Power Supply
for Metal Surface Treatment
Power Supply for Met
半世紀以上にわたって蓄積された技術。
エレクトロニクス界のますます多様化していくニーズに、
適確に対応する金属表面処理用電源の開発を続けています。
1
現在、表面処理技術は装飾・防錆や電子部品の機能めっきに至るまで、
その用途・機能はますます拡がりつつあります。
そういうなかで、この表面処理技術はさらに高精度・高品質・経済性
が強く要求されます。
なかでも、特に電気めっきはその加工技術の優れた機能により重要
な役割りを担っています。
多様化する表面処理技術
金属表面処理=めっきの作業は、素地の調整ともいうべき〈前処理
工程〉
〈各種めっき工程〉
〈後処理工程〉と、それぞれの素材や加工
品に合わせて、複雑なプロセスを有しています。
しかしながら、いかに複雑で高度なめっき作業であれ、時代はいま、
よりシビアな品質の安定化・省力化・合理化が求められています。
このような課題を総合的に解決する一つの手段として注目を集めて
いるのが、新しい電源機器の導入です。
これは各種めっきに必要なベストの電流をよりスピーディに、より効
率よく調整し、めっき品質の向上をはかるとともに、省エネ時代の要
望にすばやく対応できます。
またこれら新しい電源は、低騒音・無公害化などでも大きく貢献して
います。
金属表面処理のプロセス
表面処理業界の急速な技術の進歩とともに、この電源にも技術革新
が求められております。
一方、この技術革新を支えるパワーエレクトロニクス技術(電力用半
導体素子、変換技術、制御技術)は日々進展しつづけており、特に電
力用トランジスタの高周波化は、従来のめっき用電源の概念に革新
をもたらし、いわゆるインバータ方式の電源やパルス電源が実用化
されました。
今後、さらに高精度・高効率化をめざし、小形・軽量化をはかり、また
マイコンとのドッキングによるめっき自動化ラインの集中管理により
省力化、品質向上に大いに寄与します。
表面処理電源の革新
As for the surface treatment technology, the usage and function
are extending to the function platings of a decoration, rust
pre-vention, and electronic parts more and more now. As for this
sur-face treatment technology, high accuracy or more, the high
quali-ty, and the economy are strongly demanded by such an average.
Especially, galvanization bears an important role by the function
with excellent the processing technology.
Diversified surface treatment technology
Metal surface treatment or plating involves a complicated
proc-ess of pre-treatment, various plating procproc-esses, and
post-treat-ment that are considered as the treatpost-treat-ment of base materials, in
addition to other processes depending on each material and
fin-ishing method.
Today, however, stricter quality, improvement in energy
efficien-cy, and process rationalization are required in plating, no matter
how complicated and advanced the process is.
Our new power supply units are one way of comprehensively
re-solving such issues.
The new systems are capable of quickly and efficiently adjusting
optimal electric current required for various kinds of plating,
thus improving plating quality as well as responding to the
needs of the energy saving era.
These new systems greatly reduce noise and pollution as well.
Process of metal-surface treatment
As the technologies of the surface treatment industry quickly
ad-vance, a technology revolution is required in power supply systems.
Power electronics technologies (semiconductor elements for
power supply, conversion technology, and control technology)
that support the technology revolution have been advancing
ev-ery day. In particular, the development of higher frequency
wave-length technology for power supplies completely changed the
concept of conventional power supply for plating. This resulted
in commercialization of the inverter power supply and pulse
power supply systems.
In the future, SanRex will strive for better precision and higher
ef-ficiency, along with development of smaller and lighter devices,
as well as improved energy efficiency and quality through
cen-tralized management of automated plating lines based on micro
controller technology.
tal Surface Treatment
■イメージ図 イーサネット シーケンサ 操作パネル コンピュータ プリンタ 自 動 搬送機 各 種 センサ− その他 周辺機器 ポンプ 液 用 ヒ−タ− SanRexの製品には、DeviceNet等のオープン・ネットワーク通信を業界で はじめて搭載しました。この機能により、パソコンやPLCなどの制御機器と 相互に接続ができ、メカとのマッチングも容易です。今までのリモコンや RS232C等の専用通信による面倒なプログラム開発や専用基板が不要です。 (一部の機種で対応できないものがあります。)In the product of SanRex, the open network communication such as De-viceNet began to appear in the industry and was installed. It is possible to connect by this function the personal computer, the control equipment such as PLC, and between, and the match with mechanism is also easy. Troublesome program development and a special substrate by special communications such as the current remote controls and RS232C are un-necessary.
(There is something that it is not possible to correspond with a part of model. )
Image Operation PC Ethernet Printer DCAUTO MRT MRT-HPR Conveyer Heater Pump Sensor Others PLC オープン・フィールドネットワーク
Open field network
SanRex is developing power supply units for metal surface treatment that keep up with
the rapidly diversifying needs of the electronics industry.
Technology based on more than half a century of development
Reliability improvement & speed up and formation film of productivity. A wavy control that suits a new process is materialized.
The challenge of the road to the process with an infinite possibility is supported.
パルス効果の追及…………生産性の向上/スピードアップ・形成皮膜の信頼性向上
新しいプロセスに適合した波形制御を具体化。
無限の可能性を秘めた未知のプロセスへの挑戦を支援。
We mounted the interface in accordance with an international standard. Therefore the system construction of high
reliability will be achieved in a short time.
オープンネットワーク対応
国際規格に準拠したインターフェース搭載で、垂直立ち上げなどリードタイムの短縮に貢献。
高信頼性のシステム構築を短時間で実現します。
Design based on in depth knowledge of the locus of metal surface processing ensures stable performance over the long term.
長年培ったノウハウの結晶
金属表面処理現場を知り尽くした環境対策設計で、安定した性能を長期間に渡って維持。
A lineup for the inverter power supply with the latest digital control & an efficient electric power semiconductor.
インバータ方式の採用
最新のデジタル制御と高性能な電力半導体でインバータ電源をラインナップ。
ファンの長寿命化と交換を容易に
Fan with a long service life and easy replacement
3
耐環境性向上
Improved environmental durability
出力電流10Aのラボ用から、出力電流最大15,000Aの大容量まで8種類。
It is eight kinds from for the lab of 10A in output current to a large capacity of 15,000A or less in output current.
豊富な標準品シリーズ
A variety of models available in series
The interior is duct structure. Only heat sink is air-cooled.
Elec-tronic components are protected against influence from
envi-ronment in order to maintain stable characteristics for along
time.
内部がダクト構造で、ヒートシンクのみを風冷し、電子部品に周囲
環境からの影響を少なく、長期安定した特性を維持します。
Fan motion is varied by operating and there by fan has longer
life
(mechanically)
and reduced noise. In case of defect, fan is
easily replaced.
