TECHNICAL BULLETIN
[ 1 / 3
]
HEAD OFFICE : TOKYO BUILDING, 2-7-3 MARUNOUCHI, CHIYODA-KU, TOKYO 100-8310, JAPAN NAGOYA WORKS : 1-14 , YADA-MINAMI 5-CHOME , HIGASHI-KU, NAGOYA , JAPAN
Thank you for your continued support of Mitsubishi Electric programmable controllers.
As of July 22, 2017, product range that are subject to the EU RoHS Directive will be expanded, and the CE marking is accordingly to be affixed on certain models of Mitsubishi Electric programmable controllers, MELSEC series products. There is no impact on the general specifications, performance specifications, functions, and external dimensions of products due to the change.
1
Reason for the change
As of July 22, 2017, products defined in "Category 9 Industrial monitoring and control instruments" of the EU RoHS Directive will be subject to this directive. Accordingly the CE marking is to be affixed on the relevant products since CE marking is required for the EU RoHS Directive compliant products.
2
Relevant products and details on the change
The CE marking and address are indicated on the EU RoHS Directive compliant products. The corporate logo on certain products will also be changed along with the indication.
Position of the marking and descriptions differ depending on the products. In addition, position of the descriptions may be changed due to limitations of space.
[Issue No.]
FA-A-0237-A
[Title]
Additionally affixing the CE marking on the products that are compliant
with the EU RoHS Directive
[Date of Issue]
June 2017 (Ver. A: October 2017)
[Relevant Models]
MELSEC series
Relevant product Before change After change
Connector/terminal block conversion module
A6TBXY36 A6TBXY54 A6TBX70 A6TBX36-E A6TBY36-E A6TBX54-E A6TBY54-E A6TBX70-E
TECHNICAL BULLETIN
[ 2 / 3
]
[Issue No.] FA-A-0237-A
Q8BAT connection cable QC10BAT
Cable for connector/terminal block converter module
AC05TB AC10TB AC20TB AC30TB AC50TB AC80TB AC100TB AC05TB-E AC10TB-E AC20TB-E AC30TB-E AC50TB-E
■Pattern 1
■Pattern 2
Conversion cable for cable A1SD75-C01H A1SD75-C01HA
Without the rating plate
Extension cable QC05B QC06B QC30B
QC12B QC50B QC100B
Safety circuit part extension cable
QS90CBL-SE01 QS90CBL-SE15
Connection cable between personal computer and programmable controller CPU
QC30R2
TECHNICAL BULLETIN
[ 3 / 3
]
[Issue No.] FA-A-0237-A
3
Changeover period
The changes will take place one by one for each product manufactured on and after May 2017. Note that, depending on stock status, both the products before and after change may be distributed in the market around that time. Please be understanding of this matter.
REVISIONS
RS-232 cable connecting to CPU module
WS0-C20R2 Without the rating plate
USB/RS-232 conversion cable WS0-C20M8U Without the rating plate
RS-232 connection converter cable
Q12DCCPU-CBL
Packaging label
Version Print Date Revision
- June 2017 First edition
A October 2017 Addition of Pattern 2 to "After change" column of "Cable for connector/terminal block converter module" row in the table
