/80/80 -30°C~+80°C -30°C~+80°C AG + AFP 260.5x203.0x11.6 0.7mm Optical bonding Wet&Glove 1.1mm Chemical strength 15.0 inch NL10276KC30-50DD TN 1024x768 304.12x228.09 450 80/80/80/80 -20°C~+70°C -20°C~+80°C AG + AFP 326.5x253.5x15.0 Wet&Glove 1.8mm Chemical strength NEW Module Size(WxHxD)(mm) (D : max) Super Fine TFT 12.1 inch Wide NL12880BC20-05BA 1280x800 261.12x163.2 400 88/88/88/88 -20°C~+70°C -30°C~+80°C Clear 277.7x180.6x11.2 0.7mm ― 1.8mm Chemical strength NL10276KC30-43DD TN 1024x768 304.12x228.09 450 80/80/80/80 -20°C~+70°C -20°C~+80°C AG + AFP 326.5x253.5x15.5 ― 15.0 inch Viewing Angle(U/D/L/R) 12.1 inch Wide NL12880BC20-05BD 1280x800 261.12x163.2 400 88/88/88/88 -20°C~+70°C -30°C~+80°C AG + AFP 277.7x180.6x11.2 0.7mm ― 10.4 inch NL8060BC26-35BD TN 800x600 211.20x158.40 350 80/80/80/80 -30°C~+80°C -30°C~+80°C AG + AFP 243.0x185.1x13.2 0.7mm ― Optical bonding Wet&Glove 8.4 inch NL8060BC21-11KG TN 800x600 170.4x127.8 750 80/80/80/80 -30°C~+80°C -30°C~+80°C AR 200.0x152.0x10.8 0.7mm Optical bonding NL8060BC26-56KD TN 800x600 211.2x158.4 380 80/ 80/ 80/80 -30°C~+80°C -30°C~+80°C AG + AFP 243.0x185.1x13.2 0.7mm 10.4 inch NL8060BC26-35BA TN 800x600 211.20x158.40 350 80/80/80/80 -30°C~+80°C -30°C~+80°C Clear 243.0x185.1x13.0 0.7mm ― 10.4 inch 10.4 inch NL10276BC20-18BD TN 1024x768 210.43x157.82 350 80/80/80/80 -30°C~+80°C -30°C~+80°C AG + AFP 228.0x178.5x10.9 0.7mm Wet&Glove 10.4 inch NL10276BC20-18KD TN 1024x768 210.43x157.82 380 80/80/80/80 -30°C~+80°C -30°C~+80°C AG + AFP 228.0x178.5x11.4 0.7mm Optical bonding Wet&Glove 10.6 inch NEW

(12)

Enhanced Black Nematic

Normal White TN

EBN

TN-NW

Duty 1/4 1/9 1/16 1/32 _(1/4-static)WEBN _(1/4-static)DEBN

Bias 1/3 1/3 1/4 1/5 1/6 1/3 1/3

Available Backlight Mono Mono Mono Mono Mono Mono Mono

CR at -30℃ 1000:1 1000:1 900:1 600:1 200:1 600:1 1000:1 CR at 22℃ 1500:1 1500:1 1000:1 800:1 300:1 800:1 1000:1 CR at 85℃ 1000:1 1000:1 1000:1 600:1 200:1 600:1 1000:1 Ton+Toff(-30℃)(s) 9 4 9 11 15 8 7 Ton+Toff(22℃)(ms) 100 50 100 100 250 90 40 Ton+Toff(85℃)(ms) 20 20 30 30 40 20 10

Color/Background Black Black Black Black Black Black Black

Transmittance(%) 13 10 12 10 7 5 7 Operating Temperature -30°C ~+85°C -30°C ~+85°C -30°C ~+85°C -30°C ~+85°C -30°C ~+85°C -30°C ~+85°C -30°C ~+85°C Storage Temperature -40°C ~+90°C -40°C ~+90°C -40°C ~+90°C -40°C ~+90°C -40°C ~+90°C -40°C ~+90°C -40°C ~+90°C Vertical(CR>100) -25° /+60° -25° /+50° -15° /+38° -20° /+60° -18° /+60° ﹥-70° / ﹥ +70° -20° /+60° Horizontal(CR>100) -60° /+60° -60° /+50° -30° /+30° -50° /+49° -45° /+40° ﹥-70° / ﹥ +70° -50° /+40° Duty 1/4 1/9 1/3 Mono Transflective NW 8.4 8.6 3.5 4.3 80 30 Black/backlight color 15 -30°C~+85°C -40°C~+90°C -15°/+50° -60°/+60° 1/3 Mono Transflective NW 4.0 6.2 6.7 5 120 30 Black/backlight color 10 -30°C~+85°C -40°C~+90°C -15°/+50° -60°/+60° 1/3 Mono Transmissive NW 7.2 10.5 5.5 4.8 90 30 Black/backlight color 30 -30°C~+85°C -40°C~+90°C -15°/+50° -60°/+60° 1/3 RED/Orange/Amber Transmissive WV 93 84 5.1 2 66 20 Black/backlight color 18 -30°C~+85°C -40°C~+90°C -35°/+40° -50°/+50° 1/3 Mono Transflective NW 8.4 8.6 3.5 4.3 80 30 Black/backlight color 15 -30°C~+85°C -40°C~+90°C -15°/+50° -60°/+60° 1/5 RED/Orange/Amber Transmissive WV 35 55 7 5.2 240 50 Black/backlight color 25 -30°C~+85°C -40°C~+90°C -20°/+20° -40°/+40° Bias Available Backlight Mode CR at-30℃ CR at22℃ CR at80℃ Ton+Toff(-30℃)(s) Ton+Toff(22℃)(ms) Ton+Toff(80℃)(ms) Color/Background Transmittance(%) VerticalCR>2 for NW CR>10 for NB Horizontal CR>2 for NW CR>10 for NB Operating Temperature Storage Temperature