運転条件でファンの駆動状態を変化させ、
ファンの長寿命化
(機械的)と、
低騒音化を実現しました。万一、故障時のファンは、容易に交換で
きます。
Power Supply for Metal Su
電
圧
電流
MRS-PR
MRT-HPR
5,000
3,000
1,500
800
500
300
200
40
10A
10V
20V
15V
8V
6V
4V
30V
100A
1,000A
10,000A
15,000
SMR
HK
MRT
GOLDWAVE
(Free waveform)
mode
ゴールドウェーブ
(任意波形)モード
オプションの専用ソフトをお使いいただくと、思い
のままの任意波形出力で運転ができます。
・1サイクルの時間: 5∼150Hz
(6.7ms∼200ms)・波形設定方法: 表計算ソフトによる入力
・1サイクルの分解能: 1サイクルに64点の設定値
独自の高速スッチング回路により、出力電流の極性
切 換 時 間
( 立ち上がり、立ち下がり時 間 )を 5 0μs
TYPと高速化を実現。
The newly developed high-speed
switch-ing circuit has realized high speedswitch-ing of
50+ sec or less of output current polarity
switching time
(rise and fall time)
.
従来の直流電源による
めっき
Conventional plating
by DC power
Through-hole Via-holeMRT-HPRによる
めっき
Plating by MRT-HPR
めっき処理部 Plating areas 過剰めっき Excess plating 均一めっきUniform platingSelectable output waveform mode
出力波形モードも充実
High-speeding of output pulse current
出力パルス電流の高速化
●
DC high-speed pulse control
●
Positive-Reverse high-speed pulse control
●Reversible high-speed switching
●直流高速パルス制御
●PR高速パルス制御
●正逆高速切換
Rev
erse
OA
Normal
正
逆
If dedicated software
(option)
is used,
op-eration with any waveform output
be-comes possible.
• 1 cycle : 5 - 150Hz
(6.7 - 200ms)
• Waveform setting : input by spread sheet software
• 1 cycle resolution : 64 points in one cycle
スルーホール ビアホール
MRT-HPR 出力電流波形
WAVEFORM of MRT-HPR
Idle period ≒0 切換休止期間≒0 Rise time ≒50+s 立ち上がり時間≒50μs Ripple current content rate ≒5% リップル電流含有率≒5%urface Treatment
金属表面処理用電源
13∼14
11∼12
9∼10
5∼8
17∼18
15∼16
19∼20
Products Lineup
DCAUTO
HK
series
MRT
series
MRS
series
SMART
Mini-Rex
SMART
Mini-Rex
SUPER
MINI-REX
SUPER
MINI-REX
SUPER
MINI-REX
SMR
series
MED
series
MRT
-HPR
series
MRS
-PR
series
M Power
21∼22
デジタル直流積算電流計5
Superior model with sophisticated functions
and environmental durability
HK
series
高性能と高耐環境性を実現した最高機種
Remote control pendant
(Option)
遠隔操作用リモコンボックスにも、ジョグダイア ルで簡単操作ができます。HKEにも、専用リモ コンボックスを用意しております。
Remote control pendant is easily operated by a jog dial. An exclusive-use remote control pen-dant is provided also for HKE type.
リモコン
(オプション)
The jog dial is used for output current
and voltage setup. One dial is capable of
digit-by-digit numerical value setup and
moving through values, which allows
easy setup.
出力電流・電圧設定にジョグダイアルを採用
しており各桁の数値設定と桁移動が1つの
つまみで行えるため、条件設定が簡単にでき
ます。
ジョグダイアルで簡単設定
Easy setup with jog dial
Adjust
設定 桁上げ Set up
Push 押す
Units can be piled up to 2 stacks.
*
For more stacks piling, we provide
exclusive-use rack as an option.
2段まで段積みができます。
※多数台収納には、便利な
ラックも用意しています。
積み重ね可能
Pilling up is allowed
ラック 収納参考例 exampleIndividual indication of problems allows
for easy analysis. Buzzer and abnormal
output signal notify of defects.
Continu-ous operation mode is also available in
case of output defects.
異常表示・警報機能で故障を診断
Diagnose defects with abnormality
indicator and alarm
各種トラブル内容の個別表示によりトラブル
解析が容易で、故障時は、ブザー及び出力信
号を送出します。
さらに 、出 力 異
常につ い て は、
運転持続モード
にもできます。
DCAUTO
TYPEHKD
TYPEHKE
特 長
Features
1. 最小1msのパルスモード運転
Pulse mode operation with minimum 1msec pulsation
2. ゴールドウェーブ
(任意波形)
モード
GOLDWAVE
(Free wave form)
mode
3. 高速通信機能
(RS-485)
High speed communication
(RS-485)
4. 電流積算機能
Current integration function
A. Memorized operation
Memorized operation function workable at any set values is provided. 99 patterns of operation parameters can be memorized.
B. Patterned operation
Continuous operation at different parameters memorized in memorized operation.
Memory (Parameters setting) メモリー(条件設定)
99 patterns 99パターン
With operation mode select key, parameters can be set. Memory 1: CV: 8.0V, preset 150AM Memory 2: CC: 150A
As shown above, different parameters are memorized individually and integrated into any operation conditions by one-touch operation.
運転モード選択キーにて、条件設定ができます。 (例)メモリー1にCV設定: 8.0V プリセット: 150AM メモリー2にCC設定: 150A など、異なった運転条件を個々に記憶、ワンタッチで任意の運転条件に設定。
めっき厚管理に有効な8桁表示の電流積算機能を搭載しています。
各パターン運転の電流積算を、時・分・秒の切換ができます。
通電時間タイマーにより通電時間制御ができ、めっき厚管理に効果を発揮します。
A. メモリー運転
任意の設定値で運転できるメモリー運転機能を搭載しています。 99パターンの運転条件を登録できます。B. パターン運転
メモリー運転に登録した条件を準じ連続的に運転できます。 Item 項 目 Item 項 目 Function 機 能 Function 機 能 Individual Preset Counter Setting & Display Preset Counter Display プリセット カウンタ表示 設定・表示範囲 プリセット カウンタ表示 表示範囲 個 別 Total トータル出力波形モードも充実
Selectable output waveform mode
電流積算機能
Current integration function
High speed communication
通電時間タイマー
Energization Timer
運転パターンメモリー機能
Operation pattern memorizing
Power source for metal plating of small capacity
小容量貴金属めっき用電源
C. Single phase full wave mode
Suitable for silver plating.
C. 単相全波モード
銀めっき等に適しています。B. チョッパー
(パルス)モード
・最小1msのパルス出力が設定可能です。 貴金属へのめっきや鉛フリー対応部品へのめっきに 適しています。 ・多台数同期機能搭載(オプション)A. ゴールドウェーブ
(任意波形)モード
オプションの専用ソフトをお使いいただくと、思いのまま の任意波形出力で運転ができます。 ・1サイクルの時間: 5∼150Hz(6.7ms∼200ms) ・波形設定方法: 表計算ソフトによる入力 ・1サイクルの分解能: 1サイクルに64点の設定値 B. チョッパー(パルス)モード Chopper(Pulse) modeOpen Field Network Applicability
(Option)
C. 単相全波モード Single phase full wave mode
RS-485通信機能を標準装備。通信速度最大38,400bpsを実現しました。
高速通信機能
オープン・フィールドネットワークにより、シーケンサ側の簡単なプログラムで
制御できます。世界の主流のオープン・フィールドネットワークに対応しています。
各種オープン・フィールドネットワーク対応
(オプション)
With open field network, it can be controlled by simple program on
sequencer side. It can be applied to most of mainstream open field
networks in the world.
8-digit ampere-hour meter is built in for controlling plating thickness.
Current integrated value in each pattern of operation can be shown as
ampere-second, ampere-minute or ampere-hour.
Energization time can be controlled by a timer for controlling plating
thickness.
