Ultrafast Dual Diode12 A, 200 V

Ultrafast Dual Diode

12 A, 200 V

RURD620CCS9A

The RURD620CCS9A is an ultrafast dual diode with low forward voltage drop. This device is intended for use as freewheeling and clamping diodes in a variety of switching power supplies and other power switching applications. It is specially suited for use in switching power supplies and industrial application.

Features

• Ultrafast Recovery t rr = 30 ns (@ I F = 6 A)

• Max Forward Voltage, V F = 1.0 V (@ T C = 25 ° C)

• Reverse Voltage, V RRM = 200 V

• Avalanche Energy Rated

• RoHS Compliant Applications

• Switching Power Supplies

• Power Switching Circuits

• General Purpose

ABSOLUTE MAXIMUM RATINGS (Per Leg) (T

= 25°C unless otherwise specified)

Symbol Rating Value Unit

V

Peak Repetitive Reverse Voltage 200 V

V

Working Peak Reverse Voltage 200 V

V

DC Blocking Voltage 200 V

I

Average Rectified Forward Current

T

= 160°C 6 A

I

Repetitive Peak Surge Current

Square Wave, 20 kHz 12 A

I

Nonrepetitive Peak Surge Current

Halfwave, 1 Phase, 60 Hz 60 A

P

Maximum Power Dissipation 45 W

E

Avalanche Energy (See Figures 10 and 11) 10 mJ T

, T

Operating and Storage Temperature −65 to 175 °C Stresses exceeding those listed in the Maximum Ratings table may damage the device. If any of these limits are exceeded, device functionality should not be assumed, damage may occur and reliability may be affected.

MARKING DIAGRAM SYMBOL

A

K

A

ANODE 1 ANODE 2

CATHODE (FLANGE)

DPAK3 (TO−252 3 LD) JEDEC CASE 369AS

$Y&Z&3&K XXXXX

$Y = onsemi Logo

&Z = Assembly Plant Code

&3 = 3−Digit Date Code

&K = 2−Digits Lot Run Traceability Code XXXXX = Device Code (UR620C, RURD620)

Part Number Package Brand ORDERING INFORMATION RURD620CCS9A

TO−252−3L

UR620C NOTE: When ordering, use the entire part number.

Add the suffix, 9 A, to obtain the TO−252 variant in tape and reel, i.e.,

RURD620CCS9A.

RURD620CCS9A−F085 RURD620

TO−252−3L

RURD620CCS9A

www.onsemi.com 2

ELECTRICAL CHARACTERISTICS (Per Leg) (T

= 25°C unless otherwise specified)

Symbol Test Condition Min Typ Max Unit

V

I

= 6 A − − 1.0 V

I

= 6 A, T

= 150°C − − 0.83 V

I

V

= 200 V − − 100 mA

V

= 200 V, T

= 150°C − − 500 mA

t

I

= 1 A, dI

/dt = 200 A/ms − − 25 ns

I

= 6 A, dI

/dt = 200 A/ms − − 30 ns

t

I

= 6 A, dI

/dt = 200 A/ms − 13 − ns

t

I

= 6 A, dI

/dt = 200 A/ms − 6.5 − ns

Q

I

= 6 A, dI

/dt = 200 A/ms − 20 − nC

C

V

= 10 V, I

= 0 A − 30 − pF

R

− − 3.5 °C/W

Product parametric performance is indicated in the Electrical Characteristics for the listed test conditions, unless otherwise noted. Product performance may not be indicated by the Electrical Characteristics if operated under different conditions.

DEFINITIONS

V

= Instantaneous forward voltage (pw = 300 m s, D = 2%).

I

= Instantaneous reverse current.

T

= Reverse recovery time (See Figure 9), summation of t

+ t

. t

= Time to reach peak reverse current (See Figure 9).

t

= Time from peak I

to projected zero crossing of I

based on a straight line from peak I

through 25% of I

(See Figure 9).

Q

= Reverse recovery charge.

C

= Junction Capacitance.

R

= Thermal resistance junction to case. pw = Pulse width.

D = Duty cycle.

TYPICAL PERFORMANCE CURVES

1 30

0.5 10

0 0.25 0.5 0.75 1 1.25 1.5 0 50 100 150 200

100

0.01 0.1 1 10

0.001

175°C 25°C

100°C

175°C

25 ° C 100°C

I

, FOR W ARD CURRENT (A) I

, REVERSE CURRENT (A)

V

, FORWARD VOLTAGE (V) V

, REVERSE VOLTAGE (V)

Figure 1. Forward Current vs. Forward Voltage Figure 2. Reverse Current vs. Reverse Voltage

TYPICAL PERFORMANCE CURVES (Continued)

Figure 3. t

, t

and t

Curves vs. Forward Current Figure 4. t

, t

and t

Curves vs. Forward Current

Figure 5. t

, t

and t

Curves vs. Forward Current Figure 6. Current Derating Curve 0 1

12 20 16

0.5 6

8 4

0 1 24 40 32

0.5 6

16 8

t, RECOVER Y TIMES (ns) I

, A VERAGE FOR W ARD CURRENT (A)

I

, FORWARD CURRENT (A) T

, CASE TEMPERATURE ( ° C)

0 1 40 60 50

0.5 6

30

10 20

5

1

0 150 155 160 165 170 175

2 3 4 6

DC SQUARE WAVE

20 40 30 50

t, RECOVER Y TIMES (ns) t, RECOVER Y TIMES (ns)

I

, FORWARD CURRENT (A) I

, FORWARD CURRENT (A)

ACIT ANCE (pF)

T

= 25°C, dI

/dt = 200 A/ms

T

= 100°C, dI

/dt = 200 A/ms

T

= 175°C, dI

/dt = 200 A/ms t

t

t

t

t

t

t

t

t

RURD620CCS9A

www.onsemi.com 4

TEST CIRCUITS AND WAVEFORMS

R

V

IGBT

CURRENT SENSE DUT

V

t

t

+

−

dt dI

I

t

t

t

0

I

0.25 I

DUT CURRENT

SENSE

+

L R

V

− V

Q

I V

t

t

t

I

V

t I

V

AMPLITUDE AND R

CONTROL dI

/dt t

AND t

CONTROL I

I = 1 A L = 20 mH R < 0.1 W

E

= 1/2LI

[V

/ (V

− V

)]

Q

= IGBT (BV

> DUT V

)

Figure 8. t

Test Circuit Figure 9. t

Waveforms and Definitions

Figure 10. Avalanche Energy Test Circuit Figure 11. Avalanche Current and Voltage

Waveforms

DPAK3 (TO−252 3 LD) CASE 369AS

ISSUE A

DATE 28 SEP 2022

XXXX = Specific Device Code GENERIC MARKING DIAGRAM*

XXXXXX

XXXXXX

AYWWZZ