ジョグダイアル設定・4桁表示 4桁表示 1∼9999AS/ 1∼9999AM 1∼9999AH(切換による) ジョグダイアル設定・8桁表示 8桁表示 1∼99999999AHSet by jog dial, 4 digit display 4 digit display
(selectable)
Set by jog dial, 8 digit display 8 digit display
B. Chopper
(pulse)
mode
• Minimum 1msec pulsation output is possible.
• Suitable for plating precious ornament and/or lead free soldered
components.
• Synchronized operation of multi-units is possible.
A. GOLDWAVE
(Free waveform)
mode
If dedicated software (option) is used, operation with any waveform
out-put becomes possible.
• 1 cycle : 5 - 150Hz
(6.7 - 200ms)• Waveform setting : input by spread sheet software
• 1 cycle resolution : 64 points in one cycle
RS-485 communication port is equipped. Maximum communication
speed is 38,400bps.
A. ゴールドウェーブモード GOLDWAVE mode
7
製品一覧
Product List
機能一覧
Functions
※1: 外形寸法は外形寸法図の寸法表をご参照ください。
As for dimensions of outer case, see "external dimensions diagram".
※2: 入力電圧を自動認識し、ワンタッチにて切換できます。
Input voltage is automatically recognized and changed by one touch operation.
※3: 150Aは受注生産品です。
150A is product made after received order.
※4: オープン・フィールドネットワークとしては" " " " " "用の それぞれの専用基板があります。
We provide dedicated PCBs for " " " " " " respectively.
Common specification
Input voltage is automatically recognized and changed by one touch operation.
※: 入力電圧を自動認識し、ワンタッチにて切換できます。
共通仕様
Voltage Voltage range Adjustable range PrecisionInput voltage fluctuation Load fluctuation Ripple Control Frequency Control method
制御方式
電 圧
周 波 数
電圧範囲
制 御
調整範囲
精 度
入力電源変動
負荷変動
リップル
100/110/ 200/220/230V 200/220/230/ 380/400/440V 200/220/230V 50/60HzConstant current or constant voltage 0 - Rated value (Current, Voltage)
Rated value ±0.5% or below
RMS 1% or below (of rated value at rated input/output) Rated value ±0.5% or below (output voltage 10 - 100%) ±10% 定電流または定電圧 0∼定格値(電流・電圧) 定格値±0.5%以下 定格値±0.5%以下(出力電圧10∼100%) RMS 1%以下(定格入出力においての定格値に対して)
PWM control switching method
PWM制御スイッチング方式
Single phase 単相 3-phase 三相 Output Voltage出力電圧 Product made after received order 12V 受注生産品 Product made after received order 20V 受注生産品 Product made after received order 4V 受注生産品 Standard Product 15V 標準品 Standard Product 8V 標準品 Output Current 出力電流 10A 20A 30A 50A 100A 150A 200A 300A 0.33 0.63 0.93 1.52 3.05 3.92 5.16 7.74 0.43 0.83 1.23 2.01 3.48 5.16 6.80 − − − − 単相200V(専用)風冷 Forced air cooling
Cタイプ C type Aタイプ A type Cタイプ C type Cタイプ C type Bタイプ B type Bタイプ B type Bタイプ B type 自冷 Natural cooling 自冷 Natural cooling Single phase 単相100/200V
( )
切換 ※2 Changeover Single phase 単相100/200V( )
切換 ※2 Changeover Single phase 単相100/200V( )
切換※2 Changeover( )
切換 ※2 Changeover Three phase 三相200/400V 単相200V(専用) Single phase (Exclusive use)単相200V(専用) Single phase (Exclusive use)
Single phase 200V (Exclusive use)
( )
切換 ※2 Changeover Three phase 三相200/400V 0.26 0.51 0.75 1.22 2.41 3.17 4.18 6.18( )
切換 ※2 Changeover Three phase 三相200/400V 0.18 0.36 0.53 0.84 1.69 2.20 2.86 4.29 0.10 0.19 0.28 0.45 0.88 1.14 1.48 2.22( )
切換 ※2 Changeover Three phase 三相200/400V 入 力 入力kVA 外 形 冷却方式 入 力 入力kVA 外 形 冷却方式 入 力 入力kVA 外 形 冷却方式 入 力 入力kVA 外 形 冷却方式 入 力 入力kVA 外 形 冷却方式 入 力 入力kVA 外 形 冷却方式 入 力 入力kVA 外 形 冷却方式 入 力 入力kVA 外 形 冷却方式 input input kVA Cooling method Outer case ※1 input input kVA Cooling method Outer case ※1 input input kVA Cooling method Outer case ※1 input input kVA Cooling method Outer case ※1 input input kVA Cooling method Outer case ※1 input input kVA Cooling method Outer case ※1 ※3 input input kVA Cooling method Outer case ※1 input input kVA Cooling method Outer case ※1 パネル起動/停止 外部起動/停止 出力調整 CC/CV選択 出力波形選択 デジタル電圧計 デジタル電流計 プリセットカウンタ トータルカウンタ 外部指令 出力電流モニタ 出力電圧モニタ 異常出力 オープンフィールドネットワーク RS-485通信 リモコン制御 ソフトスタート クロスオーバー制御 下点設定 Panel start/stop External start/stop Output adjustment CC/CV selectionOutput waveform selection
Digital voltmeter
Digital ammeter
Preset counter
Total counter
External command
Output current monitor
Output voltage monitor
Abnormal output
Open field network
RS-485 communication
Remote control
Soft start
Crossover control
Initial current setting Model Output current Function モデル名 出力電流 機能 ※4
HKD
10∼300A 20∼300A 10A
HKE
● ● ● ● ● ● ● ● ● ○ ○ ○ ○ ○ ● ○ ● ○ ● ● ● ● ● − ● ● − − ● ● ● ● − − ○ ● ○ ○ − ● ● ● − ● ● − − − − − − − − − − − −Forced air cooling 風冷
風冷 Forced air cooling
100/200V 200V (切換※)(Changeover) (Exclusive use) (専用) 200/400V (切換※)(Changeover) 自冷 Natural cooling Aタイプ A type Aタイプ A type
風冷 Forced air cooling
風冷 Forced air cooling
風冷 Forced air cooling
Aタイプ A type
Aタイプ A type
単相200V(専用) Single phase (Exclusive use)
風冷 Forced air cooling
入力仕様
Input
出力仕様
Output
HK
series
●: 標準装備 Standard ○: オプション対応 Option −: 対応不可 Not available
Ethernet
Ethernet
DCAUTO
(15)
50
HKD
TYPEJog dial
4 digit Display LED Display unit lamp Count reset key Output ON/OFF key
Set key Operation mode select key Waveform mode select key Display mode select key Delete key Main body/ remote select key CC/CV select key 4桁表示LED ジョグダイヤル 運転モ−ド 選択キ− 波形モ−ド 選択キ− CC/CV 選択キ− 表示モ−ド 選択キ− 消去キ− 本体/ リモ−ト選択キ− 表示単位ランプ カウント リセットキ− 出力ON/OFFキ− セットキ− Set key セットキ− Delete key 消去キ− Jog dial ジョグダイヤル CC/CV select key CC/CV 選択キ− Display mode select key
表示モ−ド 選択キ−
Main body/ remote select key
本体/ リモ−ト選択キ−
HKE
TYPE4 digit Display LED
4桁表示LED
Display unit lamp
表示単位ランプ
Output ON/OFF key
出力ON/OFFキ− W(幅) (Width) H(高さ) (Height) D(奥行) (Depth) P1 P2 質量 Weight (kg) ケース 種 類 Type Note Ext.ON/OFF Remote control/ External communication
24V power output (0.1 max.)
Abnormal signal output
Preset count up output signal Preset Counter reset
Total count up output signal
Power output for remote control Power output for remote control
A type
B type
C type
420 420 420 155 155 155 325 500 670 318 318 318 201 381 500 9 14 23Power source for plating of small capacity
小容量貴金属めっき用電源
外形寸法
形 式
External dimension diagram
External connection diagram
ケース寸法 Dimension(mm) W P1 P2 30 穴径 Hole size φ8.2 D
HKD
Control terminal 制御端子 Control terminalHKE
制御端子 Rear surface本体裏面
外部入・切(※2) リモコン/外部通信機能 24V電源出力(0.1A以下) 異常信号出力 (+) (−)Output voltage signal 0- (rated voltage)
Output current signal
(0-60mV) (+) (−) プリセットカウントアップ 出力信号(※1) プリセットカウント リセット(※2) トータルカウントアップ出力信号(※1) ●※3: ここに供給する信号は、DC30V、20mAが開閉可能な接点信号を使用してください。
For actuation, use a contact signal which is capable of switching on/off DC 30V 20mA.
●CP-CNとVP-VN間は、非絶縁です。
CP and CN, and VP and VN are not insulated.
●RS-CO間に供給する信号は必ず絶縁したものを使用してください。
The signal given between RS and CO must be insulated.
リモコン用電源出力 (−) リモコン用電源出力 (+)
Ext. ON/OFF
Common Output setting signal input
External adjustor
Operation LED ON output (1W max.)
外部入・切(※3) CV/CC Select (Open: CC) CV/CC切換(オープン時CC) コモン 外付けボリューム 運転用LED 点灯出力(1W以下) 5kΩ 0.5W 出力設定信号入力(0∼5V)
注意
Note●※1: 接点定格は、AC125V 0.5A/DC24V 0.5A(抵抗負荷)です。
Contact rating is AC125V 0.5A/ DC24V 0.5A (Resistive Load)
●※2: ここに供給する信号は、DC30V 20mAが開閉可能な接点信号を使用してください。
For actuation, use a contact signal which is capable of switching on/off DC 30V 20mA.
注意
出力電圧信号 0∼(定格電圧) 出力電流信号 (0∼60mV)
How to read the model
HKD-15100F
D: HKD type
E : HKE type
ex) 8 ··· 8V
15 ··· 15V
Rated output current
ex) 10 ··· 10A
50 ··· 50A
100 ··· 100A
Rated output voltage
定格出力電圧 定格出力電流
外部接続
POWER ******* V E E0 S T OPTION R INPUT TYPE OUTPUT SANSHA ELECTRIC MFG.CO.,LTD SERIAL No. *******MADE IN JAPAN **PHASE 50/60Hz ******* V
******* V *** A
**********
Connect the earth wire
Risk of electric shock 感電のおそれあり
アース線を接続せよ
単相用
Single-phase Three-phase三相用
入力スイッチ
Input switch Touch panelタッチパネル
PANEL REMOTE CC CV PANEL SET CONFIG CLEAR SLOPETIME REMOTE STOP START SET/RUN S VA H SELECT DISP VA CV V/A M % CC Control terminal Option PCB slot
Option function adjusting part Cooling fan cover Input terminal
制御端子 オプションカードスロット オプション機能/調整部分 冷却ファン扉 入力端子 Output terminal 出力端子 DC-AUTO mS A % RESET COUNT VA H M VA S NORMAL MEMORY PATTERN CONFIG CHOP CONST S.W. H-L PRESET/COUNT TOTAL TIME/COUNT SET/RUN MODE OUTPUT SLOPETIME PERIOD MODE OPR CV V/A CC SELECT DISP MEMORY No. STOP START REMOTE CLEAR SET PANEL CC CV PANEL REMOTE DC-AUTO H (※3) 52.5
9
2.
ワールドワイド入力電圧に対応
●標準200V∼220V仕様に加えて、海外向け380∼440V仕様をラインナップ
Applicable to various input voltage for worldwide.
Lineup to 200 - 220V & 380 - 440V.
3. デジタル化による機能向上
●運転前に出力設定が可能(リセット機能)
●高精度化により±0.5%対応可能(オプション)
Function improvement by the digital technology.
Specification
仕 様
出 力
入力電圧
出力範囲
入力容量
制御方式
定格・冷却方式
定電圧制御精度
定電流制御精度
電流脈動率
形 式
Type MRT-10005B MRT-15005B MRT-10010B MRT-15010B MRT-10015B MRT-15015B MRT-10020B MRT-15020B MRT-10030B10V-500A 15V-500A 10V-1000A 15V-1000A 10V-1500A 15V-1500A 10V-2000A 15V-2000A 10V-3000A
6.5kVA 11.1kVA 13kVA 20.4kVA 20kVA 30.2kVA 26kVA 40.7kVA 39.5kVA
Remote control pendant
リモコン
Features
特 長
Defect diagnosis by abnormality indication and alarm function.
6. 異常表示・警報機能で故障を診断
●各種トラブル内容の個別表示によりトラブル解析が容易 Contents of troubles/defects are individually shown and therefore trouble-shooting is easy.
設置場所
周囲温度
相対湿度
標 高
Location Ambient temperature Relative humidity Altitude Working condition使用条件
電圧、電流共 定格値の10∼100% IGBTによるスイッチングレギュレータ制御 連続・強制風冷 定格直流電圧の±3%以内 定格直流電流の±3%以内 5%以下(300/360Hz成分) 屋内 0℃∼40℃ 30%∼85% 1000m以下PWM inverter controlled by IGBT Continuous / Forced air cooling Within ±3% of rated DC voltage Within ±3% of rated DC current 5% or below (300/360Hz component) Indoors
1000m or below
Voltage & Current: 10 to 100% of the rated value 出力が15Vの場合は 15 、出力が20Vの場合は 20 になります。 If output: 15V → 15005, If output: 20V → 20005
4. デザイン一新、リモコンにはジョグダイアルを採用し、使いやすさを向上
●出力電流・電圧設定にジョグダイアルを採用
●各桁の数値設定と桁移動が一つのつまみで行えるため、条件設定が簡単にできます。
New Design. Easy setting by jog dial on remote control pendant.
A jog dial employed to set output current and voltage.
By rotating jog dial, value in each figure can be adjusted, and then by pushing jog dial the value is set and moved up to next figure.
・ ・
5. 耐環境性向上
●当社独自のコーティング処理により、密閉性、耐環境性を強化。 ●周囲環境からの影響も少なく、長期安定した特性を維持します。
More durable against severe environment.
Tightly sealing treatment or coating treatment has improved environment proof quality. Power source are protected against influence from environment in order to maintain stable characteristics for a long time.
・ ・
Abundant Lineup.
1.
豊富なラインナップ
●出力電圧: 10/15/ 20V ●出力電流: 500/1000/1500/2000/3000A Output voltage: 10/15/20VOutput current: 500/1000/1500/2000/3000A ・ ・ ・ ・
Optional function
7. 充実したオプションを用意しています。
●ゴールドウェーブ(任意波形)出力モードへの対応。 ●電流積算機能 ●オープン・フィールドネットワーク対応 ●高速通信機能(RS-485) ●運転パターンメモリー機能If dedicated software and I/F is used, operation with any waveform output becomes possible. Current integration function
Open Field Network Applicability High Speed Communication Operation pattern memorizing ・ ・ ・ ・ ・ Output Input voltage Output range Input capacity Control Rated, Cooling Constant voltage control accuracy Constant current control accuracy Current ripple factor
MRT
series
SMART Mini-Rex
三相 3-phase AC200/220V ±10% or AC380/400/440V ±10% 50/60Hz
Output setting is possible before operation. (Preset function) Output precision can be ±0.5% or below. (Option)
IGBT inverter type power source for various platings
各種めっき用インバータ電源
仕 様
Specification
形式 Type 出力 Output 質量 (kg) Weight 出力端子図 Output terminal 寸法(mm)OutlineC
D
E
A1
A2
C1
B
A
External dimension diagram
外形寸法・外形図
(mm)MRT-10005B
10 ···· 10V 15 ···· 15V
20 ···· 20V Rated output current定格出力電流 Rated output voltage
定格出力電圧 B ···· 200/220V BY ···· 380/400/440V Input voltage 入力電圧 005 ···· 010 ···· 015 ···· 020 ···· 030 ···· 500A 1000A 1500A 2000A 3000A
How to read the model
形 式
Output terminal
出力端子図
(mm) 注意ラベル C1 入力ケーブル 出力端子(+) 出力端子(−) 接地端子 A2 A1 Caution label Earth terminal Output terminal Input cableAir intake Air intake
吸気 Air intake 吸気 R S T E B Exhaust 排気 吸気 リモートコントロール用コンセント 通信状態(オプション) 異常 運転 入力スイッチ 型式 制御信号ケーブル 引込口 通信ケーブル引込口(オプション) 4-φ15 A D Control cable Inlet (Option)
Network status Alarm lamp
Power lamp
Model Input switch
Network cable inlet (Option)
Remote control socket MSMS SMART MiNi-Rex SD ERR NS RDRUN NS ALARM POWER φ15 25 90 160 25 50 15 45 75 15 45 4 -φ15 20 60 20 60 100 4-φ15 4-φ15 20 60 20 60 100 Output terminal 4桁表示LED
4digit display LED
MRT-10005B
MRT-15005B
MRT-10010B
MRT-15010B
MRT-10015B
MRT-15015B
MRT-10020B
MRT-15020B
MRT-10030B
250 250 250 250 250 360 360 360 360 450 450 450 450 450 570 570 570 570 600 600 600 600 600 750 750 900 900 210 210 210 210 210 320 320 320 320 260 260 260 260 260 380 380 380 380 71 71 71 71 71 80 80 80 80 138 138 138 138 138 230 230 230 230 148 148 148 148 148 180 180 180 180 40 48 48 55 55 89 89 112 112 (1) (1) (2) (2) (2) (2) (3) (3) (4) 10V- 500A 15V- 500A 10V-1000A 15V-1000A 10V-1500A 15V-1500A 10V-2000A 15V-2000A 10V-3000A (1)Cu t=10 (2)Cu t=10 (3)Cu t=10 (4)Cu t=20 ジョグダイヤル Jog dial 本体/リモート選択キーBody / Remote select key
表示 単位表示
Display unit lamp
表示モード選択キー Display mode select key 運転スイッチ Operation switch セットキー Set key CC/CV選択キー CC/CV select key ■ 標準ケーブル 10m(Max.30mまで可能)
A 10-meter cable is attached (it can be extended up to 30 meter).
リモコン Remote control pendant Air intake 吸気 C 130 160
11
Power monitor screen
7. 計測モニタ機能
本体にRS-485の通信ポートを標準装備しており、複数の電源を同時にパソコンにて 制御。また電源の出力モニタや電流積算等の表示が可能。さらに、実験用として出力
条件等の複雑な設定も容易にできるパソコン用ソフトも準備。(オプション)
Measurement monitoring function
The main body is furnished with RS-485 communication port as standard specification, and multiple power sources can be controlled from a personal computer. Also, it is able to monitor the power output and to display the total current, etc. thereby assuring relia-bility in use. Further, a personal computer software capable of easily setting the output condition, etc. is available to be used for experiment. (Option)
8. プログラム運転機能
正逆極性それぞれのパルスピーク電流値・パルス幅・めっき時間の組合わせを1パタ ーンとして、10パターンまでを記憶し、それぞれのパターンを順次組合わせたプログ ラム運転が可能。3. 出力電流中に含まれるリップル成分を減少
出力電流に含まれるリップル電流成分は、めっきの光沢不足になりがちです。本装置 では、高周波インバータ回路技術によって、リップル含有率を5%以下まで低減し、光 沢不足を解消。Reduction of ripple of output current
Output ripple current may cause insufficient glossing of the plated surfaces. This device has reduced the ripple content to 5% or less solving the problem of insufficient glossing due to the high frequency inverter circuit technology.
4. 豊富なシリーズ
出力電流40Aのラボ用から、出力電流最大800Aの大容量まで5種類。
Abundant series
There are abundant series in 5 types ranging from laboratory type of 40A output current to large-capacity type of 800A max.
5. 出力波形の切換が可能
直流出力、正側のみのパルス出力、正逆のパルス出力などを自由に選択使用ができ、 目的に応じた使い方ができます。
Output wave form switching possible
It is free to select the DC output , pulse output of positive side only, and positive/reverse pulse output according to the purpose.
6. 同期運転機能による並列運転
この電源は、同期運転機能採用により、複数台の並列運転も可能。めっき物の表裏で
の均一性や大型めっき物などの品質の安定が得られます。(オプション)
This power source employs a synchronous operation function and is able to perform par-allel operation by multiple units. It assures uniform plating on the surface and back of the object and high-quality stable plating of large-sized objects. (Option)
Parallel operation by synchronous operation function
Program operation function
It stores up to 10 patterns in the memory, one pattern including a combination of nor-mal/reverse pulse peak current value, pulse width and plating time of each normal/re-verse polarity. and it is possible to perform program operation with individual patterns combined in order.
2. 出力電流の極性切換時に休止期間が発生しない
No generation of idle period during output current polarity
switching operation
In switching the output current pulse polarity, an idle period has been momentarily gen-erated in a conventional method, but there is no such idle period in this new method re-alizing high-quality plating.
出力電流のパルス極性を正逆に切り換える場合、従来方式では一瞬休止期間が発生 していましたが、この休止期間を無くし、めっきの高品質化を実現。
電源モニタ画面
Plating time
Example of program operation
Output current Pattern 3 Pattern 1 Pattern 2 Rev erse OA Normal 正 出力電流 めっき時間 プログラム運転例 逆
1. 出力パルス電流の高速化
(50μs TYP)High-speeding of output pulse current
(50+s or less)P.4 参照Refer to 4 pages RM21TR-15P RM21TR-15S RM15TRH-10SRM15TRH-10PH RM21TR-15P RM21TR-15S F2035EW RM21TR-15P RM21TR-15S
Features
特 長
Remote control pendant
(Option)
リモコン
(オプション)
P.4 参照Refer to 4 pages
MRT-HPR
series
MRT-8001HPR
正極ピーク電流
逆極ピーク電流
定電流制御精度
正極パルス幅
逆極パルス幅
正逆電流切換時間
正極電圧尖頭値
逆極電圧尖頭値
正逆パルス比
40A 100A 500mm 277mm 450mm 50kg 360mm 750mm 570mm 80kg 360mm 800mm 670mm 120kg 360mm 900mm 770mm 170kg 300A 900A 500A 1500A 100A 300A入力電圧
主回路方式
定格・冷却方式
動作周囲温度
質 量
幅
高さ
奥行
(W) (H) (D)MRT-800.4HPR
MRT-8001HPR
MRT-8003HPR
MRT-8005HPR
仕 様
Specification
出 力
Output形 式
TypeNormal peek current Reverse peek current
Constant current control accuracy Normal polarity pulse width Reverse polarity pulse width Normal/reverse current switching time Normal polarity voltage peak value Reverse polarity voltage peak value Normal/reverse pulse ratio Input voltage
Main circuit system Rated, Cooling
Ambient temperature for operation Width Height Depth Weight
寸 法
DimensionsHow to read the model
形 式
4-φ 13 30 10 75 75 10 30 30 (-) (+) WPOWER OUTPUT ALARM POWER NS MS
MASTER DROP PC/RC SIGNAL SIGNAL DEVICE NET INPUT OUTPUT 500 電 源 運 転 電 源 故 障 RM21TR-15P RM21TR-15P RM21TR-15S RM21TR-15S RM15TRH-10SRM15TRH-10SRM15TRH-10PHRM15TRH-10PH RM21TR-15P RM21TR-15P RM21TR-15S RM21TR-15S F2035EWF2035EW RM21TR-15P RM21TR-15P RM21TR-15S RM21TR-15S E 入力 AC200V PC/RC信号入出力 マスタ−ドロップ出力 同期信号入力同期信号出力 EX T S R PB RE 注 意 より接地してください2mm感電の恐れがありますので、 以上の線にてE端子2 MRT-500.4HPR 製造 --A --A --A --Hz --V --V 負側 正側 --V -φ --kVA 株式会社三社電機製作所 形式 質量 製造番号 (ピ−ク) 高速パルス電源 出力 入力 --kg 出力 + -250 450 吸気 D 吸気 吸気 排気 T S R
External dimension diagram
外形寸法・外形図
(mm)MRT-800R4HPR
MRT-8001HPR
・MRT-8003HPR・MRT-8005HPR・MRT-8008HPR
Air intake Air intake 吸気 Air intake Exhaust 入力ケーブル Input cabl Air intake 吸気 Air intakeHigh-accuracy plating high-speed PR
(Positive-Reverse changeover)
pulse power source
高精度めっき用高速PR
(正逆反転)
パルス電源
8 ···· 8V
00.4 ···· 40A 001 ···· 100A Rated output voltage
定格出力電圧 ±3.0% 10∼99.9ms 0.1∼2.0ms 50μs(TYP) 8V 15V 5 :1以上 三相 3-phase AC200/220V ±10% 50/60Hz IGBT PWM インバータ方式 連続・強制風冷 0∼40℃ 5 : 1 or over
PWM inverter controlled by IGBT Continuous/Forced air cooling
H
正極 ピーク電流 Normal peek current
003 ···· 300A 005 ···· 500A
13
1. 耐環境性・耐久性が一段と向上
高性能絶縁サイリスタ、エポキシ封止形特殊変圧器の採用および心臓部である制御回 路の密閉化により、耐環境性・耐久性が一段と向上。
Hight-quality and environment-proof
Environment-proof quality has been improved due to introducing a first-rate insulation type thyristor, epoxy-sealed special transformer, and tightly closed up control circuit – one of its key components.
2. 省エネタイプ
大容量低損失マルチダイオード(500A)を採用、内部構成を簡素化し、省エネルギー
化を実現。
Energy-saving type
The MRS series incorporates a large-capacity low-loss multi diode (500A) to simplify the internal makeup, resulting in saving energy.
3. 小形・軽量、省スペースの実現
冷却構造を徹底的に追求し、小形・軽量化を実現。特に前幅寸法をおさえ、据付床面 積を低減した省スペースを実現。 もちろん同一寸法のケースでは、2段積みが可能。
(但し、5,000A以下)
Compact, light, and space-saving
SanRex unique cooling system produces an extremely light compact product. The front dimension is reduced, therefore requiring less floor area and thus saving space. A unit can be mounted on another unit of the same size (up to 5,000A).
4. 充実した保護機能を装備
●定電圧運転時における電流制限機能回路、定電流運転時における電圧制限機能回 路の内蔵により、整流器を保護。 ●温度異常検出装置の内蔵により、ファン停止等、冷却関係の異常に対して整流器を 保護。 ●整流器が運転されていない時にはファンを停止。Complete protection functions
The rectifier is protected by either of its built-in circuits; a current-limiting circuit that functions under constant voltage operation or a voltage-limiting circuit that functions under constant current operation.
The rectifier is protected against problems in the cooling system by a built-in abnor-mal temperature detector in case of a fan failure or the like.
The fan stops when the rectifier is not running. • • •
Specification
仕 様
特 長
出 力
入力電圧
出力範囲
入力容量
制御方式
定格・冷却方式
形 式
Type Output Input voltage Output range Input capacity Control Rated, Cooling12V-500A 12V-1000A 12V-1500A 12V-2000A 12V-3000A 12V-4000A 12V-5000A 12V-6000A 12V-7000A 12V-8000A 12V-10000A 12V-12000A 12V-15000A
7kVA 16kVA 24kVA 32kVA 47kVA 63kVA 77kVA 94kVA 109kVA 125kVA 158kVA 191kVA 239kVA Voltage: 1/3 - rated voltage, Current: 10 to 100% of the rated current
Thyristor-based continuous step less control Continuous / Forced air cooling
• • • • • •
5. 制御機能
●ソフトスタート機能 ●CV-CC切換設定機能 ●電圧下点設定機能 ●電流下点設定機能 ●定電流密度設定機能 ●出力電圧、出力電流独立設定機能(クロスオーバー制御)[オプション]Efficient control functions
Function for soft start
Function for setting CV–CC changeover Function for setting lower limit of current Function for setting lower limit of voltage Function for setting constant current density
Function for independently setting output voltage and output current (crossover control) optional.
出力が8Vの場合は 8005 、出力が15Vの場合は 15005 になります。 If output: 8V → 8005, If output: 15V → 15005
Remote control pendant
リモコン
電圧 1/3∼定格電圧 / 電流 定格電流の10∼100% サイリスタによる連続無段階制御 連続・強制風冷MRS
series
SUPER MINI-REX
三相 3-phase AC200V ±10% 50/60Hz MRS-12005 MRS-12010 MRS-12015 MRS-12020 MRS-12030 MRS-12040 MRS-12050 MRS-12060MRS-12070MRS-12080MRS-12100 MRS-12120 MRS-12150Power supply units for various automatic platings
各種めっき用サイリスタ電源
External dimension diagram
外形寸法・外形図
(mm)MRS-12050
8 ···· 8V 12 ···· 12V
15 ···· 15V Rated output current 定格出力電流 Rated output voltage
定格出力電圧 040 ···· 050 ···· 060 ···· 070 ···· 080 ···· 4000A 5000A 6000A 7000A 8000A 100 ···· 120 ···· 150 ···· 10000A 12000A 15000A
How to read the model
形 式
Output terminal
出力端子図
(mm) A2 A1 C2 C1 入力線 75 E 75 B 出力端子 接地端子 15V 0 A V ALARM OP CC CV A VTIME ADJ. BOT.POINT DENSITY
OUTPUT ADJ. OFF ON A D Earth terminal Control terminal 4-φ15 Cable inlet リード入線孔 SL 制御端子 出力電圧レベル計 Output voltage level meter 異常表示灯 Trouble indicator 運転表示灯 Operation indicator 定電圧−定電流切換器 Constant voltage - constant current changeover switch ソフトスタート時間調整器
Soft start time regulator
運転スイッチ
Operation switch
「電圧計」表示灯
"Voltmeter" indicator lamp
「電流計」表示灯
"Ammeter" indicator lamp
電圧計−電流計切換器 Voltmeter - Ammeter changeover switch 定電流密度調整器 Constant current density regulator 下点調整器 Lower regulator 出力調整器 Output regulator リモコン Remote control pendant Exhaust 排気 Input cable Output terminal C 005 ···· 010 ···· 015 ···· 020 ···· 030 ···· 500A 1000A 1500A 2000A 3000A 50 80 25 φ15 4-φ15 9 -φ20 4-φ15 4-φ20 130 45 15 75 20 35 45 15 25 150 100 60 60 20 80 35 150 80 200 200 80 3 5 150 80 35 4 -φ20 130 35 200 65 65 35 250 (1)AR t=10 (2)AR t=6×2P (3)AR t=10×2P (4)AR t=10×2P (5)AR t=10×2P (6)AR t=15×2P (7)AR t=20×2P (8)AR t=20×3P (9)AR t=20×3P (10)Cu t=20×3P 4-φ20 35 80 35 150 80 200 ■ 標準ケーブル 10m(Max.30mまで可能)
A 10-meter cable is attached (it can be extended up to 30 meter).
仕 様
Specification
形式 Type 出力 OutputMRS-12005
MRS-12010
MRS-12015
MRS-12020
MRS-12030
MRS-12040
MRS-12050
MRS-12060
MRS-12070
MRS-12080
MRS-12100
MRS-12120
MRS-12150
300 330 330 450 450 530 530 650 700 700 700 800 800 500 550 550 650 650 700 700 950 1000 1000 1000 1100 1100 700 850 850 1100 1100 1450 1450 1450 1550 1550 1550 1750 1750C
240 270 270 390 390 470 470 550 600 600 600 700 700D
340 390 390 490 490 540 540 790 840 840 840 940 940E
60 155 155 220 220 185 185 230 240 240 240 290 290A1
100 230 230 295 295 265 265 400 440 440 440 490 490A2
305 355 355 475 475 560 560 640 710 710 710 785 785C1
400 635 635 640 640 840 840 900 1025 1025 1025 1125 1125C2
90 140 160 240 270 420 450 630 850 920 1000 1300 1500 (1) (2) (3) (4) (5) (6) (6) (7) (8) (8) (9) (9) (10)B
A
12V- 500A 12V- 1000A 12V- 1500A 12V- 2000A 12V- 3000A 12V- 4000A 12V- 5000A 12V- 6000A 12V- 7000A 12V- 8000A 12V-10000A 12V-12000A 12V-15000A出力が8Vの場合は 8 、出力が15Vの場合は 15 になります。 If output: 8V → 8, If output: 15V → 15
質量 (kg) Weight 出力端子図 Output terminal 寸法(mm)Outline
Remote control pendant
リモコン
MRS-12005PR
15
Specification
仕 様
特 長
転極方式は完全自動の無接点転極方式を採用していますので、極性切換の信頼性が 高まり、PR電源としての性能を充分に発揮します。1. 高信頼性の無接点転極方式
A highly reliable non-contact pole changing system
A fully automatic non-contact pole changing system is adopted so that reliable pole change is able to function best as a PR power source.
正・逆とも電流は自由かつスムーズに調整でき、正・逆とも60秒の任意の時間設定が できます。また直流のみで使用することができますので、PRのいらないめっきにも使 用できます。
2. 正・逆ともスムーズな出力調整
The current can be freely and smoothly adjusted either
to forward operation or backward operation
The current can be freely and smoothly adjusted either to forward operation or backward op-eration, and a 60-second time setting can be arbitrarily made. The product can be used with direct current only so that it can be also used for plating for which no PR is necessary.
形 式
Type Output Input voltage Output range Input capacity Control Rated, Cooling 12V-500A7kVA 16kVA 24kVA 32kVA 47kVA 63kVA 77kVA
12V-1000A 12V-1500A 12V-2000A 12V-3000A 12V-4000A 12V-5000A
MRS-12010PR MRS-12015PR MRS-12020PR MRS-12030PR MRS-12040PR MRS-12050PR
出 力
入力電圧
出力範囲
入力容量
制御方式
定格・冷却方式
出力が8Vの場合は 8 、出力が15Vの場合は 15 になります。 If output: 8V → 8005PR, If output: 15V → 15005PR
電圧 1/3∼定格電圧 / 電流 定格電流の10∼100%
サイリスタによる連続無段階制御 連続・強制風冷
Voltage: 1/3 - rated voltage, Current: 10 to 100% of the rated current
Thyristor-based continuous stepless control Continuous / Forced air cooling
三相 3-phase AC200V ±10% 50/60Hz
3. 耐環境性・耐久性が一段と向上
高性能絶縁サイリスタ、エポキシ封止形特殊変圧器の採用および心臓部である制御回 路の密閉化により、耐環境性・耐久性が一段と向上。
Hight-quality and environment-proof
Environment-proof quality has been improved due to introducing a first-rate insulation type thyristor, epoxy-sealed special transformer, and tightly closed up control circuit – one of its key components.
4. 省エネタイプ
大容量絶縁形サイリスタ(400A)を採用、内部構成を簡素化し、省エネルギー化を実現。
Energy-saving type
The MRS-PR series incorporates a large capacity isolated thyristor (400A) to simplify the internal makeup, resulting in saving energy.
5. 小形・軽量、省スペースの実現
冷却構造を徹底的に追求し、小形・軽量化を実現。特に前幅寸法をおさえ、据付床面 積を低減した省スペースを実現。 もちろん同一寸法のケースでは、2段積みが可能。
(但し、5,000A以下)
Compact, light, and space-saving
SanRex unique cooling system produces an extremely light compact product. The front dimension is reduced, therefore requiring less floor area and thus saving space. A unit can be mounted on another unit of the same size (up to 5,000A).
7. 制御機能
Efficient control functions
6. 充実した保護機能を装備
●定電圧運転時における電流制限機能回路、定電流運転時における電圧制限機能回 路の内蔵により、整流器を保護。
●温度異常検出装置の内蔵により、ファン停止等、冷却関係の異常に対して整流器を保護。 ●整流器が運転されていない時にはファンを停止。
Complete protection functions
The rectifier is protected by either of its built-in circuits; a current-limiting circuit that functions under constant voltage operation or a voltage-limiting circuit that functions under constant current operation.
The rectifier is protected against problems in the cooling system by a built-in abnor-mal temperature detector in case of a fan failure or the like.
The fan stops when the rectifier is not running.
●ソフトスタート機能 ●CV-CC切換設定機能 ●電圧下点設定機能 ●電流下点設定機能 ●定電流密度設定機能
Function for soft start
Function for setting CV–CC changeover Function for setting lower limit of current Function for setting lower limit of voltage Function for setting constant current density
MRS-PR
series
仕 様
Specification
形式 Type Capacity容量MRS-12005PR
MRS-12010PR
MRS-12015PR
MRS-12020PR
MRS-12030PR
MRS-12040PR
MRS-12050PR
300 330 330 450 450 530 530 500 550 550 650 650 700 700 700 850 850 1100 1100 1450 1450C
240 270 270 390 390 470 470D
340 390 390 490 490 540 540E
150 155 115 220 220 185 185A1
190 230 230 295 295 265 265A2
290 355 355 475 475 560 560C1
500 635 635 640 640 840 840C2
95 150 180 250 300 450 480 (1) (2) (3) (4) (5) (6) (7)B
A
12V- 500A 12V-1000A 12V-1500A 12V-2000A 12V-3000A 12V-4000A 12V-5000AExternal dimension diagram
外形寸法・外形図
(mm)MRS-12050PR
8 ···· 8V 12 ···· 12V
15 ···· 15V Rated output current 定格出力電流 Rated output voltage
定格出力電圧 005 ···· 010 ···· 015 ···· 020 ···· 030 ···· 040 ···· 050 ···· 500A 1000A 1500A 2000A 3000A 4000A 5000A
How to read the model
形 式
Output terminal
出力端子図
(mm) 出力が8Vの場合は 8 、出力が15Vの場合は 15 になります。 75 E 75 A D B A2 A1 C2 C1 C MCB 接地端子 4-φ15 Cable inlet リード入線孔 SL 制御端子 R S T 10 9 8 7 6 5 4 3 2 1 0 10 9 8 7 6 5 4 3 2 1 0 100 700 600 660 130 4-φ7 逆 正逆 切換 VRR VRF CS DA TM DV LED1,2 COS1,2 出力調整逆 出力調整正 定電流 切 定電圧 切換 入 出力 電源 警報 リモコン Remote control pendant Control terminal Earth terminal 入力線 Input cable Exhaust 排気 出力端子 Output terminal 50 80 25 φ15 8-φ20 4-φ20 4-φ15 4-φ15 (1)AR t =10 130 45 15 75 45 (2)AR t =6×2P (3)AR t =10×2P 150 100 60 20 60 20 (4)AR t =10×2P 200 80 80 35 (7)AR t =20×2P 80 35 15 0 15 0 80 35 35 200 (5)AR t =10×2P (6)AR t =15×2PFor electro decreasing chromium plating
電解脱脂用/硬質クロムめっき用サイリスタPR整流器
質量 (kg) Weight 寸法(mm)Outline 出力端子図 Output terminal If output: 8V → 8005PR, If output: 15V → 15005PR 2517
2. 高精度
定電圧・定電流ともに1%以下。
High accuracy
Both voltage and current are 1% or less for constant.
3. デジタル電圧/電流表示器 標準搭載
Equipped with digital voltage and current display as standard
4. 外部制御機能 標準搭載
外部信号によりON/OFF、CV/CC切換、出力調整が可能。
Availability of control by external signals as standard
ON/OFF, CV/CC change, and output conditioning are possible by an external signal.
5. リモコンボックス
(オプション)Remote controller Pendant
(Option)特 長
Features
用 途
Application
1. 出力電圧6V
出力電流300/600/750/1000/1200/1500A
Output voltage 6V,
Output current 300/600/750/1000/1200/1500A
●プリント配線板めっき
●電子部品電極めっき
●
Printed-wiring board plating
●
Electronic parts electrode plating
●半導体ウェハ表面処理
●貴金属装飾めっき
●
Semiconductor wafer surface treatment
●
Noble metal decorative plating
出力
INV
+
−
入力
Output InputCircuit configuration
回路構成
SMR
series
SMART Mini-Rex
482 418
External dimension diagram
外形寸法・外形図
(mm) (A) SMR300SP SMR600SP SMR750SP (B) SMR1000SP SMR1200SP SMR1500SPRack mount type power supply for metal surface processing
ラックマウントタイプ金属表面処理用電源
形 式
How to read the model
SMR-6003SP
OUTPUT V A SMART Mini-Rex 600SP POWER SET INPUTPRESET STOPSTART
CC CV CVCC POWER OUTPUT V A SET INPUT PRESET STOP START CC CV CVCC Output (Cu50×6) 560 80 160 212 (1 2) (2 2) 50 25 86 20 60 Output (Cu100×10) 95 60 60 82 482 418 2-φ 15 8-φ 15 424 560
Rated output current定格出力電流 003 ···· 006 ···· 010 ···· 300A 600A 1000A 012 ···· 015 ···· 1200A 1500A 定格出力電圧
Rated output voltage 6 ···· 6V
仕 様
Specification
10.5kVA 6V 1000A 6.0kW三相 3-phase AC200/220V ±10% or AC380/400/460V ±10% 50/60Hz
3.2kVA 300A 1.8kW 6.2kVA 600A 3.6kW 12.5kVA 1200A 7.2kW 15.7kVA 1500A 9.0kW At 10 to 100 % of rated voltages (for constant voltage operation) At 10 to 100 % of rated currents (for constant current) Ao kind100 % continuous rating (Confirming Japanese standard.) Switching mode
Within 1.0% of rated output voltage Within 1.0% of rated output current 3% P-P or less (Commercial component) 5MΩ or more (By DC 500V megger)
Main circuit primary side - secondary side 200V/1 min. Main circuit primary side - ground 2000V/1 min. Main circuit secondary side - ground 500V/1 min. Continuous / Forced air cooling
Indoors(place not exposed to wind and rain and direct sunshine)
1000m or below 入力電圧 入力容量 定格出力電圧 定格出力電流 定格出力電力 出力調整範囲 絶縁抵抗 絶縁耐電圧 定格・冷却方式 Insulation resistance Withstand voltage Rated, Cooling 設置場所 周囲温度 相対湿度 標 高 電気的仕様 Electrical specification Input voltage Capacity
Rated output voltage Rated output current Rated output power Range of output Conditioning
Location Ambient temperature Relative humidity Altitude Weight
SMR-6003SP
SMR-6006SP
SMR-6010SP
SMR-6012SP
SMR-6015SP
定 格 出力調整方式 定電圧精度 定電流精度 電流脈動率 RatingsOutput conditioning method Constant voltage control accuracy Constant current control accuracy Current ripple factor
質 量 Working condition 使用条件 定格電圧の10∼100%(定電圧運転時) 定格電圧の10∼100%(定電流運転時) Ao種 100%連続定格 スイッチング式 定格出力電圧の1.0%以内 定格出力電流の1.0%以内 3% P-P以内(商用成分) 5MΩ以上(DC 500Vメガーにて) 主回路1次∼2次間 2000V/1分間 主回路1次∼アース間 2000V/1分間 主回路2次∼アース間 500V/1分間 連続・強制風冷 屋内(雨風、直射日光にさらされない場所) 0∼40℃ 30∼85% 1000m以下 30kg 65kg 形 式 Type
